- Page 1 TOWER UNIT 84”, 90” & 96” Walk in Assembly Guide 96” x 24” 90” x 24” 84” x 24” 70/30 Door 1 Door Page 1 For Internal Use: CON.INS.005.001_50-WKIN0009_WalkIn_TowerGuide_Rev4.indd...
- Page 2 TOWER UNIT BEFORE YOU START INSTALLATION 84”, 90” & 96” SHOULD BE Walk in PERFORMED BY A COMPETENT Assembly Guide PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED 1Dr OPTION 70/30 OPTION Panel sE Panel D Panel sM Frontals Toe Kick Panel eA...
- Page 3 TOWER UNIT 84”, 90” & 96” Step 1. Walk in Seat cam dowel (Cc) into holes in end panel (eA) as Assembly Guide shown. Seat (Cc) cam dowel into hole as Step 2. shown. Seat dowel (Aa) into holes in end panel (eA) as shown.
- Page 4 TOWER UNIT 84”, 90” & 96” Walk in Assembly Guide Step 5. Seat 10x dowels (Aa) into holes in both panels (sM) and (sE) as shown. Step 6. Slide back panel (C) into groove of end panel (eA). Also insert dowels (Aa) (in orange) from panels (sM) and (sE) into the required holes in back panel (C).
- Page 5 TOWER UNIT Step 10. 84”, 90” & 96” Seat dowel (Aa) into holes in end panel (eB) as shown. Walk in Assembly Guide Seat (Cc) cam dowel Step 11. into hole as Seat cam dowel (Cc) into shown. holes in end panel (eB) as shown.
- Page 6 TOWER UNIT Step 14. Seat 10x dowels (Aa) into holes 84”, 90” & 96” in both panels (sM) and (sE) Walk in as shown. Assembly Guide Step 15. Secure back panel (D) to panels (sM) and (sE) and back panel (C). Use 20 x 1 ”...
- Page 7 TOWER UNIT Step 17. Secure back panel (D) to end panel (eB) at the 84”, 90” & 96” bottom. Use 4 x screws (B) to 1 x L bracket LGE ” Walk in , as shown. Assembly Guide Step 18. Hand tighten all the remaining cam locks (Dd), this will expand cam dowels...
- Page 8 TOWER UNIT Step 20. Attach hinge plates onto end panel (eA) or (eB) to 84”, 90” & 96” siut as shown. Walk in Hinge side to be mounted in accordance to Assembly Guide customer kitchen plan. 84” 84” 70/30 1 DOOR HINGE HINGE POSITION...
- Page 9 TOWER UNIT Step 20. Attach hinge plates onto end panel (eA) or (eB) to 84”, 90” & 96” siut as shoown. Walk in Hinge side to be mounted in accordance to Assembly Guide customer kitchen plan. 90” 90” 70/30 DOOR 1 DOOR HINGE HINGE...
- Page 10 TOWER UNIT Step 20. Attach hinge plates onto end panels (eA) or (eB) 84”, 90” & 96” o siut as shown. Walk in Hinge side to be mounted in accordance to customer kitchen plan. Assembly Guide 96” 96” 1 DOOR 70/30 DOOR HINGE HINGE...
- Page 11 TOWER UNIT TOWER UNIT See Customer Specific Kitchen Plan Step 21. Insert hinge where required 84”, 90” & 96” 84”, 90” & 96” in holes as shown. Walk in Walk in Assembly Guide Assembly Guide Step 23. Step 22. Secure hinges by tightening Align doors to join together 2 x screws with hinge dowels using 2 x fixing plates (Ff)
- Page 12 TOWER UNIT 84”, 90” & 96” Walk in Assembly Guide Page 11 For Internal Use: CON.INS.005.001_50-WKIN0009_WalkIn_TowerGuide_Rev4.indd...
