Introduction
1.2 Description
•
•
Rated for Reliability in Harsh Environments
•
•
•
•
•
Memory Options
•
Power Supply
•
•
•
1.2
Description
The RUGGEDCOM i800 features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
1
2
3
1
2
3
4
5
6
7
8
Figure 1.1
2
RADIUS centralized password management
SNMPv3 authentication and 56-bit encryption
Immunity to EMI and heavy electrical surges
Hazardous Location Certification: Class I, Division 2
-20 to +60 °C (-4 to 140 °F) operating temperature (optional -40 to +85°C or -40
to 185 °F)
Conformal coated printed circuit boards (optional)
Die cast aluminum enclosure
Removable microSD/microSDHC card
Dual low-voltage DC inputs: 24 VDC (9-32 VDC)
Compression fit connections
CSA/UL 60950 safety approved to 85 °C (185 °F)
4
5
Failsafe Alarm Relay
Power Supply Terminal Block
Chassis Ground Terminal
POWER LEDs
ALARM LED
Copper Ethernet Ports
Access Plate
RS-232 Console Port (RJ-45)
RUGGEDCOM i800
6
7
8
RUGGEDCOM i800
Installation Manual, 01/2021, C79000-G8976-1002-06
