Model 1305 MultiVolume Pycnometer
The Multivolume Pycnometer 1305 permits the rapid determination of sample vol-
umes. This chapter provides information and instructions to assist you in obtain-
ing maximum accuracy and productivity in running samples, calculating results,
and ensuring accurate calibration of the instrument.
Controls and Components
Before operating the Model 1305 Pycnometer, you should become familiar with
its controls and components. All operating controls for the Model 1305 Pycnome-
ter are on the front panel (shown in the following illustration). The gas, vacuum,
and power connections are located on the right side panel.

Controls

ON/OFF switch
Jun 99
OPERATION
Provides electrical power to the analyzer. Lighting of
the numbers on the pressure display indicates that AC
power is present.
