- Page 1 Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM i800 Edition 01/2021 https://www.siemens.com...
- Page 2 Preface Introduction Installing the Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM i800 Communication Ports Technical Specifications Installation Manual Certification 01/2021 C79000-G8976-1002-06...
- Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................v Training ..........................vi Customer Support ........................vi Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Required Tools and Materials ................. 3 Decommissioning and Disposal ................3 Installing the Device ...................... - Page 5 Table of Contents 6.1.1 CSA ........................23 6.1.2 ATEX/IEC Ex ......................24 6.1.3 European Union (EU) ..................24 6.1.4 FCC ........................25 6.1.5 FDA/CDRH ......................25 6.1.6 ISED ........................25 6.1.7 ISO ........................26 6.1.8 ACMA ........................26 6.1.9 RoHS ........................26 6.1.10 Other Approvals ....................
-
Page 6: Preface
Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. -
Page 7: Training
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request... -
Page 8: Contacting Siemens
Preface Contacting Siemens • Ask questions or share knowledge with fellow Siemens customers and the support community Contacting Siemens Address Siemens AG Industry Sector 300 Applewood Crescent Concord, Ontario Canada, L4K 5C7 Telephone Toll-free: 1 888 264 0006 Tel: +1 905 856 5288... - Page 9 Preface Contacting Siemens viii RUGGEDCOM i800 Installation Manual, 01/2021, C79000-G8976-1002-06...
-
Page 10: Introduction
Introduction The RUGGEDCOM i800 is a compact, fully managed Ethernet switch designed to operate reliably in harsh industrial environments. The flexibility of the RUGGEDCOM i800 allows the user to choose from managed or unmanaged, regular or extended temperature, fiber optical or copper interfaces, and fast or Gigabit Ethernet. With up to nine Ethernet ports, the RUGGEDCOM i800 is the perfect choice for a wide variety of demanding industrial environments such as those found in process control applications (oil and gas, petro-chemical, metals and mining, wind farms). -
Page 11: Description
Introduction 1.2 Description • RADIUS centralized password management • SNMPv3 authentication and 56-bit encryption Rated for Reliability in Harsh Environments • Immunity to EMI and heavy electrical surges • Hazardous Location Certification: Class I, Division 2 • -20 to +60 °C (-4 to 140 °F) operating temperature (optional -40 to +85°C or -40 to 185 °F) •... -
Page 12: Required Tools And Materials
Introduction 1.3 Required Tools and Materials Failsafe Alarm Relay Latches to default state when a power disruption or other alarm condition occurs. For more information, refer to: • "Connecting the Failsafe Alarm Relay (If Equipped) (Page 8)" • "Failsafe Alarm Relay Specifications (Page 19)" Power Supply Terminal Block A pluggable terminal block. - Page 13 Introduction 1.4 Decommissioning and Disposal Decommissioning This device may include sensitive, proprietary data. Before taking the device out of service, either permanently or for maintenance by a third-party, make sure it has been fully decommissioned. For more information, refer to the associated Configuration Manual. Recycling and Disposal For environmentally friendly recycling and disposal of this device and related accessories, contact a facility certified to dispose of waste electrical and electronic...
-
Page 14: Installing The Device
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens AG could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment. -
Page 15: General Procedure
Visually inspect each item in the package for any physical damage. Verify all items are included. IMPORTANT If any item is missing or damaged, contact Siemens for assistance. Mounting the Device The RUGGEDCOM i800 can be ordered with a DIN rail adapter pre-installed on the back of the chassis. - Page 16 Installing the Device 2.3 Mounting the Device Note For detailed dimensions of the device with the DIN rail adapter installed, refer to "Dimension Drawings (Page 20)". Mounting the Device To mount the device to a DIN rail, do the following: Hook the top teeth of the adapter onto the DIN rail. DIN Rail DIN Rail Adapter Figure 2.1...
-
Page 17: Connecting The Failsafe Alarm Relay (If Equipped)
Installing the Device 2.4 Connecting the Failsafe Alarm Relay (If Equipped) Removing the Device To remove the device from a DIN rail, do the following: Insert a flathead screwdriver into the slot of the sliding release and move it down. DIN Rail DIN Rail Adapter Figure 2.2 Removing the Device from a DIN Rail... -
Page 18: Connecting Power
Installing the Device 2.5 Connecting Power Normally Open Common Normally Closed Figure 2.3 Failsafe Alarm Relay Wiring Connecting Power The RUGGEDCOM i800 supports a single low DC power supply with reverse polarity and dual independent inputs. This allows for two redundant DC power sources with the same nominal voltage to be connected. - Page 19 Installing the Device 2.5 Connecting Power Connect the positive wire from the power source to the positive terminal (P1+ or P2+) on the terminal block. Positive Terminal Negative Terminal GND Terminal Chassis Ground Terminal Figure 2.4 Terminal Block Wiring – Single DC Power Supply Input Connect the negative wire from the power source to the negative terminal (P1- or P2-) on the terminal block.
- Page 20 Installing the Device 2.5 Connecting Power [Optional] If connecting a second redundant power source, repeat Step 1 Step 2, making sure to connect the power supply to the P2 ports. Positive Terminal Negative Terminal GND Terminal Chassis Ground Terminal Figure 2.5 Terminal Block Wiring – Dual DC Power Supply Inputs Connect the chassis ground terminal to protective Earth.
- Page 21 Installing the Device 2.5 Connecting Power RUGGEDCOM i800 Installation Manual, 01/2021, C79000-G8976-1002-06...
