ENGLISH
05CH Mode
DMX
Channel
1
2
3
4
5

MAINTENANCE

• Make sure the area below the installation place is free from unwanted persons during servicing.
• Switch off the unit, unplug the mains cable and wait until the unit has been cooled down.
During inspection the following points should be checked:
• All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded.
• Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation.
• When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced.
• The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
• In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly.
• The interior of the device should be cleaned annually using a vacuum cleaner or air-jet.
• The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit's optics.
• Clean with a soft cloth using normal glass cleaning products.
• Always dry the parts carefully.
• Clean the external optics at least once every 30 days.
• Clean the internal optics at least every 90 days.
Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!

SPECIFICATIONS

This device was designed to produce decorative effect lighting and is used in light show systems.
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
Mains Input:
Max. Power consumption:
Sound Control:
DMX connections:
DMX channels:
Par LEDs:
Working temperature:
Size:
Weight:
All the information is subject to change without prior notice You can download the latest version of this user
JB SYSTEMS®
DMX-value
000-255
000-255
000-255
000-255
000
001-010
011-255
AC 100~240V, 50/60Hz
10W
Internal microphone
3pin XLR male / female
3 / 5 channels + Ledcon-02 Mk2 mode
12x 3Watt RGB Led's
10°C to 40°C
150x160x90mm
0.4 kg
manual on our website:
6/6
function
Red color dimmer
Green color dimmer
Blue color dimmer
Master Dimmer
No Effect
Sound Control
Strobe Slow to fast
www.jb-systems.eu
USER MANUAL
MINI-PAR 12TC
