Micromeritics 1305 Operator's Manual page 20

Model 1305 MultiVolume Pycnometer
The fuses used in the pycnometer must be identical in type and rating to
that specified. Use of other fuses could result in electrical shock and/or
damage to the pycnometer.
c. Insert appropriate fuse(s) for the input power source. Refer to the chart
7. Insert fuse block and cover assembly into input power connector and snap it
into place. Once the fuse block and cover assembly are in place, the position
of the indicator pin shows the input power selected.
Jun 99
below for the appropriate fuse rating.
Power Source
100-120 VAC 0.50 Amp, 3AG, Slow Blow
220-240 VAC 0.25 Amp, 5 x 20 mm Slow Blow, Type T
Figure 2-6. Inserting Fuse Block and Cover Assembly
Selecting the Voltage
Fuse
2-5