-
Page 22: Device Management
Device Management This section describes how to connect to and manage the device. Connecting to the Device The following describes the various methods for accessing the RUGGEDCOM i800 console and Web interfaces on the device. For more detailed instructions, refer to the RUGGEDCOM ROS Configuration Manual for the RUGGEDCOM i800. -
Page 23: Configuring The Device
Device Management 3.2 Configuring the Device Name Description Comment RJ45 Male DB9 Female Read to Send The DSR, RI and DTR pins are connected together internally. The CTS and RTS pins are connected together internally. Communication Ports Connect any of the available Ethernet ports on the device to a management switch and access the RUGGEDCOM i800 console and Web interfaces via the device's IP address. - Page 24 Device Management 3.3 Inserting/Removing the MicroSD/MicroSDHC Card • Do not expose the microSD/microSDHC card to large magnetic or static electric fields. • Do not bend or drop the microSD/microSDHC card. NOTICE Security hazard – risk of unauthorized access and/or exploitation. Make sure to remove the microSD/microSDHC card before decommissioning the device or sending the device to a third-party.
- Page 25 Device Management 3.3 Inserting/Removing the MicroSD/MicroSDHC Card RUGGEDCOM i800 Installation Manual, 01/2021, C79000-G8976-1002-06...
-
Page 26: Communication Ports
Communication Ports The RUGGEDCOM i800 supports several 10/100Base-TX Ethernet ports that allow connection to standard Category 5 (CAT-5) unshielded twisted-pair (UTP) cables with RJ45 male connectors. The RJ45 receptacles are directly connected to the chassis ground on the device and can accept CAT-5 shielded twisted-pair (STP) cables. Ports 1 to 8 Figure 4.1 Port Assignment... - Page 27 Communication Ports The following is the pin-out for the RJ45 male connectors: Name Description Receive Data+ Receive Data- Transmit Data+ Reserved (Do Not Connect) Figure 4.2 RJ45 Ethernet Port Pin Reserved (Do Not Connect) Configuration Transmit Data- Reserved (Do Not Connect) Reserved (Do Not Connect) For specifications on the available copper Ethernet ports, refer to "Copper Ethernet...
-
Page 28: Technical Specifications
Technical Specifications This section provides important technical specifications related to the device and available modules. Power Supply Specifications Power Minimum Input Maximum Input Internal Maximum Power Supply Type Fuse Rating Consumption 24 VDC 9 VDC 32 VDC 3A (T) (T) denotes a time-delay fuse. Failsafe Alarm Relay Specifications Note The following specifications are for Class-2 circuits only. -
Page 29: Operating Environment
Technical Specifications 5.4 Operating Environment Operating Environment The RUGGEDCOM i800 is rated to operate under the following environmental conditions. Ambient Operating -20 to 60 °C (-4 to 140 °F) Temperature -40 to 85 °C (-40 to 185 °F) (Optional) Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F) Ambient Relative Humidity up to 95%... - Page 30 Technical Specifications 5.6 Dimension Drawings 11.7 77.5 95.3 56.5 Figure 5.1 Overall Dimensions RUGGEDCOM i800 Installation Manual, 01/2021, C79000-G8976-1002-06...
- Page 31 Technical Specifications 5.6 Dimension Drawings RUGGEDCOM i800 Installation Manual, 01/2021, C79000-G8976-1002-06...
-
Page 32: Certification
Certification The RUGGEDCOM i800 device has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. Approvals This section details the standards to which the RUGGEDCOM i800 complies. 6.1.1 This device meets the requirements of the following Canadian Standards Association (CSA) standards under certificates 2058468 (general safety) and 2068170 (hazardous locations): CAN/CSA-C22.2 No. -
Page 33: 6.1.2 Atex/Iec Ex
• 12-24 VDC, 2A, Class III 6.1.3 European Union (EU) This device is declared by Siemens AG to comply with essential requirements and other relevant provisions of the following EU directives: • EN 61000-6-2 Electromagnetic Compatibility (EMC) – Part 6-2: Generic Standards – Immunity for Industrial Environments •... -
Page 34: Fcc
Methods of Measurement The device is marked with a CE marking and can be used throughout the European community. A copy of the EU Declaration of Conformity is available via Siemens Industry Online Support at https://support.industry.siemens.com/cs/ww/en/view/109475424. 6.1.4 This device has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 35: 6.1.7 Iso
Support at https://support.industry.siemens.com/cs/ww/en/view/89855782. 6.1.9 RoHS This device is declared by Siemens AG to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: China RoHS 2 •... -
Page 36: 6.1.10 Other Approvals
Certification 6.1.10 Other Approvals 6.1.10 Other Approvals This device meets the requirements of the following additional standards: • IEC 61000-6-2 Electromagnetic Compatibility (EMC) – Part 6-2: Generic Standards – Immunity for Industrial Environments EMC and Environmental Type Tests The RUGGEDCOM i800 has passed the following EMC and environmental tests. IEC 61850-3 Type Tests Test Description... - Page 37 Certification 6.2 EMC and Environmental Type Tests Description Test Levels Fast Transient Signal ports ± 4 kV @ 5 kHz DC Power ports ± 4 kV @ 5 kHz Earth ground ports ± 4 kV @ 5 kHz Oscillatory Signal ports 2.5 kV common mode @ 1MHz DC Power ports 2.5 kV common, 1 kV differential mode @ 1MHz...
- Page 38 Further Information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens AG Digital Industry Process Automation Postfach 48 48 90026 NÜRNBERG GERMANY...
