  • Page 1 USER MANUAL...
  • Page 2 TABLE OF CONTENTS INTRODUCTION ..........................10 GETTING TO KNOW YOUR VEHICLE ................. 19 GETTING TO KNOW YOUR INSTRUMENT PANEL ............87 STARTING AND OPERATING ....................132 MULTIMEDIA ..........................199 SAFETY ............................223 IN CASE OF EMERGENCY ....................285...
  • Page 3 SERVICING AND MAINTENANCE ..................323 TECHNICAL SPECIFICATIONS .................... 377 CUSTOMER ASSISTANCE .....................388 INDEX ............................405...

  • Page 4: Table Of Contents

    INTRODUCTION DOORS..............28 UCONNECT VOICE RECOGNITION — Manual Door Locks........28 IF EQUIPPED............44 IMPORTANT NOTICE..........11 Power Door Locks........30 Introducing Uconnect ........44 Symbols Key............12 Keyless Enter-N-Go — Passive Entry... 30 Basic Voice Commands ......45 ROLLOVER WARNING .........12 Automatic Unlock Doors On Exit ....33 Get Started...........
  • Page 5 GETTING TO KNOW YOUR Lane Change Assist — If Equipped .... 52 WINDOWS ............72 Headlight Leveling System — If Equipped .. 52 Power Window Controls ......72 INSTRUMENT PANEL Battery Saver Feature........53 Automatic Window Features ...... 73 BASE / MIDLINE INSTRUMENT CLUSTER..87 INTERIOR LIGHTS ..........53 Reset Auto-Up ..........
  • Page 6 Stopping The Engine .........136 IF EQUIPPED............164 Message — Electrical Load Reduction Normal Starting — Diesel Engine....136 Jeep Active Drive ........164 Actions — If Equipped .......116 ENGINE BREAK-IN RECOMMENDATIONS ..139 SELEC-TERRAIN — IF EQUIPPED...... 166 WARNING LIGHTS AND MESSAGES ....117 ELECTRIC PARK BRAKE (EPB) ......139...
  • Page 7 SAFETY PARKSENSE REAR PARK ASSIST SYSTEM — RECREATIONAL TOWING (BEHIND IF EQUIPPED ............174 MOTORHOME) ...........194 SAFETY FEATURES ..........223 ParkSense Sensors ........174 Towing This Vehicle Behind Another Anti-Lock Brake System (ABS) ....223 ParkSense Warning Display ......174 Vehicle ............194 Drowsy Driver Detection (DDD) —...
  • Page 8 IN CASE OF EMERGENCY Emergency Tow Hooks — If Equipped ..319 Cooling System .......... 335 Tow Eye Usage — If Equipped ....320 Brake System ..........339 HAZARD WARNING FLASHERS ....... 285 ENHANCED ACCIDENT RESPONSE SYSTEM Manual Transmission — If Equipped ..340 SOS/ASSIST/HELP MIRROR —...
  • Page 9 TECHNICAL SPECIFICATIONS CUSTOMER ASSISTANCE FRANCE ............394 GERMANY...........394 VEHICLE IDENTIFICATION NUMBER (VIN)..377 IF YOU NEED ASSISTANCE .......388 GREECE ............395 BRAKE SYSTEM ..........378 ARGENTINA ..........389 GUATEMALA ..........395 AUSTRALIA..........389 WHEEL AND TIRE TORQUE HONDURAS ..........395 AUSTRIA............389 SPECIFICATIONS..........378 HUNGARY ...........395 BALANCE OF THE CARIBBEAN ....389 Torque Specifications........378...
  • Page 10 ROMANIA ............400 SOUTH AFRICA ...........401 TURKEY ............403 RUSSIA............400 SPAIN............402 UKRAINE.............403 SERBIA............400 SWEDEN .............402 UNITED KINGDOM ........404 SLOVAKIA ...........401 SWITZERLAND..........403 URUGUAY ...........404 SLOVENIA ...........401 TAIWAN ............403 VENEZUELA ..........404...
  • Page 11 Dear Customer, Congratulations on the purchase of your new Jeep® vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.

  • Page 12: Important Notice

    IMPORTANT NOTICE part in an officially approved design), or if an individual operating permit was issued for the vehicle after the attachment or installation of such ALL MATERIAL CONTAINED IN THIS PUBLICATION IS BASED ON THE parts, it cannot be implicitly assumed that the driving safety of your LATEST INFORMATION AVAILABLE AT THE TIME OF PUBLICATION vehicle is unimpaired.

  • Page 13: Symbols Key

    SYMBOLS KEY If you do not read this entire Owner’s Manual, you may miss important information. Observe all Cautions and Warnings. These statements are against operating ROLLOVER WARNING WARNING! procedures that could result in a collision, bodily injury and/or death. Utility vehicles have a significantly higher rollover rate than other types of These statements are against procedures that vehicles.

  • Page 14: Vehicle Modifications/Alterations

    SYMBOL GLOSSARY Some car components have colored labels with symbols indicating precautions to be observed when using this component. It is important to follow all warnings when operating your vehicle. See below for the definition of each symbol Ú page 98. Red Warning Lights Air Bag Warning Light Rollover Warning Label...
  • Page 15 Red Warning Lights Red Warning Lights Drowsiness Detected Warning — If Equipped Oil Pressure Warning Light Ú page 119 Ú page 120 Electric Power Steering (EPS) Fault Warning Oil Temperature Warning Light Light Ú page 120 Ú page 119 Seat Belt Reminder Warning Light Electronic Throttle Control (ETC) Warning Light Ú...
  • Page 16 Yellow Warning Lights Yellow Warning Lights Anti-Lock Brake System (ABS) Warning Light Low Fuel Warning Light Ú page 122 Ú page 123 Electronic Park Brake Warning Light Low Washer Fluid Warning Light — If Equipped Ú page 122 Ú page 123 Electronic Stability Control (ESC) Active Warning Engine Check/Malfunction Indicator (MIL) Light —...
  • Page 17 Yellow Warning Lights Yellow Indicator Lights Tire Pressure Monitoring System (TPMS) Diesel Particulate Filter (DPF) Cleaning In Warning Light — If Equipped Progress Indicator Light — Diesel Versions With DPF Only —If Equipped Ú page 124 Ú page 126 Towing Hook Breakdown Warning Light — If Equipped Low Diesel Emissions Additive AdBlue®...
  • Page 18 Green Indicator Lights Green Indicator Lights Active Speed Limiter SET Indicator Light With A Cruise Control SET Indicator Light — If Equipped Premium Instrument Cluster — If Equipped With A Premium Instrument Cluster Ú page 128 Ú page 129 Active Lane Management Indicator Light — If Cruise Control SET Indicator Light With A Equipped Premium Instrument Cluster —...
  • Page 19 Blue Indicator Lights White Indicator Lights Hill Descent Control (HDC) Indicator Light — If High Beam Indicator Light Equipped Ú page 130 Ú page 129 Cruise Control Ready Indicator Light With A Premium Instrument Cluster — If Equipped Gray Indicator Lights Ú...

  • Page 20: Getting To Know Your Vehicle

    GETTING TO KNOW YOUR VEHICLE KEYS The keyless ignition key fob supports Passive The key fob allows you to lock or unlock the Entry, Remote Keyless Entry (RKE), Keyless doors and liftgate from distances up to Enter-N-Go (if equipped), and remote power approximately 66 ft (20 m).
  • Page 21 GETTING TO KNOW YOUR VEHICLE NOTE: 1 — Unlock Button 2 — Liftgate Button The key fob’s wireless signal may be blocked  3 — Emergency Key if the key fob is located next to a mobile phone, laptop, or other electronic device. 4 —...
  • Page 22 GETTING TO KNOW YOUR VEHICLE To Unlock/Lock The Doors And Liftgate 1 — Mechanical Key Release Push and release the unlock button on the key 2 — Unlock Button fob once to unlock the driver’s door, or twice 3 — Lock Button within five seconds to unlock all the doors and the liftgate.
  • Page 23 GETTING TO KNOW YOUR VEHICLE NOTE: Customers are recommended to use a  battery obtained from Mopar®. Aftermarket coin battery dimensions may not meet the original OEM coin battery dimensions. Perchlorate Material — special handling may  apply. Do not touch the battery terminals that are ...
  • Page 24 GETTING TO KNOW YOUR VEHICLE 3. Remove the back cover to access and replace the battery. When replacing the battery, match the (+) sign on the battery to the (+) sign on the inside of the battery clip, located on the back cover. Avoid touching the new battery with your fingers.

  • Page 25: Sentry Key

    GETTING TO KNOW YOUR VEHICLE SENTRY KEY WARNING! WARNING! (Continued) The Sentry Key Immobilizer system prevents Always remove the key fobs from the Keep new and used batteries away from   unauthorized vehicle operation by disabling the vehicle and lock all doors when leaving the children.

  • Page 26: Ignition Switch

    GETTING TO KNOW YOUR VEHICLE attempted to start the engine with an invalid key All of the key fobs provided with your new fob. Either of these conditions will result in the vehicle have been programmed to the vehicle engine being shut off after two seconds. electronics.
  • Page 27 GETTING TO KNOW YOUR VEHICLE ON/RUN WARNING! (Continued) Driving mode.  Never leave children alone in a vehicle, or  All the electrical devices are available (e.g. with access to an unlocked vehicle.  climate controls, etc.). Allowing children to be in a vehicle unat- ...

  • Page 28: Integrated/Manual Ignition

    GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! (Continued) For information on normal starting, see  Do not leave children or animals inside  Ú page 132. parked vehicles in hot weather. Interior heat build-up may cause serious injury or When opening the driver's door and the igni- ...

  • Page 29: If Equipped

    GETTING TO KNOW YOUR VEHICLE The steering column can be locked (with the ignition in the OFF position. In addition to the engine and remove the key. Turn the steering  ignition key removed). chime, the “Vehicle On” message will display in wheel slightly in either direction until the lock the cluster.
  • Page 30 GETTING TO KNOW YOUR VEHICLE To lock each door, rotate the door lock knob on WARNING! WARNING! (Continued) each door trim panel forward until the lock indicator is shown. To unlock the front doors, For personal security and safety in the Never leave children alone in a vehicle, or ...

  • Page 31: Power Door Locks

    GETTING TO KNOW YOUR VEHICLE driver door is open, and the ignition is in the wireless signal and prevent the Passive Entry OWER OCKS system from locking and unlocking the RUN position, a chime will sound as a reminder A power door lock switch is located on each of to remove the key.
  • Page 32 GETTING TO KNOW YOUR VEHICLE Frequency Operated Button Integrated Key inside the vehicle and it does not find any (FOBIK-Safe) Passive Entry key fobs outside the vehicle, then the vehicle will unlock and alert the customer. To minimize the possibility of unintentionally locking a Passive Entry key fob inside your NOTE: vehicle, the Passive Entry system is equipped...
  • Page 33 GETTING TO KNOW YOUR VEHICLE To Lock The Vehicle’s Doors And Liftgate Integrated Key (FOBIK-Safe)" remains active/ functional. With one of the vehicle’s Passive Entry key fobs within 5 ft (1.5 m) of either front door handle, The Passive Entry system will not operate if ...

  • Page 34: Automatic Unlock Doors On Exit

    GETTING TO KNOW YOUR VEHICLE The liftgate (and vehicle doors if unlocked) The liftgate Passive Entry lock button will lock all To use the system, open each rear door, use a  must be locked using the lock button on the doors and the liftgate.

  • Page 35: Steering Wheel

    GETTING TO KNOW YOUR VEHICLE STEERING WHEEL NOTE: WARNING! When the Child-Protection Door Lock system  Avoid trapping anyone in a vehicle in a ELESCOPING TEERING OLUMN is engaged, the door can be opened only by collision. Remember that the rear doors can using the outside door handle even though This feature allows you to tilt the steering only be opened from the outside when the...

  • Page 36: Driver Memory Settings - If Equipped

    GETTING TO KNOW YOUR VEHICLE To unlock the steering column, push the control desired position settings for the following handle downward (toward the floor). To tilt the features: steering column, move the steering wheel Driver seat position  upward or downward as desired. To lengthen or Easy Entry/Exit seat operation (on/off) (if shorten the steering column, pull the steering ...

  • Page 37: Linking And Unlinking The Remote Keyless

    GETTING TO KNOW YOUR VEHICLE 2. Adjust all memory profile settings to desired NOTE: by pushing the unlock button on the key fob preferences (i.e., seat and radio station Before programming your key fob you must within 10 seconds. presets). select the “Memory Linked To FOB”...

  • Page 38: Seats

    GETTING TO KNOW YOUR VEHICLE SEATS While sitting in the seat, lift up on the bar and ANUAL DJUSTMENT RONT EATS move the seat forward or rearward. Release the — I QUIPPED Seats are a part of the Occupant Restraint bar once you have reached the desired position.

  • Page 39: Equipped

    GETTING TO KNOW YOUR VEHICLE Manual Seat Height Adjustment — If the seatback, lift the lever, lean forward and Fold-Forward Front Passenger Seat — If release the lever. Equipped Equipped The driver’s seat height can be raised or This feature allows for extended cargo space. lowered by using a lever, located on the When the seat is folded flat, it is an extension of outboard side of the seat.

  • Page 40: Manual Adjustment (Rear Seats)

    GETTING TO KNOW YOUR VEHICLE NOTE: To Lower The Rear Seat WARNING! Prior to folding the rear seat, it may be neces- 1. Pull the seatback release lever located on Adjusting a seat while the vehicle is moving is sary to position the front seat to its mid-track either side of the upper outer edge of the dangerous.

  • Page 41: Power Adjustment (Front Seats)

    GETTING TO KNOW YOUR VEHICLE ) — To Raise The Rear Seat Forward Or Rearward Adjustment OWER DJUSTMENT RONT EATS QUIPPED The seat can be adjusted both forward and NOTE: rearward. Push the seat switch forward or If interference from the cargo area prevents the Some models may be equipped with a power rearward, the seat will move in the direction of seatback from fully locking, you will have diffi-...
  • Page 42 GETTING TO KNOW YOUR VEHICLE Reclining The Seatback Forward Or WARNING! Rearward Do not ride with the seatback reclined so that The seatback can be reclined both forward and the shoulder belt is no longer resting against rearward. Push the seat recliner switch forward your chest.

  • Page 43: Front Ventilated Seats - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I seat position is greater than or equal to NOTE: RONT ENTILATED EATS 2.7 inches (67.7 mm) forward of the rear The engine must be running for the ventilated QUIPPED stop. The seat will return to its previously set seats to operate.

  • Page 44: Head Restraints

    GETTING TO KNOW YOUR VEHICLE Front Head Restraint Adjustment WARNING! WARNING! Your vehicle is equipped with front two way Be certain that the seatback is securely All occupants, including the driver, should  driver and passenger head restraints. not operate a vehicle or sit in a vehicle’s locked into position.

  • Page 45: Uconnect Voice Recognition - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: Rear Head Restraints NOTE: The head restraints should only be removed by The head restraints should only be removed by The rear head restraints have two positions: up qualified technicians, for service purposes only. qualified technicians, for service purposes only.

  • Page 46: Basic Voice Commands

    Or Receive A Text, Or Begin Radio, Media, Up” words include “Hey Uconnect” or “Hey again Navigation, And Climate Functions Jeep®”. 2 — Push To Access Home Screen On Notice the visual cues that inform you of your A passenger can press the VR button ...

