ELSA LANCOM Office Manual page 176

R30 Technical basics
– All non-connected networks are propagated with the distance entered in the
– The remaining networks are propagated with a distance of 16 (= unreachable) if
– Remote stations connected using Proxy ARP are an exception to this. These
Mask.
Use the 'Masquerade' option in the routing table to inform the router which IP
addresses to use when transferring the packets.
– 'Off': No masquerading.
– 'On': This entry requests a random IP address valid in the Internet from your
– 'stat.': Use this entry to request the assignment of a specific IP address from your
For further information see the 'IP Masquerading' section.
Following entries have a special meaning:
– IP address 255.255.255.255 with a network mask of 0.0.0.0: This is the default
– Network mask 255.255.255.255: Entries with completed network masks
– Router name 0.0.0.0: Exclusion routes. Data packets for this "zero route" are
Examples with explanatory notes:
IP address
192.168.1.9
192.168.120.0
ELSA LANCOM Office
routing table (but with a minimum distance of 2) as long as a free transmitting
channel is still available.
there are no longer any channels available.
"Proxy hosts" are not propagated at all.
provider which is then used for the connection and masquerading.
provider as entered in the 'TCP/IP' configuration section on the 'General' tab or
in the
/Setup/TCP-IP-module
connection and masquerading.
route. Any data packets which cannot be routed by other routing entries are
transmitted to the remote station listed here.
frequently only identify individual workstation computers (remote access) and
not actual networks. A network which is only visible by a single IP address using
IP masquerading may sometimes be concealed behind this.
rejected and are not routed any further. This is how routes which are forbidden
on the Internet (private address spaces, e.g. 10.0.0.0), for example, are excluded
from transmission.
Netmask
255.255.255.255
255.255.255.0
menu. This address will be used for the
Router Dist. This is what happens:
FIELD SERVICE 2
Router01 2
The FIELD SERVICE remote station
can be reached at IP address
192.168.1.9.
All data packets with destination
IP addresses 192.168.120.x are
transmitted to ROUTER01.
Ver.0:26.08.99/Ver.14:04.04.00
