R70 Description of the menu options

Status/Config-statistics

This menu allows you to display the statistics from the remote configuration area. It
allows you to retrieve information on the number of past and present configuration
sessions at any time. Encryption is performed by LAN, WAN and outband port.
/Config-statistics
LAN-active-connections
LAN-total-connections
WAN-active-connections
WAN-total-connections
Outband-active-connections
Outband-total-connections
Outband-bitrate
Login-errors
Login-locks
Login-rejects
Delete-values

Status/Queue-statistics

These statistics allow you to observe the flow of the individual packets through the
various modules of the ELSA LANCOM.
/Queue-statistics
LAN-heap-packets
LAN-queue-packets
WAN-heap-packets
WAN-queue-packets
Bridge-internal-queue-packets
Bridge-external-queue-packets
ARP-query-queue-packets
ARP-queue-packets
IP-queue-packets
ELSA LANCOM Office
Remote configuration statistics
Current number of active configuration connections from the
LAN
Total number of configuration connections from the LAN up
until the present
Current number of active configuration connections from the
WAN
Total number of configuration connections from the WAN up
until the present
Current number of active outband configuration connections
Total number of previous outband configuration connections
up until the present
Bit rate of the last outband configuration session
Total number of defective logins
Number of login locks
Number of login attempts while the login lock was active
Deletes the config statistics
Statistics on the queue
Number of buffers available
Number of buffers in use
Number of buffers available
Number of buffers in use
Number of bridge packets from the LAN
Number of bridge packets from the WAN
Number of ARP packets in the query queue
Number of ARP packets in the normal queue
Number of IP packets in the normal queue