  • Page 47: Mirrors

    GETTING TO KNOW YOUR VEHICLE MIRRORS This mirror automatically adjusts for headlight glare from vehicles behind you. NSIDE EARVIEW IRROR NOTE: Manual Mirror — If Equipped The Automatic Dimming Mirror feature is disabled when the vehicle is in REVERSE to This is a single ball joint mirror that fixes to the improve the driver’s rear view.

  • Page 48: Illuminated Vanity Mirrors - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I Sun Visor “Slide-On-Rod” Feature — If LLUMINATED ANITY IRRORS Equipped QUIPPED The sun visor “Slide-On-Rod” feature allows for To access an illuminated vanity mirror, flip down additional flexibility in positioning the sun visor one of the visors and lift the mirror cover.

  • Page 49: Outside Mirrors

    GETTING TO KNOW YOUR VEHICLE UTSIDE IRRORS OWER DJUSTMENT IRRORS 1 — Neutral Position 2 — Left Mirror The outside mirror(s) can be adjusted to the The power mirror control switch is located on 3 — Control Switch center of the adjacent lane of traffic to achieve the driver's side door trim panel.

  • Page 50: Folding Mirrors

    GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Power mirror position can be saved as part of operation of headlights, automatic headlights the Driver Memory Settings (if equipped) (if equipped), front and rear fog lights (if Ú page 35. equipped), as well as headlight leveling (if ULTIFUNCTION EVER equipped).

  • Page 51: Daytime Running Lights (Drls) - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I Rotate the headlight switch clockwise to the On some vehicles, the Daytime Running  UTOMATIC EADLIGHTS QUIPPED Lights may deactivate, or reduce intensity, on first detent for parking light and instrument This system automatically turns the headlights one side of the vehicle (when a turn signal is panel light operation.

  • Page 52: Lights-On Reminder - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I To activate the delay feature, place the ignition in IGHTS EMINDER QUIPPED the OFF position while the headlights are still on. If the headlights or parking lights are on after Then, turn off the headlights within 45 seconds. the ignition is in the OFF position, a chime will The delay interval begins when the headlight sound to alert the driver when the driver's door...

  • Page 53: Turn Signals

    GETTING TO KNOW YOUR VEHICLE — I To activate the rear fog lights, push the lower NOTE: EADLIGHT EVELING YSTEM half of the headlight switch. To turn off the rear QUIPPED If either light remains on and does not flash, ...

  • Page 54: Battery Saver Feature

    GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS To operate, rotate the control switch until the Driver, plus an evenly appropriate number, which corresponds to the distributed load in the load listed on the chart, aligns with the indicator NTERIOR OURTESY IGHTS luggage line on the switch.

  • Page 55: Windshield Wipers And Washers

    GETTING TO KNOW YOUR VEHICLE To protect the battery, the interior lights will turn located on the end of the lever. For information off automatically 15 minutes after the ignition is on the rear wiper/washer, see Ú page 56. placed in the OFF position. This will occur if the interior lights were turned on manually or are on because a door is open.
  • Page 56 GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! Do not operate the windshield wipers with the blades lifted from the windshield. Sudden loss of visibility through the windshield could lead to a collision. You might Windshield Washer Operation not see other vehicles or other obstacles. To To use the washer, pull the lever toward you and avoid sudden icing of the windshield during hold while spray is desired.

  • Page 57: Rain Sensing Wipers - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I Use of Rain-X or products containing wax or switch is moved or the gear selector is moved ENSING IPERS QUIPPED  silicone may reduce Rain Sensing perfor- out of NEUTRAL. This feature senses rain or snow fall on the mance.

  • Page 58: Climate Controls

    GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS The rear wiper/washer controls are located on To use the washer, push the lever the windshield wiper/washer lever on the right forward and hold while spray is The Climate Control system allows you to side of the steering column.
  • Page 59 GETTING TO KNOW YOUR VEHICLE MAX A/C sets the control for maximum cooling gentle water spray from the front of the radiator performance. and through the condenser. If the problem persists, please contact an authorized dealer. NOTE: Recirculation Button The MAX A/C button is only available on the touchscreen.
  • Page 60 GETTING TO KNOW YOUR VEHICLE window fogging may occur. Extended use of this amount of airflow. Toggling this function will Rear Defrost Button mode is not recommended. cause the system to switch between manual Press and release the button on the override and automatic modes Ú...
  • Page 61 GETTING TO KNOW YOUR VEHICLE arrow button on the touchscreen for cooler be selected using either the blower control knob CAUTION! (Continued) temperature settings. on the faceplate or the buttons on the touchscreen. Do not use scrapers, sharp instruments, or ...

  • Page 62: Manual Climate Controls Descriptions

    GETTING TO KNOW YOUR VEHICLE Faceplate amount of air is directed through the defrost Climate Control OFF Button and side window demister outlets. Push the Mode button to changes the airflow Press and release this button to turn distribution mode. the Climate Control on/off.
  • Page 63 GETTING TO KNOW YOUR VEHICLE MAX A/C Setting If your air conditioning performance seems stuffy and window fogging may occur. Extended  lower than expected, check the front of the use of this mode is not recommended. Set the temperature control knob to A/C condenser (located in front of the radi- the MAX A/C setting to change the On systems with Manual Climate Controls, if...
  • Page 64 GETTING TO KNOW YOUR VEHICLE automatic climate controls to change to manual Temperature Control CAUTION! mode. The blower speed increases to full (all Temperature Control regulates the temperature LEDs on) when MAX Defrost mode is selected, Failure to follow these cautions can cause of the air forced through the climate system.

  • Page 65: Automatic Temperature Control (Atc)

    GETTING TO KNOW YOUR VEHICLE Mode Control amount of air is directed through the defrost Climate Control OFF and side window demister outlets. Turn the mode control knob to adjust To turn the Climate Controls off, turn airflow distribution. The airflow the blower control knob to the O (off) NOTE: distribution can be adjusted so air...

  • Page 66: Climate Voice Commands

    GETTING TO KNOW YOUR VEHICLE 3. When the system is set up for your comfort Manual Operation Override PERATING level, it is not necessary to change the This system offers a full complement of manual NOTE: settings. You experience the greatest override features.
  • Page 67 GETTING TO KNOW YOUR VEHICLE Vacation/Storage air distribution box, they could plug the water Operating Tips Chart drains. In Winter months, make sure the air For information on maintaining the Climate WEATHER CONTROL SETTINGS intake is clear of ice, slush, and snow. Control system when the vehicle is being stored Set the mode control for an extended period of time, see...

  • Page 68: Interior Storage And Equipment

    GETTING TO KNOW YOUR VEHICLE Door Storage WEATHER CONTROL SETTINGS Front Door Storage Set the mode control Storage areas are located in the door trim to (Floor Mode) Cool & Humid panels. and turn on (A/C) Conditions to keep windows Rear Door Storage clear.

  • Page 69: Usb Control

    GETTING TO KNOW YOUR VEHICLE The center console has a storage area which Push the seat cushion downward after closing it Plugging in a smartphone device to a USB port can hold cell phones, PDAs, and other small to make sure it latches to the base. may activate Android Auto™...

  • Page 70: Power Outlets

    GETTING TO KNOW YOUR VEHICLE OWER UTLETS Your vehicle is equipped with 12 Volt (13 Amp) power outlets that can be used to power cellular phones, small electronics and other low powered electrical accessories. The power outlets are labeled with either a “key” or a “battery”...
  • Page 71 GETTING TO KNOW YOUR VEHICLE CAUTION! WARNING! CAUTION! (Continued) Power outlets are designed for accessory To avoid serious injury or death: Accessories that draw higher power (i.e.,  plugs only. Do not insert any other object in coolers, vacuum cleaners, lights, etc.) will Only devices designed for use in this type of ...

  • Page 72: Wireless Charging Pad - If Equipped

    GETTING TO KNOW YOUR VEHICLE — I Your mobile phone must be designed for Qi NOTE: IRELESS HARGING wireless charging. If the phone is not equipped QUIPPED The wireless charging pad will not work if any  with Qi wireless charging functionality, an of the four doors are open, even if the engine aftermarket sleeve or a specialized back plate is running.

  • Page 73: Windows

    GETTING TO KNOW YOUR VEHICLE WINDOWS The passenger door windows can also be WARNING! operated by using the single window switches on the passenger door trim panel. The window Never leave children unattended in a vehicle. OWER INDOW ONTROLS switches will operate only when the ignition is in Do not leave the key fob in or near the vehicle The window switches on the driver's door the ON/RUN position.

  • Page 74: Automatic Window Features

    GETTING TO KNOW YOUR VEHICLE If the window runs into any obstacle during 1. Pull the window switch up to close the UTOMATIC INDOW EATURES auto-closure, it will reverse direction and then window completely and continue to hold Auto-Down Feature go back down.

  • Page 75: Wind Buffeting

    GETTING TO KNOW YOUR VEHICLE open, adjust the sunroof opening to minimize the WARNING! buffeting or open any window. Never leave children unattended in a  POWER SUNROOF WITH POWER SHADE — vehicle, or with access to an unlocked vehicle. Never leave the key fob in or near IF EQUIPPED the vehicle, or in a location accessible to children.

  • Page 76: Opening And Closing The Sunroof

    GETTING TO KNOW YOUR VEHICLE Express Open/Close Any release of the switch during open or close WARNING! (Continued) operation will stop the sunroof movement. The Push the switch to open and release it within sunroof will remain in a partially opened Do not allow small children to operate the ...

  • Page 77: Opening And Closing The Power

    GETTING TO KNOW YOUR VEHICLE beyond the half open position. Pulling the Any release of the switch will stop the PENING LOSING OWER sunshade switch when the sunshade is in the movement and the sunshade will remain in a UNSHADE half open position will automatically close partially opened position until the switch is The sunshade has two programmed open...

  • Page 78: Sunroof Maintenance

    GETTING TO KNOW YOUR VEHICLE HOOD 2. Move to the outside of the vehicle. The UNROOF AINTENANCE safety latch release lever is located behind Use only a non-abrasive cleaner and a soft cloth the front edge of the hood at the center. PENING to clean the glass panel.

  • Page 79: Closing The Hood

    GETTING TO KNOW YOUR VEHICLE LIFTGATE LOSING Hoods equipped with gas props are closed from NLOCK IFTGATE the point where the props no longer hold the The liftgate may be released in one of several hood open. ways: WARNING! Key fob (if equipped with power liftgate) ...

  • Page 80: Lock/Close The Liftgate

    GETTING TO KNOW YOUR VEHICLE NOTE: When the liftgate is fully open, the liftgate will  WARNING! close. Before closing the liftgate, make sure to be in Driving with the liftgate open can allow poi- possession of the key because the liftgate may When the liftgate is moving, the liftgate will ...
  • Page 81 GETTING TO KNOW YOUR VEHICLE is within 5 ft (1.5 m) of the liftgate, pulling the The power liftgate will not operate in to fully open the liftgate and then push it  temperatures below −22°F (−30°C) or again to close. outside handle will unlock and open the liftgate.

  • Page 82: Cargo Area Features

    GETTING TO KNOW YOUR VEHICLE ARGO EATURES WARNING! Removable Rear Shelf — If Equipped Driving with the liftgate open can allow  poisonous exhaust gases into your vehicle. CAUTION! You and your passengers could be injured by these fumes. Keep the liftgate closed Do not place heavy objects on the Rear ...
  • Page 83 GETTING TO KNOW YOUR VEHICLE 4. Clear the pins placed outside of the shelf, and then remove the rear shelf pulling it upwards and out through the rear doors. Adjusting The Rear Shelf Rear Shelf Removal Label 5. The rear shelf can be stored in the cargo Cargo Load Floor area, or behind the front seat backs.
  • Page 84 GETTING TO KNOW YOUR VEHICLE NOTE: Do not raise the floor beyond the point of The lower position is not available in vehicles resistance. In vehicles equipped with a power equipped with either a compact spare tire, or a liftgate, forcing the floor upward can damage full size spare tire.
  • Page 85 GETTING TO KNOW YOUR VEHICLE To fully raise the load floor, pull upward on the Cargo Tie-Down Hooks And Loops WARNING! (Continued) floor handle, pull the floor outward, then The tie-downs located on the cargo area floor position the floor upright with the bottom fitting The weight and position of cargo and should be used to secure loads safely when the on top of the floor positioning brackets.

  • Page 86: Roof Luggage Rack - If Equipped

    GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED Rear Storage Bins WARNING! The rear storage bins are located in the rear of The load carried on the roof, when equipped Cargo must be securely tied down before driv- the vehicle on the sides of the load floor.
  • Page 87 GETTING TO KNOW YOUR VEHICLE CAUTION! (Continued) Place a blanket or other protection  between the surface of the roof and the load. Travel at reduced speeds and turn corners  carefully when carrying large or heavy loads on the roof rack. Wind forces, due to natural causes or nearby truck traffic, can add sudden upward lift.

  • Page 88: Base / Midline Instrument Cluster

    GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER Base Instrument Cluster...
  • Page 89 GETTING TO KNOW YOUR INSTRUMENT PANEL Midline Instrument Cluster...

  • Page 90: Getting To Know Your Instrument Panel

    GETTING TO KNOW YOUR INSTRUMENT PANEL 4. Temperature Gauge IDLINE NSTRUMENT LUSTER ESCRIPTIONS The temperature gauge shows engine  coolant temperature. Any reading within 1. Tachometer the normal range indicates that the engine cooling system is operating satis- Indicates the engine speed in revolutions ...
  • Page 91 GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Fuel Gauge WARNING! CAUTION! The gauge shows the level of fuel in the  A hot engine cooling system is dangerous. Driving with a hot engine cooling system fuel tank when the ignition switch is in You or others could be badly burned by steam could damage your vehicle.

  • Page 92: Premium Instrument Cluster

    GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER Premium Instrument Cluster...

  • Page 93: Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL 2. Tachometer REMIUM NSTRUMENT LUSTER WARNING! ESCRIPTIONS Indicates the engine speed in revolutions  A hot engine cooling system is dangerous. per minute (RPM x 1000). You or others could be badly burned by steam 1.

  • Page 94: Base / Midline Instrument Cluster - Diesel

    GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER — DIESEL Base Diesel Instrument Cluster...
  • Page 95 GETTING TO KNOW YOUR INSTRUMENT PANEL Midline Diesel Instrument Cluster...

  • Page 96: Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL 4. Temperature Gauge IDLINE NSTRUMENT LUSTER ESCRIPTIONS The temperature gauge shows engine  coolant temperature. Any reading within 1. Tachometer the normal range indicates that the engine cooling system is operating satis- Indicates the engine speed in revolutions ...
  • Page 97 GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Fuel Gauge WARNING! CAUTION! The gauge shows the level of fuel in the  A hot engine cooling system is dangerous. Driving with a hot engine cooling system fuel tank when the ignition switch is in You or others could be badly burned by steam could damage your vehicle.

  • Page 98: Premium Instrument Cluster - Diesel

    GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER — DIESEL Premium Diesel Instrument Cluster...

  • Page 99: Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL The fuel pump symbol points REMIUM NSTRUMENT LUSTER  CAUTION! to the side of the vehicle where ESCRIPTIONS Driving with a hot engine cooling system the fuel door is located. could damage your vehicle. If the tempera- 1.

