LEVEL Knob
Adjusts the overall output volume. Turn clockwise for more volume, or counterclockwise for less
volume. Note: Due to the varying nature of the presets and band-splitting options, the overall
output level may change for each preset, adjusting the range of this control. Because of this, there is
no hard-set "unity gain" point on the knob.
SUSTAIN/BASS Knob
Adjusts the sustain of the distortion by manipulating the input gain before the compressor. Turn
clockwise for more sustain and a bit more saturation. Turn counterclockwise for less sustain and a
more open sound/feel.
In ALT mode, this knob controls the amount of bass frequencies present in the outgoing signal. Turn
clockwise for more low end, and turn counterclockwise for less low end.
TREBLE/MID Knob
Controls how bright or mellow the overall effect is. Turn clockwise for a more top end bite, or turn
counterclockwise for a darker sound with attenuated high frequencies.
In ALT mode, this knob controls the amount of midrange present in the distortion. Turn clockwise for
a more warm, classic sound, and turn counterclockwise for a more scooped, modern sound.
Preset Selector Toggle
Use the Ultrawave's three-position toggle switch and two preset banks to easily access six different
presets. First Preset Bank (indicated by the green center LED): default the center toggle switch
selects between three presets stored in the first bank of presets. Second Preset Bank (indicated by
the red center LED): Pressing the ALT button on the topside of the pedal opens access to the second
bank of presets. After pressing the ALT button, the small LED at the top of the pedal's face will start
to blink, indicating that the second preset bank is accessible with the toggle switch. Upon moving the
toggle switch the center LED will turn red indicating the current preset is drawn from the second
bank.
