Mocka Addi Six Drawer - Wide Assembly Instructions Manual page 2

Addi Six Drawer - Wide
Assembly Instructions
1
F
E
E
F
G
C C
4
Attach 3x slide rail (F) and 3x slide rail (G) to panels [3] and [4]
as shown and secure with 18x screws (E). Tighten with a screwdriver.
Insert 4x bolts (C) into panels [3] and [4]. Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
C C
3
F
E
F
E
E
E
CR
G
E
E
G
G
2
5
F
E
E
E
CR
G
5
Attach 3x slide rail (G) to panel [5] as shown and secure with
9x screws (E). Flip the panel [5], attach 3x slide rail (F) to the
other side of panel [5] as shown and secure with 9x screws (E).
Tighten with a screwdriver.
E
CL
F
F
F
E
FLIP
E
G
E
G
E
G
2