  • Page 100: Instrument Cluster Display Location And

    GETTING TO KNOW YOUR INSTRUMENT PANEL controls allow you to scroll through and enter The instrument cluster display menu items the main menus and submenus. You can consist of the following as equipped: access the specific information you want and Drive —...
  • Page 101 GETTING TO KNOW YOUR INSTRUMENT PANEL The systems allow the driver to select OK Button  information by pushing the following buttons Push the OK button to access/select the mounted on the steering wheel: information screens or submenu screens of a main menu item.

  • Page 102: Oil Change Reset - If Equipped

     Unstored Messages Until RUN Unless reset, this message will continue to   Driver Interactive Display (Compass, Temp,  display each time the ignition is cycled to the Range to Empty, Trip A, Trip B, Average Fuel ON/RUN position.

  • Page 103: Display And Messages - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL To reset the oil change indicator after Driver Seat Belt Unbuckled Service Tire Pressure System   performing the scheduled maintenance, refer Passenger Seat Belt Unbuckled Park Brake Engaged   to the following procedure: Traction Control Off Brake Fluid Low ...

  • Page 104: Gear Shift Indicator (Gsi) - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL Remote Start Canceled Liftgate Open The Reconfigurable Telltales section is divided  NSTRUMENT LUSTER ISPLAY into the white or yellow telltales area on the left, TEMS Remote Start Canceled Time Expired  and the green or red telltales area on the right. The instrument cluster display can be used to Remote Start Disabled Start To Reset ...
  • Page 105 GETTING TO KNOW YOUR INSTRUMENT PANEL different screen within the selected category. If Tire Pressure (mph or km/h) of the speedometer. Hold the OK  the Menu button is pressed in this view, the button to toggle between Analog and Digital Fuel Economy ...
  • Page 106 GETTING TO KNOW YOUR INSTRUMENT PANEL will display when in Zoomed Out view/“Press OK 1. Tire Pressure — If Equipped 3. Transmission Temperature — Automatic to Zoom Out” will display when in Zoomed In Transmission Only If tire pressure is OK for all tires a vehicle ...
  • Page 107 GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Economy Average – The display shows the average fuel Elapsed Time – Shows the total elapsed time   economy (MPG, or L/100 km, or km/L) since of travel since Trip A or Trip B has been reset. Push and release the up or down arrow...
  • Page 108  button until the Messages Menu Icon is None  Transfer Case Status  highlighted in the instrument cluster display. Compass Steering Angle  This feature shows the number of stored  warning messages. Pushing the left or right Outside Temp Sway Bar Status ...
  • Page 109   Outside Temp  Lights  Metric  Time  Doors and Locks  Custom: allows individual changes of units  Audio Info  Compass (If Equipped)  for temperature, distance, consumption, and Trip A Distance tire pressure. ...
  • Page 110 GETTING TO KNOW YOUR INSTRUMENT PANEL Clock And Date Rear ParkSense Volume (If Equipped): selec- Warning off. If the driver exceeded the set  tion of the volume of the beeps provided by speed, a single chime will sound along with a By selecting Clock and Date, the time and date the rear ParkSense pop up message of “Speed Warning...
  • Page 111 Horn With Remote Start (If Equipped): acti-  Greeting Lights: activate the direction indica-  will display dashes (- -) until the compass is vate/deactivate the horn at the Remote tors when unlocking the doors calibrated. You may also calibrate the compass...
  • Page 112 Keep magnetic materials away from the top of the instrument panel, such as iPod’s, Mobile Phones, Laptops, and Radar Detectors. This is where the compass module is located, and it can cause interference with the compass sensor, and it may give false readings.

  • Page 113: Diesel Displays

    GETTING TO KNOW YOUR INSTRUMENT PANEL (DPF) IESEL ISPLAYS IESEL ARTICULATE ILTER CAUTION! ESSAGES When the appropriate conditions exist, the The engine may be switched off even if the following messages display in the instrument This engine meets all required diesel engine warning light is on: repeated interruptions of cluster display: emissions standards.
  • Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL diesel engine and exhaust after-treatment displayed, you will hear one chime to assist in To correct this condition it will be necessary system may never reach the conditions alerting you of this condition. to have your vehicle serviced by an autho- required to cleanse the filter to remove the rized dealer.

  • Page 115: Fuel System Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL YSTEM ESSAGES The following chart contains a list of different messages that may appear in the instrument cluster, depending on different system or fuel conditions. Use the descriptions to interpret what the message means and determine the best action to take. MESSAGE DESCRIPTION Diesel Emissions Additive AdBlue®...
  • Page 116 GETTING TO KNOW YOUR INSTRUMENT PANEL MESSAGE DESCRIPTION Diesel Emissions Additive AdBlue® (UREA) Fault Warning Messages: This message will display if AdBlue® (UREA) system issue detected is not serviced during the allowed period. Your engine will not restart unless your vehicle is serviced by an authorized dealer. If the level is not resolved, an Engine Will Not Restart Service additional warning appear whenever a certain threshold is reached until it will no longer be possible to start the AdBlue®...

  • Page 117: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL When load reduction is activated, the message Rear Defroster And Heated Mirrors ATTERY AVER ATTERY AVER  “Battery Saver On” or “Battery Saver Mode” will — E ESSAGE LECTRICAL HVAC System  appear in the instrument cluster display. —...

  • Page 118: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Unusual driving cycles (short trips separated Turn off redundant lights (interior or exte-   by long parking periods). rior) The warning/indicator lights will illuminate in The vehicle was parked for an extended Check what may be plugged in to power ...
  • Page 119 GETTING TO KNOW YOUR INSTRUMENT PANEL as a bulb check when the ignition is placed in Brake System (ABS) / Electronic Stability If brake failure is indicated, immediate repair is the ON/RUN or ACC/ON/RUN position. This light Control (ESC) system. In this case, the light will necessary.
  • Page 120 GETTING TO KNOW YOUR INSTRUMENT PANEL the parking brake is applied or a brake fault is Door Open Warning Light Electric Power Steering (EPS) Fault detected. If the light does not illuminate, have Warning Light This indicator will illuminate when a the light inspected by an authorized dealer.
  • Page 121 GETTING TO KNOW YOUR INSTRUMENT PANEL The light should turn off. If the light remains on temperature is too high, this light will illuminate NOTE: with the vehicle running, your vehicle will and a single chime will sound. If the vehicle is moving, there will also be a usually be drivable;...
  • Page 122 GETTING TO KNOW YOUR INSTRUMENT PANEL Seat Belt Reminder Warning Light Transmission Temperature Warning Light CAUTION! — If Equipped This warning light indicates when the Continuous driving with the Transmission driver or passenger seat belt is This warning light will illuminate to Temperature Warning Light illuminated will unbuckled.

  • Page 123: Yellow Warning Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Park Brake Warning Light possible to have the problem diagnosed and ELLOW ARNING IGHTS corrected. This warning light will illuminate to Anti-Lock Brake System (ABS) Warning indicate the Electronic Park Brake is The ESC OFF Indicator Light and the ESC Indi- ...
  • Page 124 GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Cutoff Warning Light — If Equipped Engine Check/Malfunction Indicator (MIL) serviced by an authorized dealer as soon as possible if this occurs. Warning Light This warning light will illuminate after an accident has occurred, and the The MIL is a part of an Onboard WARNING! system has shut the fuel off.
  • Page 125 GETTING TO KNOW YOUR INSTRUMENT PANEL AdBlue® (UREA) Injection System Failure Service 4WD Warning Light — If Equipped recommended value and/or that slow pressure loss is occurring. In these cases, optimal tire Warning Light — If Equipped This warning light will illuminate to duration and fuel consumption may not be signal a fault with the 4WD system.
  • Page 126 GETTING TO KNOW YOUR INSTRUMENT PANEL vehicle has tires of a different size than the size to trigger illumination of the TPMS low tire wheels allow the TPMS to continue to function indicated on the vehicle placard or tire inflation pressure telltale.

  • Page 127: Yellow Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Towing Hook Breakdown Warning Light — If the front and rear wheels to rotate at the same Diesel Particulate Filter (DPF) Cleaning In speed Ú page 164. Equipped Progress Indicator Light — Diesel Versions With DPF Only —...
  • Page 128 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Low Diesel Emissions Additive AdBlue® Water In Fuel Indicator Light — If Equipped On some versions, together with the symbol (UREA) Indicator Light — If Equipped The “Water In Fuel Indicator Light” will switching on, the display shows a dedicated illuminate when there is water The Low Diesel Exhaust Emissions...

  • Page 129: Green Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Wait To Start Light — If Equipped Active Lane Management Indicator Light — Turn Signal Indicator Lights If Equipped This indicator light will illuminate for When the left or right turn signal is approximately two seconds when the activated, the turn signal indicator will The LaneSense indicator light ignition is turned to the RUN position.

  • Page 130: White Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Cruise Control SET Indicator Light — If Automatic High Beam Indicator Light — If Hill Descent Control ( HDC) Indicator Light Equipped With A Premium Instrument Equipped — If Equipped Cluster This indicator shows that the This indicator shows when the HDC automatic high beam headlights are feature is turned on.

  • Page 131: Blue Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Speed Warning Indicator Light — If Speeds above 75 mph (120 km/h)  NDICATOR IGHTS - 1 cycle / 2 sec (secondary level) Equipped Cruise Control Ready Indicator Light With When Set Speed Warning is turned on Base Instrument Cluster —...

  • Page 132: Onboard Diagnostic System - Obd Ii

    GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! WARNING! Your vehicle is equipped with a sophisticated Prolonged driving with the MIL on could ONLY an authorized service technician   Onboard Diagnostic system called OBD II. This cause further damage to the emission should connect equipment to the OBD II system monitors the performance of the...

  • Page 133: Starting And Operating

    STARTING AND OPERATING STARTING THE ENGINE NOTE: WARNING! (Continued) For manual transmission versions that include Before starting your vehicle, adjust your seat, both Gasoline and Diesel models, ensure the Do not leave the key fob in or near the  adjust both inside and outside mirrors, and vehicle, or in a location accessible to chil- parking brake is engaged, and the clutch &...
  • Page 134 STARTING AND OPERATING Tip Start Feature Automatic Transmission Keyless Ignition Functions — Using The ENGINE START/STOP Button Place the ignition switch to the START position The gear selector must be in the NEUTRAL or and release it as soon as the starter engages. PARK position before you can start the engine.

  • Page 135: Cold Weather Operation (Below -22°F Or −30°C)

    STARTING AND OPERATING Keyless Ignition Functions — With Driver’s Foot Keyless Ignition Functions — Using The ENGINE accessories follow these steps starting with the OFF The Brake Pedal/Clutch Pedal (In PARK Or START/STOP Button ignition switch in the OFF position: NEUTRAL Position) 1.

  • Page 136: After Starting - Warming Up The Engine

    STARTING AND OPERATING — W 1. Install a battery charger or jumper cables FTER TARTING ARMING CAUTION! to the battery to ensure a full battery NGINE charge during the crank cycle. To prevent damage to the starter, do not The idle speed is controlled automatically and it continuously crank the engine for more than 2.

  • Page 137: Stopping The Engine

    STARTING AND OPERATING 4. Remove the key from the ignition when the When the ignition is in the STOP/OFF position, WARNING! (Continued) engine is shut off. the window switches remain active for three minutes. Opening a front door will cancel this If the vehicle has a discharged battery, ...
  • Page 138 STARTING AND OPERATING WARNING! CAUTION! WARNING! (Continued) Before exiting a vehicle, always come to a The engine should not be allowed to crank for Do not leave the key fob in or near the   complete stop, then shift the automatic vehicle, or in a location accessible to chil- more than 30 seconds.
  • Page 139 STARTING AND OPERATING Tip Start Feature For the same decrease in temperature, the CAUTION! engine requires twice as much power to crank Place the ignition in the START mode and at the same RPM. The use of battery blankets If the “Water in Fuel Indicator Light” remains release it as the starter engages.

  • Page 140: Engine Break-In Recommendations

    STARTING AND OPERATING ELECTRIC PARK BRAKE (EPB) Engine Warm Up While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes Avoid full throttle operation when the engine is Your vehicle is equipped with an EPB system to a good break-in. Wide-open throttle cold.
  • Page 141 STARTING AND OPERATING The EPB switch is located on the center console. BRAKE warning lamp will not illuminate; To release the parking brake manually, the however, it can only be released when the ignition switch must be in the ON/RUN position. ignition switch is in the ON/RUN position.
  • Page 142 STARTING AND OPERATING WARNING! CAUTION! WARNING! (Continued) Do not rely on the parking brake to operate If the Brake System Warning Light remains on Do not leave the key fob in or near the   effectively if the rear brakes have been vehicle, or in a location accessible to chil- with the parking brake released, a brake immersed in water or mud.

  • Page 143: Auto Park Brake

    STARTING AND OPERATING enabled and disabled by customer selection The driver door is open.  WARNING! through the Customer Programmable Features The vehicle is not in the PARK position.  Driving the vehicle with the parking brake section of the Uconnect Settings. engaged, or repeated use of the parking For manual transmissions, the EPB will Any single Auto Park Brake application can be...

  • Page 144: Brake Service Mode

    STARTING AND OPERATING Service Mode has requirements that must be When brake service work is complete, the RAKE ERVICE met in order to be activated: following steps must be followed to reset the We recommend having your brakes serviced by parking brake system to normal operation: The vehicle must be at a standstill.

  • Page 145: Manual Transmission - If Equipped

    STARTING AND OPERATING MANUAL TRANSMISSION — IF EQUIPPED NOTE: the knob and move the gear selector all the way During cold weather, you may experience left and then forward. increased effort in shifting until the transmis- WARNING! sion fluid warms up. This is normal. You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied.

  • Page 146: Downshifting

    STARTING AND OPERATING Recommended Vehicle Shift Speeds To utilize your manual transmission efficiently for fuel economy and performance, it should be upshifted as listed in the recommended shift speed chart. Shift at the vehicle speeds listed for acceleration. When heavily loaded or pulling a trailer, these recommended up-shift speeds may not apply. Manual Transmission Shift Speeds in MPH (KM/H) Gear Selection 2 to 3...
  • Page 147 STARTING AND OPERATING Maximum Recommended Downshift CAUTION! CAUTION! (Continued) Speeds Skipping gears and downshifting into lower Failure to follow the maximum recom-   CAUTION! gears at higher vehicle speeds can damage mended downshifting speeds may cause the engine and clutch systems, Any attempt the engine damage and/or damage the Failure to follow the maximum recommended to shift into lower gear with clutch pedal...

  • Page 148: Parking

    STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 Maximum Speed 80 (129) 70 (113) 50 (81) 30 (48) 15 (24) NOTE: ARKING CAUTION! NEVER leave the car with the gearbox in...

  • Page 149: Automatic Transmission - If Equipped

    STARTING AND OPERATING AUTOMATIC TRANSMISSION — IF WARNING! (Continued) WARNING! (Continued) EQUIPPED It is dangerous to shift out of PARK or Unintended movement of a vehicle could   NEUTRAL if the engine speed is higher than injure those in or near the vehicle. As with You must press and hold the brake pedal while idle speed.

  • Page 150: Ignition Park Interlock

    STARTING AND OPERATING the transmission in PARK. This system also CAUTION! WARNING! (Continued) locks the transmission in PARK whenever the Damage to the transmission may occur if the ignition is in the OFF mode. Never leave children alone in a vehicle, or ...

