CH1
Name
T x 1
| - 6 0 | - 4 0 | - 2 0 0 |
CH2
Name
T x 2
D
| - 6 0 | - 4 0 | - 2 0 0 |
SD Card
CH2
Status Audio Level
(data
card)
NOTE: If Link Indicator is flashing, this indicates
that the key or compat mode is invalid.
Rio Rancho, NM
CH1
Audio Level
L I N K
L I N K
Plug (or battery)
Icon

Replacing the Batteries

Lift the battery door to unlatch, push slightly forward
and open it.
Observe the battery orientation markings on the side of
the unit.
Channel
Status
indicator
Depress the batteries slightly to allow the door to close,
then press with down firmly while pushing back towards
the DC connector to latch the door closed. The battery
contacts are spring loaded to maintain constant pres-
sure. The door will snap into place for security when it is
fully closed.
Press
down
CAUTION: Be sure to remove batteries as soon
as possible after they are depleted.
Dual Channel Digital Receiver
Slide back to latch
9
