TV-Free
Universal video-in-motion Interface
Non p and p version for low speed CAN
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle's software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
Version 28.01.2013
Advertisement
Related Manuals for Caraudio-Systems TF-U501
Summary of Contents for Caraudio-Systems TF-U501
- Page 1 TV-Free Universal video-in-motion Interface Non p and p version for low speed CAN Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product.
- Page 2 Contents 1. Prior to installation 1.1. Delivery contents 1.2. Pin-assignments 1.3. Dip switch functions of the TV-501 2. Installation 3. Specifications 4. Technical support 1. Prior to installation Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation must be free of moisture and away from heat sources.
- Page 3 1.2. Pin-assignments Pin-assignment harness TV-UNI Pin-assignment male 8pin connector of TV-500 Cable colour Pin-No. Assignment ● Yellow Pin 4 CAN-HIGH – connection to the head-unit ● Blue Pin 3 CAN-LOW – connection to the head-unit ●● Yellow/Black Pin 8 CAN-HIGH – connection to the vehicle ●●...
- Page 4 2. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.
- Page 5 Alternatively for CCC it is possible to set dip-switch 1 of the CAN box TV-401 to ON. But then the navigation performance is disturbed on the first few kilometres of driving. Version 28.01.2013 TF-U501...
- Page 6 Vehicles with BMW E65 Professional Place of installation is at the back side of the navigation unit. 7series (E65/66) Compatible vehicles Vehicle/ navigation Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 All vehicles Cable colour Assignment No liability for vehicle wire colors and pin definition! Possible changes by the vehicle manufacturer.
- Page 7 3. Specifications Operation voltage 10.5 – 14.8V Stand-by power drain <2mA Operation power drain ~60mA Power consumption ~0,08W Temperature range -30°C to +80°C Weight Measurements (box only) W x H x D 76 x 27 x 54 mm Version 28.01.2013 TF-U501...
