Status/LCR-statistics

This menu has information on the current time in the device and on the path over which
the ELSA LANCOM Office has obtained the time.
The menu has the following layout:
/LCR-statistics
Total calls
Found-events
Not-found-errors
Missing time-errors
Provider-statistics
Delete values

Status/Delete-values

With the exception of the tables, this option allows you to delete all the values in the
substatistics. To do so, enter the following command:
do delete-values

Setup

This menu allows you to query and modify all the system parameters that are necessary
to the functioning of the devices.
/Setup
Name
WAN-module
Charges-module
LAN-module
IPX-module
TCP-IP-module
IP-router-module
SNMP-module
Description of the menu options
Least-cost router statistics
Total number of LCR calls
Number of calls in which the router found a suitable rule in its
tables and successfully rerouted the connection.
Number of calls in which the router did not find a suitable rule in
its tables and thus could not reroute the connection.
Number of calls in which the LCR could not become active due to
lack of time
A table with all providers used (or their prefixes), the number of
successful and unsuccessful calls
Deletes LCR statistics
System configuration
Entering the device name
WAN settings
Charge management settings
LAN settings
IPX module (IPX router) settings
TCP/IP module settings
IP router module settings
Settings for configuration via SNMP
