ARMO 2D

To check the accuracy of line laser level

To check the accuracy of line laser level (slope plane)
Set up the instrument between two walls� the distance is 5 m.Turn on the Cross Line Laser and mark the point of cross
laser line on the wall.
Set up the instrument 0�5-0�7m away from the wall and make� as described above� the same marks. If the difference
{a1-b2} and {b1-b2} is less then the value of "accuracy" (see speсiications)� there is no need in calibration.
Example: when you check the accuracy of Cross Line Laser the difference is {a1-a2}=5 mm and {b1-b2}=7 mm. The
instrument's error: {b1-b2}-{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.
If the accuracy of Cross Line Laser isn't corresponding with claimed accuracy� contact the authorized service center.
