The EMax® Plus Microplate Reader is a filter-based absorbance microplate reader, with
eight standard filters for a wide range of applications. An external computer running the
SoftMax® Pro Microplate Data Acquisition and Analysis Software provides integrated
instrument control, data display, and statistical data analysis.
Setting Up the Instrument
Before setting up the EMax® Plus Microplate Reader, prepare a dry, flat work area that
has sufficient space for the instrument, host computer, and required cables. To provide
access for disconnecting power from the instrument, maintain a 20 cm to 30 cm (7.9 in.
to 11.8 in.) gap between the rear of the instrument and the wall. To ensure sufficient
ventilation, do not block the ventilation grid on the right side of the instrument.
Note: Make sure that the host computer meets or exceeds the system
requirements for the SoftMax Pro Software. See the SoftMax Pro Software
installation guide.
Setting up the instrument includes the following procedures:
Installing the SoftMax Pro Software. See the SoftMax Pro Software installation
guide.
Removing the Shipping Lock From the Microplate Carrier, see page 2
Connecting the Instrument Cables, see page 2
Starting the Instrument and the Software, see page 3
Selecting the Instrument in the Software, see page 4
Contents of the Package
The package contains the instrument and the tools and accessories that are required for
setting up the instrument as follows:
EMax Plus Microplate Reader
EMax Plus Microplate Reader Quick Start Guide
SoftMax Pro Software Product Key
USB computer connection cable
AC power adapter
For a complete list of the contents of the package, see the enclosed packing list.
Downloading the SoftMax Pro Software
Molecular Devices recommends that you install the SoftMax Pro Software on your host
computer before setting up the instrument.
To download the latest version of the software, visit:
www.MolecularDevices.com/SMPdownloadsite
5032019 B
EMax® Plus Microplate Reader
Quick Start Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Molecular Devices EMax Plus
Summary of Contents for Molecular Devices EMax Plus
- Page 1 For a complete list of the contents of the package, see the enclosed packing list. Downloading the SoftMax Pro Software Molecular Devices recommends that you install the SoftMax Pro Software on your host computer before setting up the instrument. To download the latest version of the software, visit: www.MolecularDevices.com/SMPdownloadsite...
- Page 2 EMax® Plus Microplate Reader Quick Start Guide Removing the Shipping Lock From the Microplate Carrier A red metal lock secures the microplate carrier during shipping. This lock must be removed before the instrument can be used. To remove the shipping lock, place one hand on top of the lock, and then use your other hand to carefully pull the bottom of the lock until it comes free of...
- Page 3 SoftMax Pro Software. 4. Start the software. See the SoftMax Pro Software installation guide. Molecular Devices recommends turning the power off when the instrument is not in use. Activating Your Software License When you first start the SoftMax Pro Software, the Software License Activation dialog is displayed.
- Page 4 EMax® Plus Microplate Reader Quick Start Guide Selecting the Instrument in the Software If the instrument is properly connected and turned on, the icon for the instrument is displayed in the Home tab of the SoftMax Pro Software main window, and the correct instrument is shown as selected.
- Page 5 Information in the user guide. The user guide is installed with the SoftMax Pro Software. You can find the user guide in the Windows Start menu at: Start > All Programs > Molecular Devices > SoftMax Pro > Hardware User Guides To view the user guides, use a PDF viewer such as Adobe Reader.
- Page 6 The instrument can read 96-well, clear-bottom microplates and strip wells. For most applications use microplates with flat-bottom or round-bottom wells. Molecular Devices recommends that you do not use V-bottom microplates unless an application specifically requires their use. Irregular plastic density in the tip of the well can cause inaccurate measurements.
- Page 7 EMax® Plus Microplate Reader Quick Start Guide Setting Up an Absorbance Endpoint Experiment You can define the setting for your absorbance endpoint experiment in the SoftMax Pro Software. 1. Turn on the instrument and start the SoftMax Pro Software. See Starting the Instrument and the Software on page 2.
- Page 8 For research use only. Not for use in diagnostic procedures. The trademarks mentioned herein are the property of Molecular Devices, LLC or their respective owners. These trademarks may not be used in any type of promotion or advertising without the prior written permission of Molecular Devices, LLC.
