20. BIPOLAR MODE INDICATOR: This
lamp lights when the unit is keyed in the bipolar
mode.
21. SINGLE PAD MODE INDICATOR: The
indicator will light when this mode is in effect.
22. SINGLE FOIL PAD SELECT: Selects the
Single Pad (Foil) Mode by pressing and releasing
the key.
23. RETURN MONITOR: Illuminates when
the unit detects a problem in the return electrode
circuit. In DUAL pad mode, the indicator will
illuminate when the Monitor Set has not been
set, or a return electrode cable is open or shorted,
or the type of return electrode used does not
match the type selected, or when patient resis-
tance is out of range. In SINGLE pad mode,
it will illuminate if either of the return electrode
cables is open. In addition, an alarm tone will
sound when a Return fault is detected for either
type of electrode AND a monopolar activation is
attempted. The unit will not produce monopolar
energy when this indicator is illuminated.
24. DUAL PAD MODE SELECT: Selects the
Dual Pad (Foil) Mode by pressing and releasing
the key.
25. DUAL PAD MODE INDICATOR: The
indicator will light when this mode is in effect.
26. MONOPOLAR COAGULATION POWER
INCREASE KEY: Increases the output power
level of the Coag mode when depressed.
27. MONOPOLAR COAG MODE
INDICATORS: This lights when the unit is
keyed in the monopolar coagulation mode.
28. MONOPOLAR CUT POWER INCREASE
KEY: Increases the output power level of the
selected cut mode, Pure Cut or Blend, when
depressed.
2.4.2 Output Panel
The output panel contains the power circuit
breaker and the required patient connection jacks
for electrosurgery. Refer to the OUTPUT PANEL
portion of Fig. 2.1.
1. CIRCUIT BREAKER: Primary power switch
for the unit; turns unit on and off. Also provides
double-pole power line overload protection.
2 & 3. HAND SWITCHABLE MONOPOLAR
ACCESSORY JACKS: Two independent sets of
color coded banana jacks are provided for the
connection of hand switched monopolar accesso-
ries, such as the Aspen Hand-trol. Hand switch-
able monopolar coagulating forceps may be used
by connecting to the red and lower black jacks.
These jacks may be activated only by the accesso-
ries connected to them.
4. FOOT SWITCH CONTROLLED
MONOPOLAR ACCESSORY JACK: This jack
accepts accessory cables or adapters equipped
with standard active (Bovie #12) plugs. This
jack can be activated only by the monopolar foot
switch.
5. TWO-PIN RETURN ELECTRODE JACK:
This is a standard two-pin return electrode jack.
6 & 7. BIPOLAR ACCESSORY JACKS: Bipolar
output, activated by the bipolar foot switch or
by hand switchable bipolar accessories, appears
between these blue banana jacks.
8. BIPOLAR SWITCH JACK: Hand switchable
bipolar accessories must be connected such that
the hand switch contacts are connected between
this black miniature banana Bipolar Switch Jack
and the lower blue Bipolar Accessory Jack (6).
