Rohde & Schwarz CRTU-RU Service Manual page 57

Radio Unit R&S
CRTU-RU
Item
No.
Description
RX Average Noise Level
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 10 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 500 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 1000 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 1500 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 2200 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 47 dBm, f = 2700 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 10 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 500 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 1000 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 1500 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 2200 MHz
RX average noise level
RF1, RBW = 1 kHz,
expPow = 10 dBm, f = 2700 MHz
RX average noise level
RF2, RBW = 500 kHz,
expPow = 33 dBm, f = 10 MHz
RX average noise level
RF2, RBW = 500 kHz,
expPow = 33 dBm, f = 500 MHz
RX average noise level
RF2, RBW = 500 kHz,
expPow = 33 dBm, f = 1000 MHz
RX average noise level
RF2, RBW = 500 kHz,
expPow = 33 dBm, f = 1500 MHz
RX average noise level
RF2, RBW = 500 kHz,
expPow = 33 dBm, f = 2200 MHz
1140.0050.82
Measure-
ment to
Min.
section
RX average
noise level
1.37
Measurement
uncertainty
Actual Max.
–100
–100
–100
–100
–100
–95
–100
–100
–100
–100
–100
–95
–73
–73
–73
–73
–73
Test Reports
Unit
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
dBc
E-4
