Summary of Contents for Clarke CLS505
- Page 1 505MM CIRCULAR LOG SAW MODEL NO: CLS505 PART NO: 3401999 ASSEMBLY & OPERATING INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1120 - ISS 1...
- Page 2 When unpacking, check for damage or shortages etc. Any found should be reported to your CLARKE dealer where the product was originally purchased. Please keep these instructions in a safe place for future reference.
-
Page 3: Specifications
SPECIFICATIONS Model Number CLS505 Min/max Cutting Length 250 -1000 mm Cutting Capacity (min/max dia) 30 - 170 mm Max Wood Weight 16 kg Operating Voltage 230V / 50Hz Motor Power 3000 W IP Rating IP54 No load blade Speed 2800 rpm... -
Page 4: Safety Warnings
SAFETY WARNINGS WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. DO NOT operate power tools in explosive atmospheres such as in the presence of flammable liquids, gasses or dust. Power tools create sparks which may ignite dust or fumes. - Page 5 3. DO NOT over-reach. Keep your proper footing and balance at all times. This enables better control of the power tool in unexpected situations. 4. Concentrate on the job in hand, no matter how trivial it may seem. Be aware that accidents are caused by carelessness due to familiarity. 5.
-
Page 6: Precautions Specific To Circular Saws
Ensure the blade is secure before use. 2. Use the appropriate saw blade for this saw. Correct blades are available from your CLARKE dealer Part No 3401994. 3. ONLY use saw blades in good working condition. Discard and replace cracked or bent saw blades. -
Page 7: Safety Symbols & Pictograms
SAFETY SYMBOLS & PICTOGRAMS Please read all of the safety and operating instructions carefully before using this product. The following safety symbols are found on the product. Refer to instruction NEVER reach into the manual before use. running saw blade. Wear eye protection Wear a breathing mask Wear ear protection... -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below. - Page 9 INVENTORY Base Frame & Motor Blade Wrench M12 Log Carriage Extension User manual (this document) Wheel Axle Hardware Bag Wheels (x2) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 10 ASSEMBLY This log saw was partially assembled at the factory. To complete your saw follow the instructions below. AXLE Put the axle on the rear of the base frame and align the holes as shown. Secure it with four bolts M8 x 20, washer and nuts on both sides as shown in Fig A.
- Page 11 LOG CARRIAGE EXTENSION Loosen the adjusting wingbolt on the back of the log carriage until the extension can be inserted into the opening. Slide the log carriage extension into the channel and align it correctly, then tighten it with a wing bolt as shown in Fig C.
- Page 12 SET THE LOG RULER Loosen the wing bolt M5 x 20 to allow the log ruler to be pulled out freely. Set the desired length on the scale. Turn it clockwise as shown in step 3 and secure by tightening the wing bolt as shown in Fig E.
-
Page 13: Operation
OPERATION 1. Check that all component parts are secure. If the log saw is not fixed to the floor, ensure that it is placed in a steady position on firm ground. 2. Ensure the power cable is well away from the saw and the workpiece, then plug into the mains supply. -
Page 14: Transporting The Saw
9. ALWAYS control the cradle, keeping both hands on the handles provided. When pushing the logs into the saw, take care that the motor speed does not drop. 10. To stop the saw press the OFF switch. ALWAYS switch off before unplugging and never leave the saw running unattended. - Page 15 2. Secure it with the locking plateas shown in Fig G. 3. Stand behind the unit and tip it towards you for easy transport as shown in Fig H. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 16: Maintenance
If using compressed air always wear goggles and a dust mask. 6. For any problems requiring the dismantling and overhaul of the saw, contact your CLARKE International Service Department on 020-8988-7400. STORAGE 1. Store in a clean, dry environment protected from the weather and away from children and untrained users. - Page 17 2. Ensure the weight of the carriage is supported. 3. Pull the R-clip and washer from the return guide tubeas shown in Fig J. 4. Lower the log carriage towards the ground as shown in Fig K. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 18: Sharpening The Blade
5. Loosen the fixing bolt to release the ring end of the chain for the stop pin. 6. Pull the stop pin out of the baseframe. 7. Insert the lockpin into the hole at the saw blade cover to block the blade from rotating as shown in Fig L. -
Page 19: Fault Finding
ALWAYS keep the original shape of the tooth. Take care not to make sharp notches at the root of the tooth with your file. Check the blade carefully for cracks. NOTE: Replacement blades are available from your CLARKE dealer as Part No 3401994. FAULT FINDING... -
Page 20: Component Parts
COMPONENT PARTS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 21: Parts List
PARTS LIST Description Description Motor Screw M4 x 60 Bolt M8 x 25 Plastic wear strip 3 Flat washer Square wingbolt Log carriage Locknut M8 Log ruler Bolt M8 x 20 Log carriage extension Locking plate Plug for 25 mm section Vibration absorbing washer Plastic wearstrip 2 Bolt M8 x 25... -
Page 22: Environmental Recycling Policy
GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 23: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
