- Page 1 Blizzard Lighting, LLC www.blizzardlighting.com Waukesha, WI USA Copyright (c) 2014...
-
Page 2: Table Of Contents
Using the IR Remote Control DMX Channel Values In-Depth Troubleshooting 5. Appendix A Quick DMX Lesson Keeping Your SkyBox™ Chroma As Good As New Returns (Gasp!) Shipping Issues Tech Specs Dimensional Drawings Page 2 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... - Page 3 Under extreme temperature conditions damage may occur. Elevated temperatures in general shorten the life of your battery pack. Page 3 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC...
-
Page 4: Skybox™ Chroma
Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. -
Page 5: Safety Instructions (Don't Run With Scissors!)
Caution! There are no user serviceable parts inside this unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact Blizzard Lighting via email at support@ blizzardlighting.com. Page 5 SkyBox™... -
Page 6: Meet The Skybox™ Chroma
32-bit Dimming W2 Intensity UV2 Intensity UV2 Intensity Layer 1 Strobe Layer 1 Strobe Layer 2 Strobe Layer 2 Strobe 32-bit Dimming Colors + Auto Auto Mode 32-bit Dimming Page 6 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 7: The Skybox™ Chroma Pin-Up Picture
(Layer 2) 4-Button LCD Control Panel Figure 2: The Rear Connections Antenna DMX In DMX Out AC Power Out Power Switch AC Power In RF-ID LED Charge Status Page 7 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 8: Setup
Using Skywire™ Wireless DMX In addition to the unbridled thrill you already received the first time you turned on your fixture, you’ll be delighted to know that the SkyBox Chroma’s wireless Skywire™ DMX system is designed to work seamlessly with all Blizzard Lighting wireless DMX products. -
Page 9: Using The Intelion™ Battery System
4. Once the clearest channel is auto-selected, the status LEDs will blink quickly on both the transmitter and receiver. NOTE: The color of the SkyBox Chroma’s status LED DURING operation does not indicate channel group, instead it indicates whether the unit is transmitting or receiving. -
Page 10: Cable Connectors
Step 3: Connect other fixtures in the chain from output to input as above. Place a DMX terminator on the output of the final fixture to ensure best communication. Page 10 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 11: Fixture Linking (Master/Slave Mode)
• Safety cables MUST ALWAYS be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Page 11 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 12: Operating Adjustments
Press the <ENTER> button to select the menu function currently displayed, or to enable a menu option. To return to the previ- ous option or menu, press the <MENU> button. Page 12 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 13: Control Panel Menu Structure
1 - 7 Selects wireless channel group (1-7) IR MODE <ENTER> Set to use IR remote control (sold separately) OUT MOD <ENTER> Power output mode: H=100%, M=75%, S=50% Page 13 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 14: Dmx Mode
58 Red+Green+Blue+White+UV 17 Blue+UV 38 Blue+Amber+UV 59 Red+Green+Amber+White+UV 18 Amber+White 39 Blue+White+UV 60 Red+Blue+Amber+White+UV 19 Amber+UV 40 Amber+White+UV 61 Green+Blue+Amber+White+UV 20 White+UV 41 Red+Green+Blue+Amber 62 All Colors: R+G+B+A+W+UV Page 14 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 15: Strobe
1.) Navigate the menu using the <MENU> button until you reach OUT MOD. 2.) Select 0 (High: 100%), 1 (Medium: 75%), or 2 (Battery Saver: 50%) output mode. 3.) Press the <ENTER> button to confirm. (See page 9) Page 15 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 16: Using The Ir Remote Control
Backspace Button - Press the < > in any mode to activate IR MODE. Enter - The < > button is used to save a selected user setting. Page 16 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 17: Dmx Channel Values In-Depth
106 <--> 155 Mode 2 = 32-bit, 0-50% intensity range 156 <--> 205 Mode 3 = 32-bit, 0-75% intensity range 206 <--> 255 Mode 4 = 32-bit, full intensity dimming Page 17 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... - Page 18 000 <--> 255 Layer 2 Amber Intensity (0% <--> 100%) 000 <--> 255 Layer 2 White Intensity (0% <--> 100%) 000 <--> 255 Layer 2 UV Intensity (0% <--> 100%) Page 18 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC...
-
Page 19: Troubleshooting
Make sure all connectors are seated properly and securely. ing / Responding Use Only DMX Cables and/or check cables for defects Erratically Install a Terminator. Reset fixture(s). If your problem persists or isn’t listed contact support@blizzardlighting.com. Page 19 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 20: Appendix
It is flexible, robust, and scalable, and its ability to control everything from dimmer packs to moving lights to foggers to lasers makes it an indispensable tool for any lighting designer or lighting performer. Page 20 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 21: Keeping Your Skybox™ Chroma As Good As New
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 21 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 22: Tech Specs
Neutrik AG, Neutrik USA and their related entities, however they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG. Page 22 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... -
Page 23: Dimensional Drawings
Dimensional Drawings 6.81 in (173 mm) Page 23 SkyBox™ Chroma Manual Rev. A © 2014 Blizzard Lighting, LLC... - Page 24 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
