ENGLISH
• Press the [ENTER] button
• Now use the [UP] or [DOWN] to select the desired pulse speed. (01=slowest, 32=fastest)
3) STATIC COLOR MODES A1. & RGBW.
You can set a static color in 2 Different ways:
PRESET COLOR A1.
• Press the [MENU] button until the display shows [A1.00] (A1. Followed by 2 numbers)
• Now use the [UP] or [DOWN] to select the desired color
MANUAL CUSTOM COLOR.
If you need a color that is not available in the presets, you can compose your own color by adapting the
intensity of each individual color (Red, Green, Blue)
• Press the [MENU] button until the display shows [rxxx] (r Followed by 3 numbers)
• Now use the [UP] or [DOWN] to set the intensity of the Red color
• Press the [MENU] button until the display shows [Gxxx] (G Followed by 3 numbers)
• Now use the [UP] or [DOWN] to set the intensity of the Green color
• Press the [MENU] button until the display shows [bxxx] (b Followed by 3 numbers)
• Now use the [UP] or [DOWN] to set the intensity of the blue color

4) MASTER / SLAVE MODE:

Several units can be connected together to create nice synchronized shows. The (slave) units will follow
the instructions given by the first unit (master) in the chain.
NOTE: it is important to execute the next steps in the correct order
• Set the DMX address of all the slave units to [d001] before to connect them to the master unit .
• Connect the DMX output of the master unit to the infput of the first Slave unit.
• Connect the DMX output of the first Slave unit to the infput of the second Slave unit.
• Etc.
• Select the desired working mode in your master unit (fixed color, color fade, color change, etc...)
• All the connected slave devices will follow the program of the master unit.
You can connect up to 32 units together.