  • Page 151: Six-Speed Or Nine-Speed Automatic

    STARTING AND OPERATING in the ON/RUN mode (whether the engine is transmission out of PARK (or NEUTRAL, when The nine-speed transmission has been running or not), and the brake pedal must be the vehicle is stopped or moving at low speeds). developed to meet the needs of current and pressed.
  • Page 152 STARTING AND OPERATING using the AutoStick shift control Ú page 154. PARK (P) Moving the gear selector into the AutoStick This range supplements the parking brake by (+/-) position (beside the DRIVE position) locking the transmission. The engine can be activates AutoStick mode, providing manual started in this range.
  • Page 153 STARTING AND OPERATING 3. Turn the ignition OFF. WARNING! (Continued) WARNING! (Continued) 4. Remove the key fob from the vehicle. It is dangerous to shift out of PARK or Unintended movement of a vehicle could   NEUTRAL if the engine speed is higher than injure those in or near the vehicle.
  • Page 154 STARTING AND OPERATING Look at the transmission gear position  CAUTION! WARNING! (Continued) display and verify that it indicates the PARK position (P). Before moving the transmission gear Never leave children alone in a vehicle, or   selector out of PARK, you must turn the igni- with access to an unlocked vehicle.
  • Page 155 STARTING AND OPERATING economy. The transmission automatically If the transmission becomes extremely hot, the WARNING! upshifts through all forward gears. The DRIVE "Transmission Temperature Warning Light" may Do not coast in NEUTRAL and never turn off position provides optimum driving illuminate, and the transmission may operate the ignition to coast down a hill.
  • Page 156 STARTING AND OPERATING and improve overall vehicle performance. This another upshift or downshift is chosen, except If a requested downshift would cause the  engine to over-speed, that shift will not occur. system can also provide you with more control as described below.
  • Page 157 STARTING AND OPERATING In the event of a momentary problem, the NOTE: WARNING! transmission can be reset to regain all forward Even if the transmission can be reset, we Do not downshift for additional engine gears by performing the following steps: recommend that you visit an authorized dealer braking on a slippery surface.

  • Page 158: Seven - Speed Ddct Automatic

    STARTING AND OPERATING NOTE: The electronically-controlled transmission (+/-) position (beside the DRIVE position) The torque converter clutch will not engage until provides a precise shift schedule. The activates AutoStick mode, providing manual the engine and/or transmission is warm transmission electronics are self-calibrating; shift control and displaying the current gear in (usually after 1 to 3 miles [2 to 5 km] of driving).

  • Page 159: Gear Ranges

    STARTING AND OPERATING precaution, turn the front wheels toward the ANGES WARNING! (Continued) curb on a downhill grade and away from the Do not press the accelerator pedal when curb on an uphill grade. Your vehicle could move and injure you and ...
  • Page 160 STARTING AND OPERATING CAUTION! WARNING! (Continued) WARNING! (Continued) Before moving the transmission gear Unintended movement of a vehicle could Never leave children alone in a vehicle, or    selector out of PARK, you must turn the igni- injure those in or near the vehicle. As with with access to an unlocked vehicle.
  • Page 161 STARTING AND OPERATING Look at the transmission gear position economy. The transmission automatically  WARNING! display and verify that it indicates the PARK upshifts through all forward gears. The DRIVE position (P). Do not coast in NEUTRAL and never turn off position provides optimum driving the ignition to coast down a hill.
  • Page 162 STARTING AND OPERATING Very aggressive driving may result in some rarily hold the car in position when the brake heavy loading conditions, in hilly terrain, or  clutch odor similar to a manual transmission. pedal is released. If the accelerator pedal is traveling into strong head winds), use the An active warning message will appear in the not applied after a short time, the car will roll...
  • Page 163 STARTING AND OPERATING MESSAGE DESCRIPTION The gear selector is being moved without the brake pedal pressed while SHIFT TO PARK TO OBTAIN DRIVABILITY locked in PARK or NEUTRAL. The transmission will ignore the attempt to move the selector and stay in NEUTRAL, and display this message. In AutoStick mode, the gear selected by the driver is not available due to GEAR NOT AVAILABLE a fault condition.
  • Page 164 STARTING AND OPERATING MESSAGE DESCRIPTION The transmission is unable to shift itself automatically, due to a fault AUTOMATIC MODE NOT AVAILABLE condition. Use the AutoStick mode to shift the transmission manually. See an authorized dealer for diagnosis and service. The transmission driving clutch is overheating, usually due to repeated TRANS.

  • Page 165: Four-Wheel Drive Operation - If Equipped

    STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF Transmission Limp Home Mode 1. Stop the vehicle. Transmission function is monitored EQUIPPED 2. Shift the transmission into PARK. electronically for abnormal conditions. If a 3. Turn the ignition to the OFF position. condition is detected that could result in CTIVE RIVE...
  • Page 166 STARTING AND OPERATING Active Drive Control — If Equipped CAUTION! The Power Transfer Unit (PTU) is locked to All wheels must have the same size and type ensure immediate availability of torque to the tires. Unequal tire sizes must not be used. rear drive axles.

  • Page 167: Selec-Terrain - If Equipped

    STARTING AND OPERATING SELEC-TERRAIN — IF EQUIPPED Enabling 4WD LOW a vehicle with two wheel drive. This mode also reduces fuel consumption, since it With the vehicle stationary, the ignition in the Selec-Terrain combines the capabilities of the allows the disconnect of the drive shaft ON/RUN position or with the engine running, vehicle control systems, along with driver input, where conditions permit.

  • Page 168: Power Steering

    STARTING AND OPERATING ROCK (Trailhawk only): This mode is only driving conditions are safe, then pull over and  WARNING! available in 4WD LOW. The device sets the let vehicle idle for a few moments until the light vehicle to maximize traction and allows the Continued operation with reduced assist turns off Ú...

  • Page 169: Operating Modes

    STARTING AND OPERATING Engine Restarting Mode PERATING ODES WARNING! Models equipped with manual transmission: Engine Stopping Mode Before opening the hood, make sure that the To restart the engine, press the clutch pedal. engine is off and that the ignition is in the Models equipped with a manual transmission: OFF mode.

  • Page 170: Possible Reasons The Engine Does Not Autostop

    STARTING AND OPERATING HVAC is set to MAX A/C. going into a STOP/START READY state under OSSIBLE EASONS NGINE  more extreme conditions of the items listed UTOSTOP Engine has not reached normal operating  above. temperature. Prior to engine shut down, the system will check TART NGINE HILE...

  • Page 171: Manual Activation / Deactivation

    STARTING AND OPERATING ACTIVE SPEED LIMITER — IF EQUIPPED Stop/Start OFF switch is pushed.  ANUAL CTIVATION EACTIVATION A Stop/Start system error occurs. To activate/deactivate the system manually,  The Active Speed Limiter button is positioned push the button on the instrument panel. on the right side of the steering wheel.

  • Page 172: Activation

    STARTING AND OPERATING NOTE: CTIVATION EACTIVATION The Cruise Control (if equipped) system will be To activate the feature, push the Active Speed To turn off Active Speed Limiter, push the Active unavailable while the Active Speed Limiter is in Limiter button located on the right side of the Speed Limiter button on the right side of the use.
  • Page 173 STARTING AND OPERATING The Cruise Control buttons are located on the NOTE: To Activate right side of the steering wheel. In order to ensure proper operation, the Cruise Push the on/off button to activate the Cruise Control system has been designed to shut down Control.
  • Page 174 STARTING AND OPERATING To Set A Desired Speed If the button is continually pushed, the set Using Cruise Control On Hills  speed will continue to adjust until the button The transmission may downshift on hills to Turn the Cruise Control on. When the vehicle is released, then the new set speed will be maintain the vehicle set speed.

  • Page 175: Parksense Rear Park Assist System

    STARTING AND OPERATING PARKSENSE REAR PARK ASSIST SYSTEM — To Resume Speed fast. The system will become active again if the vehicle speed is decreased to speeds less than To resume a previously set speed, push the RES IF EQUIPPED approximately 6 mph (9 km/h).

  • Page 176: Parksense Display

    STARTING AND OPERATING The ParkSense Warning screen is located within The system will indicate a detected obstacle by If an obstacle is detected in the left and /or right the instrument cluster display Ú page 98. It showing a single arc in one or more regions rear region, the display will show a single provides visual warnings to indicate the based on the obstacle’s distance and location...
  • Page 177 STARTING AND OPERATING Rear ParkSense Arcs 1 — Continuous Tone/Flashing Arc 4 — Slow Tone/Solid Arc 2 — Fast Tone/Flashing Arc 5 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 6 — Single 1/2 Second Tone/Solid Arc...
  • Page 178 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Greater than Less than Rear Distance...

  • Page 179: Enabling And Disabling Parksense

    STARTING AND OPERATING actuate a single chime, once per ignition cycle, sensors quickly keeping the vapor jet/high NABLING ISABLING ENSE and it will display the “PARKSENSE pressure washing nozzles at least 4 inches ParkSense can be enabled and UNAVAILABLE WIPE REAR SENSORS” or the (10 cm) from the sensors.

  • Page 180: Parkview Rear Back Up Camera - If

    STARTING AND OPERATING Clean the ParkSense sensors regularly, NOTE:  CAUTION! taking care not to scratch or damage them. If any objects are attached to the fascia/ The sensors must not be covered with ice, bumper within a 6.5 ft (2 m) field of view, they ParkSense is only a parking aid and it is ...
  • Page 181 STARTING AND OPERATING displayed on the Navigation/Multimedia radio When the vehicle is shifted out of REVERSE Distance To The Rear Zone display screen along with a caution note to (with camera delay turned off), the rear camera Of The Vehicle “Check Entire Surroundings”...

  • Page 182: Surround View Camera System - If

    STARTING AND OPERATING is available. By pressing the “magnifying glass” NOTE: CAUTION! icon in the upper left of the display screen, the If the vehicle is in DRIVE, NEUTRAL, or  To avoid vehicle damage, ParkView should image will zoom in to four times the standard ...
  • Page 183 STARTING AND OPERATING this note will disappear. The Surround View PARK or the ignition is placed in the OFF Distance To The Rear Zone Camera system is comprised of four sequential position. There is a touchscreen button “X” to Of The Vehicle cameras located in the front grille, rear liftgate disable the display of the camera image.
  • Page 184 STARTING AND OPERATING The arcs will change color from yellow to red Open front doors will cancel outside image. Front Cross Path View  corresponding the distance zones to the Pressing the Front Cross Path soft key Open liftgate will cancel rear image while in ...

  • Page 185: Zoom View

    STARTING AND OPERATING Deactivation WARNING! CAUTION! (Continued) The system can be deactivated under the Drivers must be careful when backing up To avoid vehicle damage, the vehicle must  following conditions: even when using the Surround View Camera. be driven slowly when using Surround View The speed of the vehicle is greater than ...

  • Page 186: Refueling The Vehicle - Gasoline

    STARTING AND OPERATING REFUELING THE VEHICLE — GASOLINE When Zoom View is selected while the vehicle is in REVERSE, then shifted to DRIVE, the camera ENGINE delay view will display the standard Back Up Camera view. If the vehicle is then returned to The Capless Fuel System uses a flapper placed REVERSE gear from DRIVE, the Zoom View at the filler pipe of the fuel tank;...

  • Page 187: Emergency Fuel Filler Door Release

    STARTING AND OPERATING 3. There is no fuel filler cap. A flapper door 1. Open the liftgate. WARNING! inside the pipe seals the system. 2. Remove package tray (if equipped). Never have any smoking materials lit in or  4. Insert the fuel nozzle fully into the filler pipe; near the vehicle when the fuel door is open 3.

  • Page 188: Refueling The Vehicle - Diesel Engine

    STARTING AND OPERATING 4. Grab the release cable tether and gently 5. Push on the outer edge to open the fuel pull up while simultaneously push the fuel door. filler door to unlock. NOTE: Adding excessive pull force may lead to cable tether breakage.
  • Page 189 STARTING AND OPERATING 1. Unlock the fuel filler door by pushing the 4. Insert the fuel nozzle fully into the filler pipe; 6. Wait 10 seconds before removing the fuel unlock button on the key fob or the unlock the nozzle opens and holds the flapper door nozzle to allow fuel to drain from nozzle.

  • Page 190: Adblue® (Urea) - If Equipped

    STARTING AND OPERATING messages and system warnings Ú page 117. AdBlue® (UREA) is subject to freezing at the CAUTION! AdBlue® (UREA) is a very stable product with a lowest temperatures. For example, AdBlue® For diesel engines, only use diesel fuel for long shelf life.
  • Page 191 STARTING AND OPERATING Adding AdBlue® (UREA) CAUTION! Preliminary Conditions Never fill AdBlue® (UREA) or diesel fuel into AdBlue® (UREA) freezes at temperatures lower the wrong filling ports. This may result in than 12°F (-11°C). If the car stands for a long serious damage to the engine, fuel system, time at this temperature refilling could be and emission system components.
  • Page 192 STARTING AND OPERATING Refilling With Containers Place the ignition to RUN (it is not necessary operate below the freezing point of the UREA,  to start the engine). it is advisable not to fill the tank beyond the Proceed as follows: maximum level because if the UREA freezes Wait for the indication on the instrument ...

  • Page 193: Vehicle Loading

    STARTING AND OPERATING Never pour AdBlue® (UREA) into another Gross Vehicle Weight Rating (GVWR) Each axle GAWR is determined by the  container: it could be contaminated. components in the system with the lowest load The Gross Vehicle Weight Rating (GVWR) is the carrying capacity (axle, springs, tires or wheels).
  • Page 194 STARTING AND OPERATING Curb Weight The entire vehicle should first be weighed on a Improper weight distributions can have an commercial scale to ensure that the GVWR has adverse effect on the way your vehicle steers The curb weight of a vehicle is defined as the not been exceeded.

  • Page 195: Recreational Towing (Behind Motorhome)

    STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE TOWING CONDITION WHEELS OFF THE GROUND FRONT WHEEL DRIVE (FWD) FOUR-WHEEL DRIVE (4WD) Flat Tow NONE NOT ALLOWED NOT ALLOWED REAR NOT ALLOWED NOT ALLOWED Dolly Tow FRONT NOT ALLOWED On Trailer BEST METHOD...

  • Page 196: (Fwd) Models

    STARTING AND OPERATING — 4X4 5. Turn the ignition to the ON/RUN position, applications. Specific design characteristics ECREATIONAL OWING but do not start the engine. give them a higher center of gravity than ODELS conventional passenger cars. 6. Press and hold the brake pedal. Recreational towing (with all four wheels on the An advantage of the higher ground clearance is ground, or using a towing dolly) is NOT...
  • Page 197 STARTING AND OPERATING sand where additional low speed pulling power determine the depth and the bottom condition (Trailhawk only): Avoid driving in standing water is needed. Vehicle speeds in excess of 25 mph (and location of any obstacles) prior to entering. deeper than 19 inches (48 cm), and reduce (40 km/h) should be avoided when in 4WD Proceed with caution and maintain a steady...
  • Page 198 STARTING AND OPERATING contaminated. Contaminated fluids and Before climbing a steep hill, shift the WARNING! lubricants (milky, foamy in appearance) should transmission to a lower gear and shift the 4WD be flushed/changed as soon as possible to System to 4WD LOW. Use FIRST gear and 4WD If the engine stalls or you lose headway or prevent component damage.
  • Page 199 STARTING AND OPERATING Traction Downhill Completely inspect the underbody of your  WARNING! vehicle. Check tires, body structure, steering, Shift the transmission into a low gear and the suspension, and exhaust system for damage. Abrasive material in any part of the braking four-wheel drive system to 4WD Low range or system may cause excessive wear or select Hill Descent Control (if equipped).

