Figure 6. Pad Mounting Bracket Installation; Figure 7. Pole Mount Dimensions - ADTRAN T200 H2TU-R Installation And Maintenance Manual

nut*
split
washer*
flat
washer*
Mounting
Pad mounted stud*
Bracket
(4 places)
*Customer supplied
Pad arrangement is representative

Figure 6. Pad Mounting Bracket Installation

9. Hoist the cabinet to an upright position and
center it over the pad.
CAUTION
The minimum internal bend radius for cable
stubs is nine inches.
10. At this time, on the cable stub model, the cable
stubs should be fed through their designated
conduit or other route per craft plan.
11. Lower the cabinet with attached brackets onto
the pad ensuring the four bottom bracket
5/8 inch bolt holes align with the pad fastener
arrangement. Secure with customer supplied
fasteners. Continue feeding the cable stubs as the
cabinet is lowered.
12. On the ground lug on the cabinet bottom next to
the spare cable penetration attach an
appropriately sized (6 AWG) ground cable to the
most direct path to ground. Ground cable and
connectors are customer supplied.
CAUTION
Without positive ground surge protection is
lost.
13. After the cabinet is secured to the pad the front
and back security access covers can be installed
6
13. If lifting details are to be removed, replace the
sealing washer
Pole Mount Installation
Pole mounting has two configurations:
•
bolt torque:
100-110 in-lbs
•
The pole-mount or H-frame support structure must
5/8" dia
bear the weight of a fully equipped cabinet (200 Lbs).
The weight and the distance the cabinet will be
installed above the ground determines the type of pole
configuration to be selected. Refer to Figure 7 for
pole mount access clearances.
1. At the installation site remove all packaging
2. Remove and set aside the Mounting Hardware
3. The cabinet is bolted to two boards running
Section 61150090L1-5A, Issue 1
on the pad mounting brackets using the included
fasteners. Tighten to 10-15 in-lbs. Install with
the access cover lip facing in and against the
cabinet's bottom panel. See Figure 4.
fasteners removed in step 4 ensuring the sealing
washers are installed next to the cabinet side
panels.
Mounted to a single pole on either the left or
right side panel.
H-frame where the cabinet is supported by a
frame arrangement at either the left or right side
panel.
material enclosing the cabinet.
Kit. Verify kit contents per Table 3.
across the wood box frame. Remove the screws
securing the two boards to the wood box frame.

Figure 7. Pole Mount Dimensions

61150090L1-5A
