/WAN-module
PPP-list
Number-list
Script-list
Manual-dialing
Protect
CB-attempts
Backup-delay-
seconds
Interface-list This table contains the interface settings, which apply to all operating modes (modules)
of the devices.
Ifc Protocol
S0 Auto
Additional, special interface settings are also available for the various modules, e.g. the
call numbers to which a module should react, see also
Setup/WAN-module/Router-interface-list
setup/lancapi-module
Below is a detailed description of the meaning of each field:
Ifc
Protocol
LL-B-chan.
Dial-prefix
WAN settings
Parameter settings for PPP connections
Settings for call numbers with access authorization
Dial script settings
Settings for manual connection control
Protection for answering incoming calls
Number of callback attempts when the remote station is busy
LL-B-chan.
1
Designates the associated interface.
D-channel protocol setting. The possible values are:
Auto: automatic detection of the D-channel protocol
DSS1: Euro-ISDN
1TR6: National ISDN
GRP0: Leased-line connection group 0
P2P-DSS1: Point-to-point connection
B-channel settings for a leased-line connection. The possible values are:
none: Leased-line connection not assigned to a specific channel.
1 or 2: Leased-line connection operates over the assigned B channel.
Please refer to the information on setting these parameters in the fixed connection
description.
Global dialing prefix for all modules of the devices. The digits entered here
(maximum 8) are automatically prefixed to the selected call number in every call. Use
this prefix when, for example, the router is connected to a PBX.
Description of the menu options
Dial-prefix
0