  • Page 200: Multimedia

    MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain WARNING! security features to reduce the risk of For detailed information about the Uconnect unauthorized and unlawful access to vehicle It is not possible to know or to predict all of ...

  • Page 201: Uconnect Settings

    MULTIMEDIA Privacy of any wireless and wired to scroll through menus and change settings. WARNING! (Continued) communications cannot be assured. Third Push the center of the control knob one or more parties may unlawfully intercept information times to select or change a setting. As always, if you experience unusual ...

  • Page 202: Customer Programmable Features

    MULTIMEDIA For the Uconnect 5 With 8.4-inch Display and When making a selection, press the button on USTOMER ROGRAMMABLE EATURES Uconnect 5/5 NAV With 10.1-inch Display the touchscreen to enter the desired menu. Once in the desired menu, press and release Press the Vehicle button, then press the the preferred setting option until a check mark Settings tab on the top of the touchscreen.
  • Page 203 MULTIMEDIA Seat Belt Buzzer When the Seat Belt Buzzer button is pressed on the touchscreen, the system displays the options related to the seat belt buzzer. The available setting is: Setting Name Description This setting will allow you to activate or deactivate the seat belt reminder Seat Belt Buzzer buzzer.
  • Page 204 MULTIMEDIA Setting Name Description This setting will allow you to set the brightness when the headlights are Display Brightness With Headlights ON on. To access this setting, Display Mode must be set to “Manual”. The “+” setting will increase the brightness; the “-” will decrease the brightness. This setting will allow you to set the brightness when the headlights are off.
  • Page 205 MULTIMEDIA My Profile When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles. Setting Name Description This setting will change the language of the Uconnect system. The available languages are Brasileiro, Deutsch, English, Español, Français, Language Italiano, Polski, Japanese, Dutch, Czech, Slovak, Hungarian, Korean, Português, Türk, Pусский, and Arabic.
  • Page 206 MULTIMEDIA Setting Name Description This setting will adjust the units in the vehicle. The available options are “US”, “Metric”, and “Custom”. Within Custom, the available options are “Speed” (MPH or km/h), Units “Distance” (mi or km), “Fuel Consumption” (MPG [US], MPG [UK], L/100 km, or km/L), “Pressure”...
  • Page 207 MULTIMEDIA Setting Name Description This setting will allow you to change the voice options for the radio with Voice Options “Male” or “Female”. Voice Barge-in This setting will allow voice barge-in to be turned on or off. Show Command List This setting will allow the command list to be shown on or off.
  • Page 208 MULTIMEDIA Setting Name Description Reset App Drawer to Default Order This setting will reset the app drawer to its factory default layout. This setting will return all the previously changed settings to their factory Restore Settings to Default default. More Profile Options This setting will give access to more profile options.
  • Page 209 MULTIMEDIA Setting Name Description This setting will turn the Forward Collision Warning-Plus system on or off. The “Off” setting will deactivate the FCW+ system. The “Warning Only” Forward Collision Warning-Plus (FCW+) setting will provide only an audible chime when a collision is detected. The “Warning + Active Braking”...
  • Page 210 MULTIMEDIA Setting Name Description This setting will provide braking assist if the Rear ParkSense system Rear ParkSense Braking Assist senses a collision with an object. This setting will change the type of alert provided when an object is detected in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Blind Spot Alert Alert.
  • Page 211 MULTIMEDIA Setting Name Description This setting will allow you to set the warning type related to the traffic Traffic Sign Assist Warning sign. The available options are “Off”, “Visual”, and “Visual + Chime”. Intelligent Speed Limiter This setting will allow you to turn the Intelligent Speed Limiter on or off. This setting will allow you to set if the system will warn you that the speed New Speed Zone Indication limit has changed in an area.
  • Page 212 MULTIMEDIA Setting Name Description This setting will allow you to set the hours. Sync Time With GPS must be Set Time Hours off for this setting to be available. The “+” setting will increase the hours. The “-” setting will decrease the hours. This setting will allow you to set the minutes.
  • Page 213 MULTIMEDIA Voice When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature. Setting Name Description This setting will allow you to turn the voice recognition “Wake Up” word on Wake Up Word or off.
  • Page 214 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. Setting Name Description This setting will add a delay to the Rear Backup Camera when shifting out ParkView Backup Camera Delay of REVERSE.
  • Page 215 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchased.
  • Page 216 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following setting will be available: Setting Name Description Auto Park Brake This setting will turn the Auto Park Brake on or off. Doors & Locks When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors. Setting Name Description This setting will unlock the doors when any of the doors are opened from...
  • Page 217 MULTIMEDIA Setting Name Description This setting will change how many pushes of the Unlock button on the key fob are needed to unlock all the doors. The “Driver Door” setting will only Remote Door Unlock, Door Lock/1st Press Of Key Fob Unlocks unlock the driver door on the first push on the Unlock button.
  • Page 218 MULTIMEDIA Seats & Comfort When the Seats & Comfort button is pressed on the touchscreen, the system displays the option related to the vehicle’s comfort systems when remote start has been activated or the vehicle has been started. Setting Name Description This setting will activate the vehicle’s comfort systems and heated seats (if equipped) or heated steering wheel (if equipped) when the vehicle is...
  • Page 219 MULTIMEDIA Key Off Options/Engine Off Options When the Key Off Options/Engine Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF. Setting Name Description This setting will keep the radio running after the engine is turned off.
  • Page 220 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. Setting Name Description This setting will adjust audio levels from specific speakers in the front/...
  • Page 221 MULTIMEDIA Setting Name Description This setting will turn the radio off when any of the doors are opened after Radio Off With Door vehicle shut off. This setting will allow you to adjust the volumes of the different radio Volume Adjustment systems and connected devices.
  • Page 222 MULTIMEDIA Radio Setup When the Radio Setup button is pressed on the touchscreen, the system will provide selectable options related to the regional setup of the radio. Setting Name Description This setting will automatically switch between network stations Regional depending on the region. This setting will allow the system to pause the radio or a media device to Traffic Announcement issue a traffic bulletin.

  • Page 223: Steering Wheel Audio Controls - If

    MULTIMEDIA STEERING WHEEL AUDIO CONTROLS — IF increase the volume, and pushing the bottom of EDIA the rocker switch will decrease the volume. EQUIPPED Pushing the top of the switch once goes to the Pushing the center button will make the radio next track on the selected media (AUX/USB/ The remote sound system controls are located switch between the various modes available...

  • Page 224: Safety

    SAFETY SAFETY FEATURES snow, gravel, bumps, railroad tracks, loose WARNING! debris, or panic stops may increase the (ABS) RAKE YSTEM likelihood of ABS activation(s). The ABS contains sophisticated electronic  equipment that may be susceptible to inter- You also may experience the following normal The ABS provides increased vehicle stability ference caused by improperly installed or characteristics when the ABS activates:...

  • Page 225: Drowsy Driver Detection (Ddd)

    SAFETY If the ABS Warning Light remains on or comes 1. “Driver Assistance” WARNING! (Continued) on while driving, it indicates that the anti-lock 2. “Drowsy Driver Detection” portion of the brake system is not functioning The ABS cannot prevent the natural laws of ...

  • Page 226: Electronic Brake Control (Ebc) System

    SAFETY If the driver accepts the suggestion provided by together to enhance both vehicle stability and the system by pushing the OK button on the control in various driving conditions. multifunction lever, the message will disappear Your vehicle may also be equipped with from the display.
  • Page 227 SAFETY Do not reduce brake pedal pressure unless If the Brake System Warning Light remains on or NOTE: braking is no longer desired. Once the brake comes on while driving, it indicates that the The DST feature is only meant to help the driver pedal is released, the BAS is deactivated.
  • Page 228 SAFETY Electronic Roll Mitigation (ERM) independently of other lamps, and will turn on WARNING! and off automatically. This indicates to others ERM anticipates the potential for wheel lift by Many factors, such as vehicle loading, road that the vehicle is stopping quickly. monitoring the driver’s steering wheel input and conditions and driving conditions, influence the speed of the vehicle.
  • Page 229 SAFETY Oversteer — when the vehicle is turning more apply as little throttle as possible. Be sure to  WARNING! (Continued) than appropriate for the steering wheel posi- adapt your speed and driving to the prevailing tion. road conditions. Vehicle modifications, or failure to properly ...
  • Page 230 SAFETY ESC Operating Modes NOTE: WARNING! (Continued) When driving with snow chains, or when starting Depending upon model and mode of operation, off in deep snow, sand, or gravel, it may be Trailer Sway Control (TSC) is disabled when  the ESC system may have multiple operating desirable to allow more wheel spin.
  • Page 231 SAFETY When the vehicle speed drops below 30 mph several miles (kilometers) at speeds greater WARNING! (48 km/h), the ESC system shuts off. ESC is than 30 mph (48 km/h), see an authorized deactivated at low vehicle speeds so that it will In the "Full Off"...
  • Page 232 SAFETY NOTE: HDC has three states: Activating HDC Once HDC is enabled, it will activate The ESC Activation/Malfunction Indicator 1. Off (feature is not enabled and will not  automatically if driven down a grade of sufficient Light and the ESC OFF Indicator Light come activate).
  • Page 233 SAFETY Disabling HDC HDC switch when enable conditions have not The following conditions must be met in order been met. for HSA to activate: HDC will be deactivated and disabled if any of the following conditions occur: The feature must be enabled. The HDC switch is located in the center console ...

  • Page 234: Auxiliary Driving Systems

    SAFETY Rain Brake Support (RBS)— If Equipped the spinning wheel(s) and/or reduce vehicle WARNING! power to provide enhanced acceleration and RBS may improve braking performance in wet There may be situations where the Hill Start stability. A feature of the TCS, Brake Limited conditions.
  • Page 235 SAFETY vehicle may need to be driven for up to The tire pressure will vary with temperature by continue to warn the driver of low tire pressure approximately 1 psi (7 kPa) for every 12°F as long as the condition exists, and will not turn 10 minutes above 15 mph (24 km/h) in order (6.5°C).
  • Page 236 SAFETY Driving on a significantly underinflated tire  CAUTION! CAUTION! (Continued) causes the tire to overheat and can lead to tire failure. Underinflation also reduces fuel The TPMS has been optimized for the orig- Using aftermarket tire sealants may cause ...
  • Page 237 SAFETY NOTE: or more of the four active road tires. In addition, tire pressures, the system will automatically It is particularly important for you to check the the instrument cluster will display a "Tire Low" update, the pressure values in the graphic tire pressure in all of the tires on your vehicle message and a graphic showing the pressure display in the instrument cluster will stop being...
  • Page 238 SAFETY display a "SERVICE TPM SYSTEM" message for Using tire chains on the vehicle. 3. After driving the vehicle for up to  a minimum of five seconds and then display 10 minutes above 15 mph (24 km/h), the Using wheels/tires not equipped with TPMS ...

  • Page 239: Occupant Restraint Systems

    SAFETY OCCUPANT RESTRAINT SYSTEMS off and the graphic in the instrument cluster instrument cluster will display the “SERVICE will display a new pressure value instead of TPM SYSTEM” message and then display Some of the most important safety features in dashes (- -), as long as no tire pressure is dashes (--) in place of the pressure values.
  • Page 240 SAFETY Here are some simple steps you can take to 2. A child who is not big enough to wear the 8. Do not lean against the door or window. If minimize the risk of harm from a deploying air vehicle seat belt properly must be secured your vehicle has side air bags, and bag:...

  • Page 241: Seat Belt Systems

    SAFETY that includes you. This can happen far away Initial Indication WARNING! (Continued) from home or on your own street. If the driver is unbuckled when the ignition Should it be necessary to carry a child on  Research has shown that seat belts save lives, switch is first in the START or ON/RUN position, the passenger side front seat in a and they can reduce the seriousness of injuries...
  • Page 242 SAFETY sequence starts by blinking the Seat Belt seat is folded flat (if equipped). It is feature allows the shoulder part of the seat belt Reminder Light and sounding an intermittent recommended that pets be restrained in the to move freely with you under normal conditions. chime.
  • Page 243 SAFETY WARNING! WARNING! (Continued) WARNING! (Continued) A lap belt worn too high can increase the It is dangerous to ride in a cargo area, Wearing your seat belt incorrectly could    risk of injury in a collision. The seat belt inside or outside of a vehicle.
  • Page 244 SAFETY seat belt. Slide the latch plate up the WARNING! (Continued) WARNING! (Continued) webbing as far as necessary to allow the seat belt to go around your lap. A seat belt that is too loose will not protect A frayed or torn seat belt could rip apart in ...
  • Page 245 SAFETY Lap/Shoulder Belt Untwisting Procedure 3. When the seat belt is long enough to fit, insert the latch plate into the buckle until Use the following procedure to untwist a twisted you hear a “click.” lap/shoulder belt. 1. Position the latch plate as close as possible to the anchor point.
  • Page 246 SAFETY seat belt away from your neck. Push or squeeze NOTE: WARNING! (Continued) the anchorage button to release the anchorage, The adjustable upper shoulder belt anchorage and move it up or down to the position that is equipped with an Easy Up feature. This Position the shoulder belt across the ...

