10
STEP 3: Compile source code
After the source code is written, select the Build option from the Build menu to compile it.
When the source code is compiled, the .hex file is generated and ready to be uploaded into the MCU.
STEP 4: Uploade .hex file into MCU
To upload .hex file we will use StartUSB for AVR that was created in step 2. Just press Ctrl+F2 (or chosen shortcut) and
.hex file will be automatically transferred into the MCU, Figure 6.
MikroElektronika
Click on the Build option or press Ctrl+F9 on keyboard
StartUSB for AVR
Select desired shortcut (in this case
Ctrl+F2) from the drop down list
Click OK
