Mono -> Stereo -> Mono
This routing mode also allows for both channels to be run at once, but in this case, they are being run
in parallel. The Channel Balance control in the Neuro sound editor comes in handy in this routing
mode, as it controls the relative mix levels of each channel. When Ch. 1 and Ch. 2 are linked, the
processing will be the same for both channels. When they are unlinked, you can configure separate
parameters for Channel 2.

Preset Storage and Recall

User Presets store all user-editable parameters. This includes the knob positions, parameter settings,
frequencies, routing options, external control, and the full list of Neuro/MIDI-accessible parameters.
Included in every preset are settings for either channel (Channel 1 [Mono] or Channel 2). After a
preset is recalled, you can always tweak the top-level controls in a performance situation by turning
the knob. The knob parameter will then "jump" to the current knob position as it is rotated.

Recalling Presets

The first six User Presets are accessible via the onboard hardware or with an external footswitch in
the following ways:
1. Move the toggle switch to left, center, or right to access presets #1-3.
2. Press the ALT button, then while the Control LED is flashing, move the toggle switch to access
presets #4-6, or press + hold the footswitch when the pedal is OFF for 5 seconds (or 2 second in
"Quick Change" mode) to access the Red LED (presets #4-6).

Recalling MIDI Presets

All 128 available User Presets are accessible with an external MIDI controller. MIDI controllers can be
connected via USB port at the top of the pedal, or through a Neuro Hub, which connected to the
CONTROL INPUT at the top of the pedal. All 128 User Presets can be recalled with the corresponding