  • Page 247: Supplemental Restraint Systems (Srs)

    SAFETY To remove slack, pull the loose end of the Position the lap belt snug and low below the air bags, the pretensioners are single use items. webbing. Wear the lap belt snug against the abdomen and across the strong bones of the A deployed pretensioner or a deployed air bag hips.
  • Page 248 SAFETY Air Bag Warning Light electrical Air Bag System Components. Your single chime will sound to alert you if the light vehicle may be equipped with the following Air comes on again after initial startup. The Occupant Restraint Controller Bag System Components: (ORC) monitors the readiness of the The ORC also includes diagnostics that will Air Bag System Components...
  • Page 249 SAFETY Redundant Air Bag Warning Light NOTE: The passenger front air bag is mounted in the If the speedometer, tachometer, or any engine instrument panel, above the glove If a fault with the Air Bag Warning related gauges are not working, the Occupant compartment.
  • Page 250 SAFETY Driver And Passenger Front Air Bag WARNING! WARNING! (Continued) Features Being too close to the steering wheel or Should it be necessary to carry a child on   The driver and passenger front air bag system is instrument panel during front air bag the passenger side front seat in a designed to inflate based on the severity and deployment could cause serious injury,...
  • Page 251 SAFETY collisions. The front air bags will not deploy in all The steering wheel hub trim cover and the WARNING! (Continued) frontal collisions, including some that may upper passenger side of the instrument panel produce substantial vehicle damage — for separate and fold out of the way as the air bags Do not put anything on or around the air ...
  • Page 252 SAFETY The Passenger Advanced Front Air Bag can be The Occupant Restraint Controller (ORC) WARNING! ENABLED (ON) or DISABLED (OFF) by selecting monitors the readiness of the electronic parts of A DISABLED (OFF) Passenger Advanced the desired setting in the instrument cluster the air bag system whenever the ignition switch ...
  • Page 253 SAFETY Both indicator lights come on as you drive.  illuminate to show that the Passenger WARNING! Advanced Front Air Bag will not deploy during a Both indicator lights turn off as you drive.  NEVER use a rearward facing child restraint collision.
  • Page 254 SAFETY DISABLING (OFF) the Passenger Advanced WARNING! (Continued) WARNING! (Continued) Front Air Bag A deploying passenger front air bag can Children 12 years or younger should always   To DISABLE (OFF) the Passenger Advanced cause death or serious injury to a child ride buckled up in the rear seat of a vehicle Front Air Bag, access the instrument cluster 12 years or younger, including a child in a...
  • Page 255 SAFETY Action Information Press the “OK” button on the steering wheel to select Passenger AIRBAG OFF “ OFF” Scroll Up or Down to select “YES” to confirm NOTE: Press the “OK” button on the steering wheel to select “YES” If this step is not completed within 1 minute this option will timeout and this process will have to be repeated.
  • Page 256 SAFETY ENABLING (ON) The Passenger Advanced Front Air Bag Access the instrument cluster display main menu located in the instrument cluster by pushing the Up or Down arrow button located on the steering wheel, then complete the following actions: Action Information Scroll Up or Down to “Vehicle Set-Up”...
  • Page 257 SAFETY Action Information A single chime will sound with the Passenger AIRBAG ON indicator light illuminated for 4 to 5 seconds confirming the enabling of the Passenger Advanced Front Air Bag. The Passenger AIRBAG ON indicator light will remain continuously illuminated in the center stack telling the driver and front passenger that the Passenger Advanced Front Air Bag is ENABLED (ON).
  • Page 258 SAFETY WARNING! (Continued) WARNING! (Continued) A deploying passenger front air bag can Do not mount any accessories to the knee   cause death or serious injury to a child impact bolsters such as alarm lights, 12 years or younger, including a child in a stereos, citizen band radios, etc.
  • Page 259 SAFETY occupants if they are not seated properly, or if The trim covering the SABICs is labeled “SRS The SABIC deploys downward, covering the side items are positioned in the area where the SAB AIRBAG” or “AIRBAG.” windows. An inflating SABIC pushes the outside inflates.
  • Page 260 SAFETY side impacts, the Side Air Bags deploy WARNING! WARNING! (Continued) independently; a left side impact deploys the left Side Air Bags only and a right-side impact Occupants, including children, who are up In order for the SABICs to work as intended, ...
  • Page 261 SAFETY Rollover Events (If Equipped With Rollover The SABICs may help reduce the risk of partial WARNING! Sensing) or complete ejection of vehicle occupants Side Air Bags need room to inflate. Do not through side windows in certain rollover or side ...
  • Page 262 SAFETY Supplemental Side Air Bags contact with chemicals. They are not perma-  WARNING! nent and normally heal quickly. However, if Front and Side Impact Sensors  you haven’t healed significantly within a few Deployed air bags and seat belt pretension- days, or if you have any blistering, see your ers cannot protect you in another collision.
  • Page 263 SAFETY determine whether to have the Enhanced Cut off battery power to the: engine. If there are no fuel leaks or damage to  Accident Response System perform the the vehicle electrical devices (e.g. headlights) Engine  following functions: after an accident, reset the system by following the procedure described below.
  • Page 264 SAFETY Customer Action Customer Will See NOTE: Each step MUST BE held for at least two seconds 1. Turn ignition STOP/OFF/LOCK. (Turn Signal Switch Must be placed in Neutral State). Right turn light BLINKS. 2. Turn ignition MAR/ON/RUN. Left turn light is OFF. Right turn light is ON SOLID.
  • Page 265 SAFETY Customer Action Customer Will See NOTE: Each step MUST BE held for at least two seconds Right turn light is ON SOLID. 9. Turn left turn signal switch ON. Left turn light is ON SOLID. Right turn light is OFF. 10.
  • Page 266 SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) WARNING! (Continued) This vehicle is equipped with an event data WARNING! Do not attempt to modify any part of your  recorder (EDR). The main purpose of an EDR is air bag system.

  • Page 267: Child Restraints - Carrying Children Safely

    SAFETY — C These data can help provide a better Everyone in your vehicle needs to be buckled up HILD ESTRAINTS ARRYING understanding of the circumstances in which at all times, including babies and children. EC HILDREN AFELY crashes and injuries occur. directive 2003/20/EC requires proper use of restraints in all EC countries.
  • Page 268 SAFETY read and follow all the instructions and WARNING! (Continued) WARNING! (Continued) warnings in the child restraint Owner’s Manual and on all the labels attached to the child Should it be necessary to carry a child on In a collision, an unrestrained child can ...
  • Page 269 SAFETY Check the label of your child restraint. All Child restraint systems with ISOFIX anchor-  WARNING! approved child restraints must include ages are available for installing the child restraint system to the vehicle without using type-approval data and the control mark on its Should it be necessary to carry a child on the the vehicle’s seat belts.
  • Page 270 SAFETY Group 1 Group 2 child’s head and does not induce stress on the neck in the event of sudden decelerations or a crash. The rear-facing child restraint is restrained by the vehicle’s seat belts, as shown in fig. A. The child seat restrains the child with its own harness.
  • Page 271 SAFETY Group 3 Fig. D shows an example of a Group 3 child WARNING! (Continued) restraint system correctly positioning the child on the rear seat. When your child restraint is not in use,  secure it in the vehicle with the seat belt or WARNING! ISOFIX anchorages, or remove it from the vehicle.
  • Page 272 SAFETY Suitability Of Passenger Seats For Universal Child Restraint System Use According to the European Directive 2000/3/EC, the suitability of each passenger seat position for the installation of Universal Child Restraint Systems is shown in the following table: Universal Child Seat Position Table Front Passenger Mass Group Rear Outboard...
  • Page 273 SAFETY WARNING!
  • Page 274 SAFETY Seat Belts For Older Children ISOFIX Restraint System If the answer to any of these questions was “no”, then the child still needs to use a Group Children over 1.50 m in height can wear seat 2 or 3 child restraint in this vehicle. If the child belts instead of using child restraints.
  • Page 275 SAFETY An example of a Universal ISOFIX child restraint ISOFIX child restraint systems will be equipped system for weight group 1 is shown in fig. E. with a rigid bar on each side. Each will have a ISOFIX child restraints are also available in the connector to attach to the lower anchorage and other weight groups.
  • Page 276 SAFETY Center Seat ISOFIX WARNING! This vehicle does not have center ISOFIX or  tether anchorages. This position is not approved for any type of ISOFIX child restraint system. Do not install a forward facing child seat with a tether strap in the center seating position.
  • Page 277 SAFETY Suitability Of Passenger Seats For ISOFIX Child Restraint System Use The table below shows the various installation possibilities for ISOFIX child restraint systems on seats fitted with ISOFIX anchorages in accordance with European standard ECE 16. Vehicle ISOFIX Positions Table Front Rear Outboard Intermediate...
  • Page 278 SAFETY Vehicle ISOFIX Positions Table Front Rear Outboard Intermediate Intermediate Mass Group Size Class Fixture Rear Center Other Sites Passenger Rt./Lt. Outboard Center ISO/R2 ISO/R3 ISO/F2 IUF-IL I – 9 to 18 kg ISO/F2X IUF-IL ISO/F3 IUF-IL II – 15 to 25 kg III –...
  • Page 279 SAFETY Always follow the directions of the child room for the child seat. You may also move WARNING! restraint manufacturer when installing your the front seat forward to allow more room child restraint. Not all child restraint systems for the child seat. Improper installation of a child restraint to ...
  • Page 280 SAFETY Installing Child Restraints Using The Top restraint and pass the tether strap around WARNING! the outboard side of the head restraint. Tether Anchorage: An incorrectly anchored tether strap could  3. Attach the tether strap hook of the child 1.
  • Page 281 SAFETY Suitability of Passenger Seats for i-Size Compatibility between the vehicle seats and  i-Size Child Seat Position Table the child restraint systems is better: the i-Size Child Restraint System Use Front Rear child restraint systems can be considered as Rear The rear outboard seats of the vehicle are Device...

  • Page 282: Safety Tips

    SAFETY SAFETY TIPS Air Bag Warning Light RANSPORTING Air Bags deploying in the front seat could harm The Air Bag Warning Light will turn on for four RANSPORTING ASSENGERS your pet. An unrestrained pet will be thrown to eight seconds as a bulb check when the NEVER TRANSPORT PASSENGERS IN THE about and possibly injured, or injure a ignition switch is first placed in the ON/RUN...
  • Page 283 SAFETY Floor Mat Safety Information WARNING! (Continued) WARNING! (Continued) Always use floor mats designed to fit your ONLY use the driver’s side floor mat on the ALWAYS securely attach your floor mat  vehicle. Only use a floor mat that does not ...

  • Page 284: Periodic Safety Checks You Should Make Outside The Vehicle

    SAFETY Fluid Leaks ERIODIC AFETY HECKS HOULD WARNING! (Continued) UTSIDE EHICLE Check area under the vehicle after overnight NEVER place any objects under the floor  parking for fuel, coolant, oil, or other fluid leaks. Tires mat (e.g., towels, keys, etc.). These objects Also, if gasoline fumes are detected or if fuel or could change the position of the floor mat Examine tires for excessive tread wear and...

  • Page 285: Carbon Monoxide Warnings

    SAFETY broken, damaged, deteriorated, or WARNING! (Continued) WARNING! (Continued) mispositioned parts. Open seams or loose connections could permit exhaust fumes to If you are required to drive with the trunk/ Do not inhale exhaust gases. They contain   seep into the passenger compartment. In liftgate/rear doors open, make sure that all carbon monoxide, a colorless and odorless windows are closed and the climate control...

  • Page 286: In Case Of Emergency

    IN CASE OF EMERGENCY HAZARD WARNING FLASHERS SOS/ASSIST/HELP MIRROR — IF EQUIPPED Push the switch to turn on the Hazard Warning Flashers. When the switch is activated, all The Hazard Warning Flashers switch is located directional turn signals will flash on and off to in the lower center area of the instrument warn oncoming traffic of an emergency.
  • Page 287 IN CASE OF EMERGENCY The SOS and ASSIST buttons will only func- 2. The LED light located between the SOS and  WARNING! tion if you are connected to an operable LTE ASSIST buttons on the rearview mirror will (voice/data) or 4G (data) network, which ALWAYS obey traffic laws and pay attention to turn green once a connection to a SOS comes as a built in function.
  • Page 288 IN CASE OF EMERGENCY 4. You should be able to speak with the SOS operator, the SOS operator may be able WARNING! operator through the vehicle audio system to open a voice connection with the to determine if additional assistance is vehicle to determine if additional assis- If anyone in the vehicle could be in danger ...
  • Page 289 IN CASE OF EMERGENCY The Device Screen will display the following  WARNING! (Continued) WARNING! (Continued) message “Vehicle device requires service. Please contact an authorized dealer.” The SOS/ASSIST/HELP Call system is Modifications to any part of the SOS/   embedded into the vehicle’s electrical ASSIST/HELP Call system could cause the An In-Vehicle Audio message will state...
  • Page 290 IN CASE OF EMERGENCY Even if the SOS Call system is fully functional, Weather data) or 4G (data) network connection and a  factors beyond FCA’s control may prevent or GPS signal is required for the SOS Call Buildings, structures, geographic terrain, or ...
  • Page 291 IN CASE OF EMERGENCY ASSIST Call Uconnect Customer Care - Total support for If equipped, the rearview mirror contains a  Radio, Phone and NAV issues. HELP button. The vehicle is equipped with an onboard assistance system designed to provide support The vehicle is equipped with an on-board NOTE: in the case of a vehicle malfunction.
  • Page 292 IN CASE OF EMERGENCY function. Other Uconnect services will only be NOTE: WARNING! operable if you are connected to an operable The HELP function may not be available for the LTE (voice/data) or 4G (data) network. first minute after the vehicle is started. ALWAYS obey traffic laws and pay attention to the road.
  • Page 293 IN CASE OF EMERGENCY vehicle’s HELP Call system, the operator WARNING! WARNING! (Continued) should be able to speak with you or other vehicle occupants and hear sounds If anyone in the vehicle could be in danger The SOS/ASSIST/HELP Call system is ...

  • Page 294: Jacking And Tire Changing

    IN CASE OF EMERGENCY REPARATIONS ACKING WARNING! (Continued) WARNING! (Continued) 1. Park the vehicle on a firm level surface as Modifications to any part of the SOS/ Being under a jacked-up vehicle is   far from the edge of the roadway as ASSIST/HELP Call system could cause the dangerous.

  • Page 295: Jack Location/Spare Tire Stowage

    IN CASE OF EMERGENCY 6. Block both the front and rear of the wheel OCATION PARE TOWAGE diagonally opposite the jacking position. For If equipped, the jack and tool kit bag are located example, if the right front wheel is being in the rear storage compartment.

  • Page 296: Jacking Instructions

    IN CASE OF EMERGENCY 3. Remove the alignment pin from the middle, WARNING! (Continued) rotate the jack counterclockwise, and lift it from the foam tray. Always park on a firm, level surface as far  from the edge of the roadway as possible 4.
  • Page 297 IN CASE OF EMERGENCY 4. Place the jack underneath the lift area that CAUTION! WARNING! (Continued) is closest to the flat tire. Turn the jack screw Do not attempt to raise the vehicle by jacking clockwise to firmly engage the jack saddle Only use the jack in the positions indicated ...
  • Page 298 IN CASE OF EMERGENCY 5. Raise the vehicle just enough to remove the flat tire. WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire.
  • Page 299 IN CASE OF EMERGENCY 8. Mount the spare tire. NOTE: 11. Finish tightening the wheel bolts. Push down on the wrench while at the end of the For vehicles equipped, do not attempt to  CAUTION! handle for increased leverage. Tighten the install a center cap or wheel cover on the wheel bolts in a star pattern until each Be sure to mount the spare tire with the valve...

  • Page 300: Ec Declaration Of Conformance

    IN CASE OF EMERGENCY placed in position, rotate it clockwise to lock 2. Description of machinery. 4. Authorized Person to compile the technical it in. Replace the alignment pin in the center file Generic Denomination: Pantograph jack  hole to lock the jack in place. Mr.
  • Page 301 IN CASE OF EMERGENCY German Translation...

  • Page 302: Jack Usage Precautions

    IN CASE OF EMERGENCY SAGE RECAUTIONS CAUTION! To complete the Use and Maintenance The jack is a tool designed exclusively for Handbook to which this supplement is changing a wheel, in case of a puncture or attached, given below are some instructions on damage to a tire of the vehicle on which it is fit- the proper use of the jack.

