III. SHRINK-WRAP
After all other connections are completed, or correct
wire lengths verified, complete the shrink-wrap
process as follows:
a. Position the shrink-wrap up against the bottom
of the cabinet enclosing the entire sealing
grommet assembly.
b. Heat treat the shrink-wrap until properly
constricted around the assembly.
NOTE
On pole mounts, secure the cable exiting the
cabinet to the pole using standard practices
and customer-supplied hardware.
Proceed with Step 5 of the Splice Wires sub section.
5. Insert the circuit pack into the desired slot. The
card's edge connector is offset and must be
properly aligned to ensure connectivity.
CAUTION
The FPU at the CO must be online for fan
operation. For the best cooling results, fully
load the top shelf with circuit cards before
loading the bottom shelf.
6. Connect the wiring in cable stubs based on the
appropriate matching slot used.
7. Refer to Table 5A and 5B for splice module
connections and Table 6A and 6B for Circuit
Technology Configuration charts. Table 5 also
provides circuit and pair identification to
configure the cards listed in the table.
NOTE
Refer to the 3M MS
System Instructions Booklet for splicing and
connecting to 4005-DPM Super Mate
Pluggable Modules.
8. Connect the ground lug on the bottom of the
cabinet to an appropriate 6 AWG ground cable
and earth ground.
61150090L1-5A
2
™ Modular Splicing
Section 61150090L1-5A, Issue 1
CAUTION
Without positive ground the cabinet does not
provide surge protection.
9. Inspect and clean the door gasket and gasket
sealing area prior to closing the front or rear
doors. If there is visible damage, replace the
door gasket.
10. Tighten the tamper resistant security screws on
the front and rear doors using a 7/16 inch nut
driver or an equivalent tool. While loosening or
tightening the security screws, alternate between
the top and bottom screws to allow even
pressure. Tighten to 10-15 in-lbs. maximum.
