2.4.3 Rear Panel
The rear panel contains the foot switch connec-
tors and power cord. Refer to the REAR PANEL
portion of Fig. 2.1.
1. MONOPOLAR FOOT SWITCH
CONNECTOR: This 4-pin threaded connector
is designed to accept plugs attached to any two
treadle monopolar foot switch available from
Aspen Labs.
2. BIPOLAR FOOT SWITCH CONNECTOR:
A 3-pin threaded connector designed to accept a
single-treadle bipolar foot switch.
2-6
3. POWER CORD: Supplies ac mains power
to the unit. It should only be connected to a
source of power corresponding to that listed
on the nameplate. Supplied with a standard 3-
prong, parallel-blade, hospital grade plug (U.S.A.
Domestic only).
4. NAMEPLATE: Specifies Aspen model name,
serial number, nominal line voltage, frequency,
current, and power consumption.
5. POWER INLET CONNECTOR: Accepts a
CEE22 6A or 10A mains power cord (IEC units
only).