  • Page 303: Tire Service Kit - If Equipped

    IN CASE OF EMERGENCY TIRE SERVICE KIT — IF EQUIPPED Conditions Of Non-Use: Temperatures below −40°C.  Your vehicle may be equipped with a Tire Service Kit. Small punctures up to 1/4 inch On sandy or muddy ground.  (6 mm) in the tire tread can be sealed with Tire On uneven ground.
  • Page 304 IN CASE OF EMERGENCY Tire Service Kit And Components And Operation Using The Mode Select Knob And Hoses Using The Deflation Button  Your Tire Service Kit is equipped with the Push the Deflation Button to following symbols to indicate the air or sealant reduce the air pressure in the tire if mode.
  • Page 305 IN CASE OF EMERGENCY For optimum performance, make sure the  WARNING! WARNING! (Continued) valve stem on the wheel is free of debris before connecting the Tire Service Kit. Do not attempt to seal a tire on the side of Keep Tire Service Kit away from open ...
  • Page 306 IN CASE OF EMERGENCY tire and running the air pump. Move the NOTE: WARNING! (Continued) vehicle as necessary to place the valve Do not remove foreign objects (e.g., screws or stem in this position before proceeding. nails) from the tire. Tire Service Kit Sealant solution contains ...
  • Page 307 IN CASE OF EMERGENCY If the sealant (white fluid) does not flow within If the sealant (white fluid) does flow through the If the tire does not inflate to at least 26 psi 0 – 10 seconds through the Sealant Hose: Sealant Hose: (1.8 Bar) pressure within 15 minutes: The tire is too badly damaged.
  • Page 308 IN CASE OF EMERGENCY 3. Immediately disconnect the Sealant Hose After Driving: 7. Check the pressure in the tire by reading the from the valve stem, reinstall the cap on the Pressure Gauge. 1. Uncoil the Sealant Hose, and then remove fitting at the end of the hose, and place the If tire pressure is less than 19 psi (1.3 Bar): the cap from the fitting at the end of the...
  • Page 309 IN CASE OF EMERGENCY 3. Place the Tire Service Kit in its proper 4. Rotate the bottle up beyond vertical to storage area in the vehicle. release. 4. Have the tire inspected and repaired or replaced at the earliest opportunity at an authorized dealer or tire service center.

  • Page 310: Jump Starting

    IN CASE OF EMERGENCY 5. Pull the bottle away from the Compressor. and a battery in another vehicle or by using a REPARATIONS TART portable battery booster pack. Jump starting The battery in your vehicle is located in the front can be dangerous if done improperly, so please of the engine compartment, behind the left follow the procedures in this section carefully.
  • Page 311 IN CASE OF EMERGENCY See below steps to prepare for jump starting: WARNING! 1. Apply the parking brake, shift the Take care to avoid the radiator cooling fan  automatic transmission into PARK (manual whenever the hood is raised. It can start transmission in NEUTRAL) and turn the anytime the ignition switch is ON.

  • Page 312: Jump Starting Procedure

    IN CASE OF EMERGENCY 3. Connect the negative (-) end of the jumper TARTING ROCEDURE WARNING! cable to the negative (-) post of the booster battery. Do not connect the jumper cable to the WARNING! negative (-) post of the discharged battery. The 4.

  • Page 313: Refueling In Emergency - If Equipped

    IN CASE OF EMERGENCY Disconnecting The Jumper Cables NOTE: CAUTION! In certain cold conditions, ice may prevent the 1. Disconnect the negative (-) end of the Accessories plugged into the vehicle power fuel door from opening. If this occurs, lightly jumper cable from the engine ground of outlets draw power from the vehicle’s battery, push on the fuel door to break the ice buildup...

  • Page 314: If Your Engine Overheats

    IN CASE OF EMERGENCY 1. Retrieve funnel from the spare tire storage WARNING! (Continued) area. A fire may result if fuel is pumped into a  2. Insert funnel into same filler pipe opening portable container that is inside of a as the fuel nozzle.

  • Page 315: Gear Selector Override

    IN CASE OF EMERGENCY In any of the following situations, you can 3. Grab the boot material rearward of the gear WARNING! reduce the potential for overheating your selector and pull up to carefully separate engine by taking the appropriate action. You or others can be badly burned by hot the gear selector bezel and boot assembly engine coolant (antifreeze) or steam from...

  • Page 316: Freeing A Stuck Vehicle

    IN CASE OF EMERGENCY FREEING A STUCK VEHICLE 5. Insert a small screwdriver or similar tool Use the least amount of accelerator pedal down into the gear selector override access pressure that will maintain the rocking motion If your vehicle becomes stuck in mud, sand or hole (at the right rear corner of the gear without spinning the wheels or racing the snow, it can often be moved using a rocking...
  • Page 317 IN CASE OF EMERGENCY NOTE: CAUTION! CAUTION! (Continued) Push the ESC OFF switch (if necessary), to place the Electronic Stability Control (ESC) system in Racing the engine or spinning the wheels When “rocking” a stuck vehicle by shifting   may lead to transmission overheating and “Partial Off”...

  • Page 318: Towing A Disabled Vehicle

    IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The Ground FWD MODELS 4X4 MODELS Flat Tow NONE NOT ALLOWED NOT ALLOWED Rear NOT ALLOWED NOT ALLOWED Wheel Lift Or Dolly Tow...

  • Page 319: Without The Key Fob

    IN CASE OF EMERGENCY manually disable the Electric Park Brake each ITHOUT CAUTION! time the driver's door is opened by pressing the Special care must be taken when the vehicle is brake pedal and then releasing the EPB. Towing this vehicle in violation of the above towed with the ignition in the LOCK/OFF mode.

  • Page 320: Emergency Tow Hooks - If Equipped

    IN CASE OF EMERGENCY — I MERGENCY OOKS CAUTION! (Continued) QUIPPED Towing this vehicle in violation of the above  If your vehicle is equipped with tow hooks, there requirements can cause severe transmis- will be one in the rear and two mounted on the sion and/or transfer case damage.

  • Page 321: Tow Eye Usage - If Equipped

    IN CASE OF EMERGENCY — I the aid of the power brakes and the electrome- Tow Eye Usage Precautions SAGE QUIPPED chanical power steering will require greater Your vehicle is equipped with a tow eye that can CAUTION! force when applying the brakes and steering of be used to move a disabled vehicle.
  • Page 322 IN CASE OF EMERGENCY To install the tow eye, open the door using the WARNING! (Continued) vehicle key or a small screwdriver, and thread the tow eye into the receptacle. Failure to follow proper tow eye usage may  cause components to break resulting in Insert the flat end of the jack handle through serious injury or death.

  • Page 323: Enhanced Accident Response System

    IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM Rear Tow Eye The rear tow eye receptacle is located behind a (EARS) door, located on the right rear fascia/bumper. This vehicle is equipped with an Enhanced To install the tow eye, open the door using the Accident Response System.

  • Page 324: Servicing And Maintenance

    SERVICING AND MAINTENANCE SCHEDULED SERVICING Refer to the “Service And Warranty Handbook” for scheduled servicing.

  • Page 325: Engine Compartment

    SERVICING AND MAINTENANCE ENGINE COMPARTMENT 1.4L E NGINE 1 — Brake Fluid Reservoir Cap 5 — Power Distribution Center (Fuses) 2 — Engine Oil Dipstick 6 — Engine Air Cleaner Filter 3 — Engine Oil Fill Cap 7 — Engine Coolant Pressure Cap 4 —...

  • Page 326: L Diesel Engine

    SERVICING AND MAINTENANCE 2.0L D IESEL NGINE 1 — Brake Fluid Reservoir Cap 5 — Engine Air Cleaner Filter 2 — Engine Oil Fill 6 — Engine Oil Dipstick 3 — Battery 7 — Engine Coolant Pressure Cap 4 — Power Distribution Center (Fuses) 8 —...

  • Page 327: Checking Oil Level

    SERVICING AND MAINTENANCE NOTE: When refilling the washer fluid reservoir, take HECKING EVEL Always maintain the oil level within the cross- some washer fluid, apply it to a cloth or towel, To ensure proper engine lubrication, the engine hatch markings on the dipstick. and wipe clean the wiper blades;...
  • Page 328 SERVICING AND MAINTENANCE inspected and topped up every six months. CAUTION! WARNING! (Continued) Have the vehicle battery inspected by an authorized dealer. It is essential when replacing the cables on Battery fluid is a corrosive acid solution and   the battery that the positive cable is can burn or even blind you.

  • Page 329: Pressure Washing

    SERVICING AND MAINTENANCE American Petroleum Institute (API) Engine NOTE: RESSURE ASHING Intentional tampering with emissions control Oil Identification Symbol Cleaning the engine compartment with a high systems may void your warranty and could This symbol means that the oil has pressure washer is not recommended.

  • Page 330: Engine Oil - Diesel Engine

    SERVICING AND MAINTENANCE — D Synthetic engine oils which do not have both the NOTE: NGINE IESEL NGINE engine oil certification mark and the correct SAE Be sure to follow the “Severe Duty Conditions” Engine Oil Selection — Diesel Engine viscosity grade number should not be used.

  • Page 331: Air Conditioner Maintenance

    SERVICING AND MAINTENANCE recommends that air conditioning service be ONDITIONER AINTENANCE WARNING! (Continued) performed by an authorized dealer or other For best possible performance, your air service facilities using recovery and recycling The air conditioning system contains refrig-  conditioner should be checked and serviced by equipment.

  • Page 332: Body Lubrication

    SERVICING AND MAINTENANCE Cabin Air Filter The external lock cylinders should be lubricated Keep the wiper blade out of contact with twice a year, preferably in the Autumn and petroleum products such as engine oil, Refer to the “Service And Warranty Handbook” Spring.
  • Page 333 SERVICING AND MAINTENANCE 1. Lift the wiper arm to raise the wiper blade 2. To disengage the wiper blade from the wiper 3. Tilt the lower end of the wiper blade away off of the glass, until the wiper arm is in the arm, flip up the locking tab.
  • Page 334 SERVICING AND MAINTENANCE 4. Slide the wiper blade down towards the Installing The Front Wipers base of the wiper arm. 1. Lift the wiper arm off of the glass, until the 5. With the wiper blade disengaged, remove wiper arm is in the full up position. the wiper blade from the wiper arm by 2.

  • Page 335: Exhaust System

    SERVICING AND MAINTENANCE XHAUST YSTEM WARNING! CAUTION! The best protection against carbon monoxide Exhaust gases can injure or kill. They contain The catalytic converter requires the use of   entry into the vehicle body is a properly carbon monoxide (CO), which is colorless unleaded fuel only.

  • Page 336: Cooling System

    SERVICING AND MAINTENANCE Under normal operating conditions, the To minimize the possibility of catalytic converter OOLING YSTEM catalytic converter will not require damage: maintenance. However, it is important to keep WARNING! Do not interrupt the ignition when the trans-  the engine properly tuned to ensure proper mission is in gear and the vehicle is in You or others can be badly burned by hot...
  • Page 337 SERVICING AND MAINTENANCE Coolant Checks dealer clean and flush with Organic Additive refilled with fresh OAT coolant (conforming to Technology (OAT) coolant (conforming to MS.90032), by a3 Check engine coolant (antifreeze) protection MS.90032). every 12 months (before the onset of freezing authorized dealer as soon as possible.
  • Page 338 SERVICING AND MAINTENANCE Adding Coolant Material Standard MS.90032 and distilled Mixing engine coolant types is not recom-  water. Use higher concentrations (not to mended and can result in cooling system Your vehicle has been built with an improved exceed 70%) if temperatures below −34°F damage.
  • Page 339 SERVICING AND MAINTENANCE in puddles on the ground, clean up any ground ment. This is normally a result of moisture from WARNING! spills immediately. If ingested by a child or pet, rain, snow, or high humidity accumulating on Do not open hot engine cooling system. seek emergency assistance immediately.

  • Page 340: Brake System

    SERVICING AND MAINTENANCE Brake Master Cylinder If frequent engine coolant additions are RAKE YSTEM  required, the cooling system should be pres- The fluid in the master cylinder should be In order to ensure brake system performance, sure tested for leaks. checked when performing under hood services all brake system components should be or immediately if the “Brake Warning Light”...

  • Page 341: Manual Transmission - If Equipped

    SERVICING AND MAINTENANCE Add fluid, if necessary, to maintain the proper WARNING! WARNING! (Continued) level. Use only manufacturer's recommended Overfilling the brake fluid reservoir can   Please see an authorized dealer for service. brake fluid Ú page 386. Using the wrong result in spilling brake fluid on hot engine Frequency Of Fluid Change type of brake fluid can severely damage...

  • Page 342: Automatic Transmission - If Equipped

    SERVICING AND MAINTENANCE — I Fluid Level Check Fluid And Filter Changes UTOMATIC RANSMISSION QUIPPED The fluid level is preset at the factory and does Under normal operating conditions, the fluid not require adjustment under normal operating installed at the factory will provide satisfactory Special Additives conditions.

  • Page 343: Fuses

    SERVICING AND MAINTENANCE Also, please be aware that when using power CAUTION! WARNING! (Continued) outlets for extended periods of time with the Using a transmission fluid other than the man- engine off may result in vehicle battery Before replacing a fuse, make sure that the ...
  • Page 344 SERVICING AND MAINTENANCE Fuse Location Power Distribution Center/Fuses The fuses are grouped into controllers located The Front Power Distribution Center is located in the engine compartment. in the engine compartment. This module contains fuses and relays. Fuse cavity location are printed on the inside of the power distribution center cover.
  • Page 345 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description BCM Feed 3 / (Run/Start & FB Relay and /Start/Stop & FB Relay 20 Amp – in BCM) 40 Amp – BSM Pump 40 Amp – BSM Valves 40 Amp – Diesel Filter Heater Diesel vehicles only 40 Amp –...
  • Page 346 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description 25 Amp Engine Control Module (ECM) / Fuel Injectors / SNSR GPF EGT – 20 Amp 1.4L gas application* – 7.5 Amp Blow By Heater (Diesel) F29A & B – – Spare –...
  • Page 347 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description Powertrain Control Module (PCM) / Purge Solenoid / Surge – 10 Amp Solenoid / Wastegate Solenoid / 02 Sensor Upstream & Downstream 1.4L (Gas Engine) – 10 Amp ECM/TCM/AGSM/DCSM/STM/Fuel Pump Relay Coil –...
  • Page 348 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description – 5 Amp Drive Train Control Module (DTCM) ECU Power – 20 Amp NOX SNSR Feed (Diesel Engine) Automatic Gearbox Shifter Module (AGSM) (Diesel & Gas) / Dual – 5 Amp Clutch Shifter Module (DCSM) (Gas Engine) Dual Clutch Transmission Module (DCTM) Supply 1 (Gas Engine) –...
  • Page 349 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description MOD DCSD / ACT Grille Shutter / Handsfree Liftgate / UCI + USB – 10 Amp Port / HRLS – 20 Amp Horn – 20 Amp Cigar Lighter* – 10 Amp Engine Control Module (ECM) * If Equipped Interior Fuses...
  • Page 350 SERVICING AND MAINTENANCE Cavity Blade Fuse Description 20 Amp Yellow Door Lock/Unlock, Liftgate Release 7.5 Amp Brown Brake System Module, Electric Power Steering 20 Amp Yellow Washer Pump Front And Rear 20 Amp Yellow Rear Left Window Lifter 20 Amp Yellow Rear Right Window Lifter Park Assist, Blind Spot, Voltage Stabilizer, Humidity Sensor, Electronic 7.5 Amp Brown...
  • Page 351 SERVICING AND MAINTENANCE Rear Cargo Fuse/Relay Distribution Unit -If Fuse Holder No. 1 Equipped Cavity Mini Fuse Description To access the fuses, remove the access door 30 Amp Memory Seat from the left rear panel of the rear cargo area. Green 20 Amp The fuses may be contained in two units.

