Humanscale Float Installation Manual page 3

Assembly Instructions
1
Attach the Feet
a. Turn the Base upside down so the Legs are pointing up.
b. Position the foot over the leg. Align the 4 holes in the
foot with those in the end of the leg. The longer portion
of the Foot should extend towards the front. (Fig. A)
c. Use the 5 mm hex driver, to install the (4) M8 × 30 mm
button head screws that secure the Foot to the Leg.
d. Repeat steps 1b– 1c for the second Foot.
2
Attach the Wing Brackets
a. Turn the Base over so that it rests on it' s feet.
b. Starting on the Left, locate the 4 screws on the outside end of the cross-beam where it connects to the leg (Fig. B)
c. Use the 4 mm hex driver to
Caution: Do not fully remove this screw from the cross-beam or it can cause internal misalignment.
d. Use the 4 mm hex driver to completely remove the lower-front screw, set it aside.
e. Position the Left Wing Bracket (stamped
f. Replace the lower screw through the bracket into the cross-beam. Tighten both upper and lower screws. (Fig. C)
g.
h. Repeat Steps 2c– 2f for the Right side and Right side bracket.
Fig. B
Left side shown
3
Lay a soft material beneath it to avoid scratches.
The work-surface must measure
at least 3/4" (19 mm) thick.
work-surface size
30" (800 mm) 16 ½" (420 mm)
24" (600 mm) 13 ½" (350 mm)
loosen the upper-front screw, until there is a
L) on the end of the cross-beam, extending forward.
loosen
remove
d
d
Fig. M – Non Humanscale work-surface diagram.
/
Fig. C
Front
3
Fig. A – attaching the foot.
"(3 mm) gap under the screw' s head.
8
Fig. D
Release Paddle
positioning
1"
(25 mm)
2 ¼"
(60 mm)
