NewHeights™ Fixed Conference Desk Assembly Instructions
Warranty: raproducts.com/warranty
Failure to comply with or observe all assembly, safety, and
operation instructions and warnings regarding the use of this
product may result in serious property damage or bodily injury.
Instruction #54038 • Dated: 12/28/2017
1 of 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RightAngle NewHeights Fixed Conference Desk
Summary of Contents for RightAngle NewHeights Fixed Conference Desk
- Page 1 NewHeights™ Fixed Conference Desk Assembly Instructions Warranty: raproducts.com/warranty Failure to comply with or observe all assembly, safety, and operation instructions and warnings regarding the use of this product may result in serious property damage or bodily injury. Instruction #54038 • Dated: 12/28/2017 1 of 5...
- Page 2 NewHeights™ Fixed Conference Desk #54038 Hardware Included Tools Required for Assembly: for Assembly: BILL 3/16” Power Driver with Tape #2 Square Head Allen Wrench Adjustable Torque Measure Driver Bit May have extra hardware 3/4” Wood Screw Socket Screw 51708 xVaries U-Channel xVaries Cross...
- Page 3 U-Channel 51708 xVaries xVaries The following instruction illustrates a RightAngle manufactured base and work- surface. If your worksurface is from another • Lay worksurface on a protected surface. manufacturer, you are responsible for the • Align #3 U-channels with pre-drilled pilot holes.
- Page 4 NewHeights™ Fixed Conference Desk #54038 BILL Socket Screw Cross Support Cover x4 • Install #2 socket screws through the cross support holes and into the weld nuts held in place by the leg stickers. Do this to both cross supports using four (4) screws per support.
- Page 5 NewHeights™ Fixed Conference Desk #54038 BILL 3/4” Wood Screw 51708 xVaries • Align assembled base with pre-drilled pilot holes. • Screw in base with #1 wood screws. Do not overtighten. Note: This workstation is used with a variety of bases. Your worksurface and base may have extra holes.
