Front Panel
xx1500000809
1
2
3
4
5
6
7
8
9
10
11
12
13
Continues on next page
16
USB Connection A (Host)
Voltage/Arc Adjust Display Meter
Program Display
Program # Select
Power Switch
Process Setup Button
Control Knob
Wire Speed/Amperage Display Meter
Purge Pushbutton
Jog Forward Pushbutton
Jog Retract Pushbutton
Wire Feed/Amperage Select
Arc Control
