COBHAM EXPLORER 727 Getting Started page 4

With magnetic mounts:
NOTE: Before using the magnetic mounts, first make sure the roof of the vehicle is made of
a magnetizable material! Also wipe the surface clean before mounting the antenna, to
improve the contact between the roof and the magnets and to avoid scratches in the
surface of the roof.
Use the Magnetic Mount kit from Cobham
SATCOM.
3. Mount the magnetic mounts on the 3
"legs" of the antenna according the
installation manual.
4. Place the antenna on the roof of your
vehicle.
Important! Cobham SATCOM (Thrane &
Thrane A/S) assumes no liability for any
damage caused by the antenna falling off
the vehicle or stressing the mounting
surface.
Insert the SIM card (provided by your Airtime Provider)
The SIM slot is located in the connector panel of the terminal.
1. Open the SIM cover.
2. Insert the SIM card into the SIM slot
with the chip side facing up. Press gently
until it clicks.
3. Slide the lock to secure the SIM card.
4. Close the SIM cover.
