Required Tools And Materials; Decommissioning And Disposal - Siemens SIMATIC NET RUGGEDCOM i800 Installation Manual

Failsafe Alarm Relay
Power Supply Terminal Block
POWER LEDs
ALARM LED
Communication Ports
Access Plate
RS-232 Console Port
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM i800:
AC or DC power cord (16 AWG)
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #8-32 screws
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM i800
Installation Manual, 01/2021, C79000-G8976-1002-06
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (If Equipped) (Page
8)"
• "Failsafe Alarm Relay Specifications (Page 19)"
A pluggable terminal block. For more information, refer to:
• "Connecting Power (Page 9)"
• "Power Supply Specifications (Page 19)"
Illuminate when power is being supplied to the device by the
respective power source.
Green
Red
Off
Illuminates when an alarm condition exists.
Receive and transmit data, as well as provide access to the
RUGGEDCOM i800 Web interface. For more information about
the various ports available for the RUGGEDCOM i800, refer to
"Communication Ports (Page
The removable access plate provides access to the microSD/
microSDHC slot. Use a microSD/microSDHC card to load/store the
firmware and configuration for the device. For information about
using a microSD/microSDHC card, refer to
MicroSD/MicroSDHC Card (Page
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Tools/Materials
1.3 Required Tools and Materials
Color
Device ready
Device booting up
No power
17)".
14)".
13)".
Purpose
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
Introduction
Description
"Inserting/Removing the
3
