Status/TCP-IP-statistics/DNS-statistics
The DNS statistics provide supplementary information about the DNS module. This
menu has the following structure:
LAN-Rx
LAN-Tx
WAN-Rx
WAN-Tx
Forwarded
Errors
DNS-access
DHCP-
access
NetBIOS-
access
Hit-list
Delete
values
The hit list has the following structure:
Domain Requests
www.elsa.com 1
The individual fields of this list have the following significance:
Domain Name of the requested computer
Requests Total number of requests for this name since its appearance in the table
Time Time of the last request
IP-address Address of the computer that last requested this name
This list is sorted according to the frequency of requests. When the table is full, the
names that have not been requested for the longest period will be deleted to make room
for new entries.
Description of the menu options
Number of DNS packets received by the LAN
Number of DNS packets sent on the LAN
Number of DNS packets received by the WAN
Number of DNS packets sent on the WAN
Number of requests that could not be fulfilled and were thus forwar-
ded
Number of invalid requests
Indicates the number of names that were looked up from the DNS
table
Indicates the number of names that were looked up from the DHCP
table
Indicates the number of names that were looked up from the Net-
BIOS tables
This table contains the 16 most popular requests. These may then
be prohibited via the filter list if desired.
Deletes DNS statistics
Time
00.00.0000 00:00:29
IP-address
10.0.0.123
