Technical Specifications
5.4 Operating Environment
5.4

Operating Environment

The RUGGEDCOM i800 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
Vibration
Shock
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing, 55 °C (131 °F), 6 cycles.
5.5

Mechanical Specifications

Weight
Ingress Protection
Enclosure
5.6

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
20
-20 to 60 °C (-4 to 140 °F)
a
-40 to 85 °C (-40 to 185 °F) (Optional)
-40 to 85 °C (-40 to 185 °F)
b
up to 95%
2000 m (6562 ft)
1 g @ 10 to 500 Hz
30 g @ 11 ms
1.0 kg (2.2 lbs)
IP40 (1 mm or 0.04 in objects)
Cast Aluminum Enclosure
RUGGEDCOM i800
