Send A Fax - COBHAM EXPLORER 727 Getting Started

To make a call to a phone connected to the EXPLORER 727 terminal, dial +870 <mobile
number> (+ is the prefix to call out of the country you are located in).
NOTE: There are two voice numbers, one for 3.1 kHz Audio and one for Standard voice.
Make a local call
You can make local calls between phones connected to the same terminal.
To make a local call to an IP handset, dial the number of the IP handset (e.g. 0501) followed
by #.
To make a local call to an ISDN phone, dial 0401 or 0402 followed by #.
To make a local call to an analog phone, dial 0301 or 0302 followed by #.
For information on allocation of local numbers, refer to the User Manual.

Send a fax

To send a fax from the Phone/Fax interface of the terminal, dial
2* 00 <country code> <phone number> #
Example: Cobham SATCOM in Denmark: 2* 00 45 39558888 #
"2*" forces the connection to use 3.1 kHz Audio. The connection uses Standard Audio by
default.
When using the ISDN interface, dial 3* before the number to force the connection to use
UDI.
To send a fax to the terminal, dial +870 <3.1 kHz Audio mobile number>
Alternatively you can send a fax directly from your browser, using a "web fax" feature
provided by an electronic fax provider.
Make an IP handset connection
To connect an IP Handset, do as follows:
1. Start up the EXPLORER 727 terminal.
2. Connect the LAN cable between the IP
Handset cradle and one of the LAN/PoE
connectors on the terminal. The handset
starts up automatically.
3. If a PIN is required in order to access the
terminal, enter the PIN as described in
Enter the PIN on page 5. To see if a PIN
is required, select BGAN > PIN Status
in the IP Handset menu system.
8
When the top right corner of the display
shows you can make calls from the
handset.
