ConMed Sabre 2400 Operators & Service Manual page 13

OPERATING MODES AND NOMINAL OUTPUT PARAMETERS
MODE
MONO PURE CUT
MONO BLEND
MONO COAG
BIPOLAR COAG
*(Bipolar Coag crest factor decreases as power setting increases.)
CONTROLS:
Monopolar Cut Power Increase Key:
Monopolar Cut Power Decrease Key:
Monopolar Pure Mode Select Key:
Monopolar Blend Mode Select Key:
Monopolar Coag Power Increase Key:
Monopolar Coag Power Decrease Key:
Bipolar Power Increase Key:
Bipolar Power Decrease Key:
Single Pad Select:
Dual Pad Select:
Monitor Set Point Key:
Volume Increase Key:
Volume Decrease Key:
Circuit Breaker:
Preset Select ("SEL")
Preset Store
INDICATORS:
Monopolar Cut Mode Indicator:
Monopolar Coag Mode Indicator:
Bipolar Mode Indicator:
Monopolar Cut Power Digital Display:
Monopolar Coag Power Digital Display: Red LED digital displays
Bipolar Power Digital Display:
Return Monitor Indicator:
Resistance Indicator:
Return Monitor Dual Pad Indicator:
Return Monitor Single Pad Indicator:
Monopolar Cut Mode Select:
Power Line Breaker:
Preset Memory Location
MAX. POWER
(WATTS) RESISTANCE
(OHMS)
300
180
120
50
Gray UP push button
Gray DOWN push button
Gray push button
Gray push button
Gray UP push button
Gray DOWN push button
Gray UP push button
Gray DOWN push button
Gray push button
Gray push button
Gray push button
Gray button
Gray button
Lighted rocker switch
Gray push button
Gray push button
Yellow LED
Blue Incandescent Light
Blue Incandescent Light
Red LED digital displays
Red LED digital displays
Red LED
Green LED bar graph
Green LED
Green LED
Yellow LED
Green light
Red LED digital display
LOAD CREST
FACTOR
300 1.8
300 2.5
500 7.0
50 1.5-12.1*
R
MAX. OPEN
CIRCUIT
VOLT P-P
2000
2200
9000
280
1-7
