Mocka Addi Six Drawer - Wide Assembly Instructions Manual page 10

Addi Six Drawer - Wide
Assembly Instructions
17
Drawers x6
R
15
E
11
12
16
E
I
11
12
13
x2
14
x2
Attach panel [19] to panels [15], [16] and [17] using 36x screws (R).
Now attach 6x slide rail (I) to panel [16] and 6x slide rail (H) to panel
[15] as shown. Secure with 24x small screws (E) and tighten with a
screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
R
19
R
16
13
x2
14
x2
E
E
H
15
18
13
13
Insert the assembled drawers into the unit ensuring they slide smoothly
along the rails.
12
14
14
11
10
