Install the Access Point Using the WALL04 Bracket

Install the Access Point Using the WALL04 Bracket
About This Task
The optional WALL04 (#30516) bracket is used for wall installations, and ships with two Phillips pan
head screws and two screw-in anchors. You must purchase the bracket separately.
Note
The locking tab on the WS-MBI-WALL04 bracket must be on the top side during installation.
Procedure
1. Using the WALL04 bracket as a template, mark and drill two holes on a wall.
2. Attach the WS-MBI-WALL04 bracket on a wall using two Phillips pan head screws.
3. Connect the GE1 cable to the access point.
4. Insert the access point into the WALL04 bracket keyhole posts and slide it into place.
5. Lock the access point at approximately 1/4

Install the Access Point Using the Main Mounting Bracket and Easy-Attach Adapter

About This Task
Use the flat metal easy-attach adapter (#37210) in combination with the main mounting bracket
(#37201) when you do not want to use the screw holes on the main mounting bracket. The easy-attach
adapter extends past the access point housing, thereby making it convenient to easily attach and
remove the access point from a flat surface.
18 ExtremeWireless™ Access Points AP410i/e
Tip
The best practice is to use the "A" and "B" hole templates on the WALL04 bracket to mark
the attachment holes.
Note
When using the "A" or "B" hole template, if the holes are not near the corners of the
bracket, you can break off the corner to minimize the amount of bracket that is visible
behind the access point.
Tip
The best practice is to install the screw-in anchors before attaching the pan head screws
during drywall installations.
th
in. from the bracket.
Install the Access Point
