Fig. 10
Lowering Stand to its Lowest
Position
Begin with the stand in the locked
upright position, as shown above in
figure 11.
Firmly grip the handle with both hands
and place one foot against the kick bar
C. Pull back on the handle and lower the
stand to the ground, as shown (Fig. 12).
To Level Stand
The stand is equipped with two
adjustable feet for leveling the stand.
Adjust the height of the foot (See Fig.
13):
1. Loosen the top wing nut X.
2. Adjust the height of the foot by
raising or lowering the bottom wing
nut Y.
3. Retighten both wing nuts securely
once the stand is level.
Operating Instructions
Fig. 11
Fig. 13
-9-
C
X
Y
Fig. 12
