R46 Description of the menu options

Status/WAN-statistics

This option allows you to display the various statistics parameters for the WAN port. A
large number of values related to the data volume transferred provide you with useful
information on WAN port utilization, errors that have occurred, and the internal resources
of the devices that are available in the current operating state.
The WAN statistics are maintained on an interface-specific basis, i.e. separate statistics
in which the transferred data and errors are recorded are available for each interface.
The Status/WAN-statistics menu has the following layout:
/WAN-statistics
Byte-transport-statistics
Packet-transport-statistics
Error-statistics
WAN-tx-discarded
WAN-heap-packets
WAN-queue-packets
WAN-queue-errors
Throughput-statistics
Delete-values
The menu item Status/WAN-statistics/Byte-transport-statistics contains statistics
Byte-transport-
statistics
of the bytes transferred over an interface for every available interface. The table
maintained here has the following layout:
Ifc
Ch01
Ch02
Below is a detailed description of the meaning of each field:
Ifc
CRx-bytes
Rx-bytes
Tx-bytes
CTx-bytes
ELSA LANCOM Office
Running status displays
Statistics on bytes transferred
Statistics on data packets transferred
Statistics on data errors that have occurred
Number of packets discarded due to an error/lack of
resources
Number of buffers in use
Number of buffers available
Number of packets discarded due to a lack of buffers
Statistics for bytes transferred on every channel
Deletes WAN statistics
CRx-bytes Rx-bytes
0 0
0 0
Designates the associated channel.
Number of bytes received (compressed)
Number of bytes received (uncompressed)
Number of bytes sent (uncompressed)
Number of bytes sent (compressed)
Tx-bytes CTx-bytes
0 0
0 0
