Radio Unit R&S
CRTU-RU
Serial number
83 69 17
83 91 55
83 58 55
If none of cases above applies, please contact the central R&S Service in Munich in order to obtain
the correct K5 code.
Enter the CRTU-K2 as well as the CRTU-K5 (for CRTU-G only) codes.
Boot up within BootMagic
Preparing WIN2000:
Note: During the following setup procedure you will be asked to enter your own user and company
name as well as the Windows 2000 product key. This key can be found in the upper left corner
of the right side panel of the device, inside the gray metal case.
Reboot into "Windows OPSW".
Click Next, accept the agreement, click Next, Next and enter name and company.
Click Next, insert the Windows 2000 product key, click Next and enter company name.
Click Next, set the COMPUTERNAME and PASSWORD for administrator.
Click Next, select Time Settings, Next, select Typical Settings, Next, Next, Finish.
Reboot (automatically done), click Next and "User must enter user name".
Click Next, Finish and login.
In case the CRTU-RU belongs to a CRTU-G or CRTU-S system, copy the file "REG_INFO.DAT"
which has been saved from the exchanged hard disk to the path "C:\CONFIG".
Boot up within BootMagic
version of CRTU-RU software is installed on the CRTU-RU. This depends on the system that the
CRTU-RU belongs to (e.g. CRTU-G, CRTU-S, CRTU-W).

Installing the GSM Operational Software

Note: The GSM operational software CR02P2P can be installed only if the CRTU-RU belongs to a
CRTU-G or CRTU-S system. The CR02P2P software is located on the Service Harddisk
(1139.0573.00) which is part of the Service Kit CRTU-Z3 (1139.0509.02). For the file-copy
process it is necessary to connect both harddisks to the IDE controller of the CRTU-RU. To this
end the unit must be opened.
Configure the Service Harddisk with a jumper-connector as Device 1 (if not yet done).
Remove the casing (tube) and the cover plate of the CRTU-RU.
Use the Y-cable (1139.0550.00) to connect the customer's harddisk (=destination harddisk) as IDE
Master and the Service Harddisk (=source harddisk) as IDE Slave to the primary IDE controller of the
CRTU-RU.
Boot up within BootMagic
Login as "Administrator" with no password.
Open the Windows Explorer and browse to drive volume "SERVICE_HARDDISK".
Start the installation process of the Operational Software by calling "\CR02P2P\1Vxx\SETUP.EXE".
1140.0050.82
K5 Code
2B80768F4DB4C662
11419B13E092AD39
7D7FF1541D22C4D4

menu into "Windows OPSW".

menu into "DOS OPSW / Service" and make sure that the currently valid

menu into "Windows OPSW".
3.25
Module Replacement
E-4
