2610047964.qxp_GTA47W 11/15/19 9:12 AM Page 29
Fig. 10
Bajada de la base de soporte
hasta su posición más baja
Comience con la base de soporte en la
posición vertical bloqueada, de la
manera que se muestra arriba en la
figura 11.
Agarre firmemente el manillar con las
dos manos y coloque un pie contra la
barra para el pie C. Jale hacia atrás el
manillar y baje la base de soporte hasta
el piso, de la manera que se muestra en
la ilustración (Fig. 12).
Para nivelar la base de
soporte
The stand is equipped with two
adjustable feet for leveling the stand.
La base de soporte está equipada con
dos pies ajustables para nivelarla.
Ajuste la altura del pie (vea la Fig. 13):
1.
Afloje la tuerca de mariposa superior
X.
2.
Ajuste la altura del pie subiendo o
bajando la tuerca de mariposa
inferior Y.
3.
Reapriete firmemente ambas tuercas
de mariposa una vez que la base de
soporte esté nivelada.
Instrucciones de utilización
-29-
Fig. 11
C
Fig. 13
Fig. 12
X
Y
