Chore-Time Turbo-Cool Installation & Operator's Instruction Manual page 10

Turbo-Cool 6" Recirculating Evaporative Cooling System Manual
The next Trough Support (at the sump end) must be positioned in 10" (25 cm).
See Figure 4.
Space the remaining Trough Supports 20" (50 cm) apart.
The chalk line provides the proper vertical location of the lag screws.
2. Loosely secure the Trough Hangers, Trough Supports, and plastic washers to
the lower stringer, as shown in Figure 4, using the 5/16 x 1-1/2" stainless steel
lag screws.
Note: Leave the Trough Supports loose to allow the Trough to be installed. See
Figure 5, Step 1.
3. The Trough should extend out past the last Trough Support at the Sump
Assembly end at least 5" (12.7 cm)
The Trough should extend out past the last Trough Support at the inlet end at
least 1" (2.5 cm).
The Trough will be cut to length after the End Assembly is installed.
Roll the Trough out flat on the floor below the Trough Hangers.
4. Beginning at one end, slide one side of the Trough between the stringer and the
Trough Support. Make sure the Trough edge is up against the washer. See
Figure 5, Step 1.
10
Figure 4. Trough Support and Hanger Installation
Item Description
1 Chalk Line
2 5/16 x 1-1/2" S.S. Lag Screw
3 Nylon Washer
4 Bottom Stringer
5 Hanger
Item Description
6 Trough Support (Left End)
7 Flush with edge of end framing
8 Trough Support (Right End)
9 10" (25 cm)
10 20" (50 cm)
