ENGLISH

OVERHEAD RIGGING

• Important: The installation must be carried out by qualified service personal only. Improper
installation can result in serious injuries and/or damage to property. Overhead rigging requires
extensive experience! Working load limits should be respected, certified installation materials
should be used, the installed device should be inspected regularly for safety.
• Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
• Locate the fixture in a well ventilated spot, far away from any flammable materials and/or liquids. The
fixture must be fixed at least 50cm from surrounding walls.
• The device should be installed out of reach of people and outside areas where persons may walk by or be
seated.
• Before rigging make sure that the installation area can hold a minimum point load of 10times the device's
weight.
• Always use a certified safety cable that can hold 12 times the weight of the device when installing the unit.
This secondary safety attachment should be installed in a way that no part of the installation can drop
more than 20cm if the main attachment fails.
• The device should be well fixed; a free-swinging mounting is dangerous and may not be considered!
• Don't cover any ventilation openings as this may result in overheating.
• The operator has to make sure that the safety-relating and machine-technical installations are approved by
an expert before using them for the first time. The installations should be inspected every year by a skilled
person to be sure that safety is still optimal.
HOW TO SET UP AND CONTROL THE UNIT
1) SOUND CONTROLLED MODE A4:
The unit runs a preprogrammed sequence to the rhythm of the music. Select this mode when only 1 unit is
used (standalone) or when the unit is placed as the first (master) unit in a chain with several units.
• Press the [MENU] button until the display shows: [A4.00] (A4. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select on of the 19 different sound modes.
2) FULL AUTOMATIC MODES A2. A3. A5. A6. A7.
The unit automatically runs a preprogrammed sequence. Different automatic modes are available:
COLOR CHANGE A2.
• Press the [MENU] button until the display shows [A2.00] (A2. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select the desired speed. (01=slowest, 32=fastest)
COLOR FADE A3.
• Press the [MENU] button until the display shows [A3.00] (A3. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select one of the 19 different modes.
• Press the [ENTER] button
• Now use the [UP] or [DOWN] to select the desired speed. (01=slowest, 32=fastest)
COLOR CHANGE + STROBE A5.
• Press the [MENU] button until the display shows [A5.00] (A5. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select one of the 19 different modes.
• Press the [ENTER] button
• Now use the [UP] or [DOWN] to select the desired strobe speed. (01=slowest, 32=fastest)
AUTOMATIC RANDOM MODE A6.
• Press the [MENU] button until the display shows [A6.01]
• A show of different types of effects (fade, color change, strobe, ...) will start
COLOR CHANGE + PULSE EFFECT A7.
• Press the [MENU] button until the display shows [A7.00] (A5. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select one of the 19 different modes.
