6. Carefully set the cover plate on the workbench. Some wires remain attached to the cover
plate.
7. Disconnect the white wire connector between the halogen lamp assembly and the power
supply.
Wire Connector and Halogen Lamp Assembly
Item
1
2
5032018 C
WARNING! WARNING!
Before touching the area near the lamp, make sure that the lamp has had time
to properly cool to a safe temperature.
Description
Wire Connector
2 Screws on halogen lamp assembly
The halogen lamp can become hot when in use.
Chapter 4: Maintenance
19
