Invertek Drives Optidrive Plus 3GV Compact User Manual page 15

Par. Description
P2-19 Keypad Restart Mode
P2-20 Standby Mode
P2-21 Display Scaling Factor
P2-22 Display Scaling Source
Effective Switching
P2-24
Frequency
nd
2 Deceleration Ramp
P2-25
time
Communication Baud
P2-26
Rate
Drive Communication
P2-27
Address
Master / Slave Mode
P2-28
Select
Digital / Slave speed
P2-29
reference scaling factor
P2-30 Analog Input 1 format
P2-31 Analog Input 1 scaling
P2-32 Analog Input 1 offset
P2-33 Analog Input 2 format
P2-34 Analog Input 2 scaling
GV
Optidrive Plus 3
Range
0 : Minimum Speed, Edge-r
1 : Previous Speed, Edge-r
2 : Minimum Speed, Auto-r
3: Previous Speed, Auto-r
0.0 : Disabled
0.1 to 60
0.000 to 30.000
nd
0 : 2 Analog Input
1 : Motor Speed
2 : Motor Torque
3 : Motor Current
4 to 16 / 24 / 32
Drive Power Rating
Dependent
0.0 to 30.0
0 : Automatic
0: Disabled
1 to 63
0 : Slave Mode
1 : Master Mode
0 to 500.0
U U U U 0- 0-24 24
0- 0- 24 24 = 0 - 24V DC
U U U U 0-10 0-10 0-10 0-10
= 0 - 10V DC
0 to 500.0
-500.0 to 500.0
D D D D 0- 0-24 0- 0- 24 24 24
= Digital
U U U U 0-10 0-10 0-10 0-10 =
0 to 10V DC
=
A A A A 4 4 4 4 - - - - 2 2 2 2 0 0 0 0
4 to 20mA
A A A A 0- 0-2 2 2 2 0 0 0 0 =
0- 0-
0 to 20mA
0 to 500.0
www.invertek.co.uk
Compact - User Guide
Units Default Explanation
Active when P1-12 = 1 or 2
0 : Following a stop and restart, the drive will
run at minimum speed
1 : Following a stop and restart, the drive will
run at the last setpoint speed
2 : As per setting 0, except that the Run
- 0 command will be determined by the status of
Digital Input 1, and the user is not required to
press the keypad start button
3 : As per setting 1, except that the Run
command will be determined by the status of
Digital Input 1, and the user is not required to
press the keypad start button
When P2-20 >0, the drive enters standby mode
seconds 0.0 if the minimum speed is maintained for the
time period set in P2-20
- 0.000
Disabled if P2-21 is set to 0.
If P2-21 is set >0, the variable selected in P2-22
- 0 is multiplied by the factor entered in P2-21, and
displayed whilst the drive is running
Effective power stage switching frequency.
16 Higher frequencies reduce the audible 'ringing'
kHz 8 noise from the motor, and improve the output
4 current waveform, at the expense of increased
drive losses
Deceleration 2
Selected Automatically on mains power loss if
P1-05 = 2
Can also be selected by digital inputs,
seconds 0.0
dependent on P2-01 setting.
When set to 0, the drive decelerates as quickly
as possible, whilst preventing an overvoltage
trip
Factory set serial data link communication Baud
- 0
Rate
Sets the communication address for the drive
- 1
when connected on an Optibus Network
When in Master Mode, the drive transmits its
operational status via the serial data link. All
- 0 drives on the data link must have unique
addresses. Only one drive can be programmed
as a Master
Scaling factor applied to any speed reference
on the serial data link, e.g. in Master / Slave
% 100.0 operation, a Slave drive will apply this scaling
factor to the transmitted Master speed
reference
Configures the analog input signal to match the
reference connected to terminal 6. Only
- V V V V 0- 0-24 24 voltage signals can be directly connected, mA
0- 0- 24 24
reference signals require an external resistor
connection.
Scales the analog input by this factor, e.g. if P2-
30 is set for 0 – 10V, and the scaling factor is
% 100.0
set to 200.0%, a 5 volt input will result in the
drive running at maximum speed (P1-01)
Sets an offset, as a percentage of the full scale
% 0.0 range of the input, which is applied to the
analog input signal
Selects the format for the 2
-
D D D D 0- 0-24 24 Selecting
0- 0- 24 24
input
Scales the 2
% 100.0
this parameter
nd
ramp down time
nd
analog input
d 0-24 d 0-24 sets the input up as a digital
d 0-24 d 0-24
nd
analog input by the factor set in
15