  • Page 352: Bulb Replacement

    SERVICING AND MAINTENANCE BULB REPLACEMENT On the Rear Cargo Fuse/Relay Distribution Unit ATO / Cavity Description bracket, there is a Maxi Fuse holder for the Uni-Val Fuse Replacement Bulbs Power Liftgate and an ATO / Uni Val fuse holder 25 Amp Clear HIFI Audio System* for the HIFI Audio System.
  • Page 353 SERVICING AND MAINTENANCE Exterior Bulbs Lamps Bulb Number Low Beam Headlamps LED (Serviced at an authorized dealer) High Beam Headlamps LED (Serviced at an authorized dealer) Front Position/Daytime Running Lights (DRL ) LED (Serviced at an authorized dealer) Base:WY21W Front Direction Indicator Lamps Premium: LED (Serviced at an authorized dealer) Front Position LED (Serviced at an authorized dealer)
  • Page 354 SERVICING AND MAINTENANCE Exterior Bulbs Lamps Bulb Number Liftgate Lamp Reverse W21WLL Liftgate Lamp Tail LED (Serviced at an authorized dealer) Replacing Exterior Bulbs 5. Install the bulb and sockets and rotate them Rear Body Side Tail Lamps clockwise making sure that it is properly Turn Signal Light Contain the following: locked.
  • Page 355 SERVICING AND MAINTENANCE To replace the bulbs proceed as follows: 9. Reinstall the body side lamp making sure to align the ball studs. 1. Open the liftgate. NOTE: 2. Using a suitable tool remove fasteners. Ensure uniform gap between body and lamp assembly.
  • Page 356 SERVICING AND MAINTENANCE 10. Install fasteners and tighten body side lamp Reverse Lamps 4. Remove bulb and replace making sure it is assembly. properly locked. 1. Open the liftgate. 11. Finally close the tailgate. 5. Reconnect the electrical connector. 2. Using a suitable tool remove the access panel for body side lamps, remove liftgate 6.
  • Page 357 SERVICING AND MAINTENANCE Replacing Interior Bulbs 2. Release the retainer clips and bulb housing WARNING! (Continued) as shown. Front Courtesy Light Halogen lamps must be handled by  To replace the bulbs proceed as follows: touching only the metallic part. If the trans- parent bulb is in contact with the fingers, it 1.
  • Page 358 SERVICING AND MAINTENANCE 3. Replace the bulbs by pulling straight out of 5. Reassemble the bulb housing and courtesy bulb housing. light housing making sure that they are properly locked. 6. Install the front courtesy light, making sure that it is properly locked. Dome Light Vanity Mirror —...
  • Page 359 SERVICING AND MAINTENANCE Dome Light Glove Compartment Dome Light To replace the bulb proceed as follows: To replace the bulbs proceed as follows: 1. Open the glove compartment. 1. Lower the handle in the direction shown; remove the dome light. 2.
  • Page 360 SERVICING AND MAINTENANCE Interior Cargo Lights WARNING! To replace the bulbs proceed as follows: Modifications or repair of the electrical  1. Using thumb with slight pressure – push system performed incorrectly and without bulb holder to the side. taking into account the technical character- istics can cause malfunctions with the risk of fire.

  • Page 361: Tires

    SERVICING AND MAINTENANCE TIRES Tire Markings Tire Loading And Tire Pressure NOTE: AFETY NFORMATION The proper cold tire inflation pressure is listed Tire safety information will cover aspects of the on the driver’s side B-pillar or the rear edge of following information: Tire Markings, Tire the driver's side door.

  • Page 362: Tires - General Information

    SERVICING AND MAINTENANCE This placard tells you important information NOTE: about the: Under a maximum loaded vehicle condition, gross axle weight ratings (GAWRs) for the front 1. Number of people that can be carried in and rear axles must not be exceeded. the vehicle.
  • Page 363 SERVICING AND MAINTENANCE Safety Fuel Economy WARNING! (Continued) Underinflated tires will increase tire rolling WARNING! Unequal tire pressures from one side of the  resistance resulting in higher fuel consumption. vehicle to the other can cause the vehicle Improperly inflated tires are dangerous and ...
  • Page 364 SERVICING AND MAINTENANCE Tire Pressures For High Speed Operation At least once a month: cold tire inflation pressure must not exceed the maximum inflation pressure molded into the Check and adjust tire pressure with a good The manufacturer advocates driving at safe ...
  • Page 365 SERVICING AND MAINTENANCE Radial Ply Tires Consult an authorized tire dealer for tire repairs after driving with underinflated tire condition, and additional information. please replace the TPM sensor as it is not WARNING! designed to be reused when driven under Run Damaged Run Flat tires, or Run Flat tires that Flat mode 14 psi (96 kPa) condition.
  • Page 366 SERVICING AND MAINTENANCE Life Of Tire WARNING! The service life of a tire is dependent upon Fast spinning tires can be dangerous. Forces varying factors including, but not limited to: generated by excessive wheel speeds may Driving style.  cause tire damage or failure. A tire could explode and injure someone.
  • Page 367 SERVICING AND MAINTENANCE equivalent to the originals in size, quality and WARNING! WARNING! performance when replacement is needed Tires and the spare tire should be replaced Ú page 365. Refer to the Tire and Loading Do not use a tire, wheel size, load rating, or ...

  • Page 368: Tire Types

    SERVICING AND MAINTENANCE sidewall. Use all season tires only in sets of four; WARNING! WARNING! (Continued) failure to do so may adversely affect the safety and handling of your vehicle. Do not use Summer tires in snow/ice Failure to equip your vehicle with tires ...

  • Page 369: Spare Tires - If Equipped

    SERVICING AND MAINTENANCE Compact Spare Tire — If Equipped Snow tires generally have lower speed ratings CAUTION! than what was originally equipped with your The compact spare is for temporary emergency vehicle and should not be operated at Because of the reduced ground clearance, do use only.
  • Page 370 SERVICING AND MAINTENANCE Full Size Spare — If Equipped Do not install a wheel cover or attempt to mount replace (or repair) the original equipment tire a conventional tire on the compact spare wheel, and reinstall on the vehicle at the first The full size spare is for temporary emergency since the wheel is designed specifically for the opportunity.

  • Page 371: Tire Rotation Recommendations

    SERVICING AND MAINTENANCE STORING THE VEHICLE OTATION ECOMMENDATIONS The tires on the front and rear of your vehicle If the vehicle should remain stationary for more operate at different loads and perform different than a month, observe the following steering, handling, and braking functions. For precautions: these reasons, they wear at unequal rates.

  • Page 372: Bodywork

    SERVICING AND MAINTENANCE BODYWORK system, thus minimizing the possibility of What Causes Corrosion? damage to the compressor when the vehicle Corrosion is the result of deterioration or is put back into operation. ROTECTION TMOSPHERIC removal of paint and protective coatings from GENTS your vehicle.

  • Page 373: Body And Underbody Maintenance

    SERVICING AND MAINTENANCE NDERBODY AINTENANCE CAUTION! CAUTION! Wheel And Wheel Trim Care Avoid products or automatic car washes that Do not use scouring pads, steel wool, a bristle All wheels and wheel trim, especially aluminum use acidic solutions or strong alkaline brush, metal polishes or oven cleaner.

  • Page 374: Preserving The Bodywork

    SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or To minimize the possibility of scratching the Avoid using abrasive compounds and power  Low Gloss Clear Coat Wheels lenses and reducing light output, avoid wiping buffing that may diminish the gloss or thin out the paint finish.

  • Page 375: Interiors

    SERVICING AND MAINTENANCE vehicle slowly and apply the brakes several Use Mopar® Touch Up Paint on scratches as Remove as much of the stain as possible by   times. This activity will remove red oxidation soon as possible. An authorized dealer has blotting with a clean, dry towel.

  • Page 376: Plastic And Coated Parts

    SERVICING AND MAINTENANCE If the belts need cleaning, use a mild soap Clean with a wet soft cloth. A mild soap solution LASTIC OATED ARTS solution or lukewarm water. Do not remove the may be used, but do not use high alcohol Use Mopar®...

  • Page 377: Glass Surfaces

    SERVICING AND MAINTENANCE NOTE: LASS URFACES CAUTION! If equipped with light colored leather, it tends to All glass surfaces should be cleaned on a show any foreign material, dirt, and fabric dye Do not use Alcohol and Alcohol-based and/or regular basis with Mopar® Glass Cleaner, or transfer more so than darker colors.

  • Page 378: Technical Specifications

    TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) The VIN is found on the left front corner of the windshield and is visible from the outside of the vehicle. The VIN number also is stamped into the right front body, on the front floor. With the right front seat in the rear most position, a door in the carpet can be opened to reveal the VIN.

  • Page 379: Brake System

    TECHNICAL SPECIFICATIONS WHEEL AND TIRE TORQUE SPECIFICATIONS If either of the two hydraulic systems lose normal capability, the remaining system will still Proper lug nut/bolt torque is very important to function with some loss of overall braking ensure that the wheel is properly mounted to effectiveness.

  • Page 380: Fuel Requirements - Gasoline Engine

    TECHNICAL SPECIFICATIONS Inspect the wheel mounting surface prior to CAUTION! mounting the tire and remove any corrosion or loose particles. Do not use pneumatic wrench to tighten the wheel bolts. This may overtighten the wheel bolts and damage the chrome caps of the wheel nut.

  • Page 381: L Engine

    TECHNICAL SPECIFICATIONS 1.4L E E-85 U NGINE SAGE WARNING! EHICLES This engine is designed to meet all emission Do not use gasolines containing methanol. regulations and provide satisfactory fuel Non-Flex Fuel Vehicles (FFV) are compatible Use of these blends may result in starting and economy and performance when using with gasoline containing up to 15% ethanol drivability problems and may damage critical...

  • Page 382: Materials Added To Fuel

    TECHNICAL SPECIFICATIONS CNG or LP are not the responsibility of FCA and ATERIALS DDED CAUTION! may void the New Vehicle Limited Warranty. Besides using unleaded gasoline with the DO NOT use E-85, gasoline containing YSTEM AUTIONS proper octane rating, gasolines that contain methanol, or gasoline containing more than detergents, corrosion and stability additives are 15% ethanol (E-15).

  • Page 383: Fuel Requirements - Diesel Engine

    TECHNICAL SPECIFICATIONS paraffin clots with consequent defective WARNING! CAUTION! (Continued) operation of the fuel supply system. Do not use alcohol or gasoline as a The use of fuel additives, which are now being  In order to avoid these problems different types sold as octane enhancers, is not recom- fuel-blending agent.

  • Page 384: Fluid Capacities

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) All Engines 15.9 Gallons 60 Liters AdBlue® (UREA) Fluid Tank — If Equipped 3.4 Gallons 13 Liters Engine Oil With Filter 1.4L Gasoline Engine 4.0 Quarts 3.8 Liters 2.0L Diesel Engine 5.1 Quarts 4.8 Liters Cooling System* 1.4L Gasoline Engine...

  • Page 385: Engine Fluids And Lubricants

    TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar® Antifreeze/Coolant 10 Year/ 150,000 mile (240,000 kilometers) Formula OAT (Organic Additive Engine Coolant Technology) meeting the requirements of FCA Material Standard MS.90032. We recommend you use 0W-30 ACEA C2 – FCA 9.55535-GS1 synthetic Engine Oil –...
  • Page 386 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other This vehicle has not been designed for use   than specified Organic Additive Technology with propylene glycol-based engine coolant. (OAT) engine coolant, may result in engine Use of propylene glycol-based engine damage and may decrease corrosion coolant is not recommended.

  • Page 387: Chassis Fluids And Lubricants

    TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar® C Series Manual & Dual Dry Clutch Manual Transmission – If Equipped Transmission Fluid. Use only Mopar® AW-1 Automatic Transmission Fluid or equivalent. Automatic Transmission 6 Speed (FWD Models) –...
  • Page 388 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar® Rear Axle/RDM Synthetic Axle Rear Differential (RDM) – If Equipped Lubricant SAE 75W-90 (API GL-5). We recommend you use Mopar® DOT 4. If DOT 4 brake fluid is not available, then DOT 3 is acceptable.

  • Page 389: Customer Assistance

    CUSTOMER ASSISTANCE IF YOU NEED ASSISTANCE When you contact the distributor please provide Selling and servicing authorized dealer.  all of the following information: Vehicle's delivery date and current odometer  FCA’s distributors are vitally interested in your Your name, address and phone number. ...

  • Page 390: Argentina

    CUSTOMER ASSISTANCE ARGENTINA AUSTRIA Dodge Customer Service*  Universal Toll Free Number FCA Automobiles Argentina S.A. Jeep® Customer Service*   Tel: 00 800 36343 000 Carlos Maria Della Paolera 299, Piso 25 Universal Toll Free Number  Local Toll Free Number Tel: 00 800 0 426 5337 ...

  • Page 391: Belgium

    CUSTOMER ASSISTANCE BELGIUM BRAZIL Dodge Customer Service*  Universal Toll Free Number Jeep® Customer Service* FCA FIAT CHRYSLER AUTOMÓVEIS BRASIL LTDA   Tel: 00 800 36343 000 Avenida Engenheiro Luís Carlos Berrini, Universal Toll Free Number  Local Toll Free Number 105 –...

  • Page 392: Chile

    CUSTOMER ASSISTANCE CHILE COLOMBIA CROATIA Comercial Chrysler S.A. Chrysler Colombia S.A. Autocommerce Hrvatska d.o.o. Av. Americo Vespucio 1601, Quilicura Avenida Calle 26 # 70A-25 Jablanska 80 Santiago, Chile Zip Code 110931 10 000 Zagreb Zip Code 101931-7, 367-V Bogotá Colombia Tel: 00 385 1 3869 001 Tel.: +562 837 1300 Tel: +57 1 745 5777...

  • Page 393: Czech Republic

    CUSTOMER ASSISTANCE CZECH REPUBLIC DENMARK Dodge Customer Service*  Universal Toll Free Number Jeep® Customer Service* Jeep® Customer Service*    Tel: 00 800 36343 000 Universal Toll Free Number Universal Toll Free Number   Local Toll Free Number...

  • Page 394: Ecuador

    CUSTOMER ASSISTANCE ECUADOR ESTONIA FINLAND Corporacion Maresa, Distrivehic Silberauto AS Jeep® Customer Service*  Avenida De los Granados E11-67 Järvevana tee 11 Universal Toll Free Number  Tel: 00 800 0 426 5337 Quito, Ecuador 11314 Tallinn International Toll Number Tel.: +593 1800 627 372...

  • Page 395: France

    CUSTOMER ASSISTANCE FRANCE Dodge Customer Service* Chrysler Customer Service*   Universal Toll Free Number Universal Toll Free Number Jeep® Customer Service*    Tel: 00 800 36343 000 Tel: 00 800 1692 1692 Universal Toll Free Number ...

  • Page 396: Greece

    CUSTOMER ASSISTANCE GREECE HONDURAS Dodge Customer Service*  Universal Toll Free Number Chrysler Jeep® Dodge Hellas Grupo Q de Honduras  Tel: 81 10 10 80 240-242 Kifisias Avenue Blvd. Centro América frente a Plaza Miraflores, International Toll Number ...

  • Page 397: Ireland

    CUSTOMER ASSISTANCE IRELAND Dodge Customer Service* Chrysler Customer Service*   Universal Toll Free Number Universal Toll Free Number Jeep® Customer Service*    Tel: 00 800 36343 000 Tel: 00 800 1692 1692 Universal Toll Free Number ...

  • Page 398: Latvia

    Dodge Customer Service*  LUXEMBURG SIA “Autobrava” Universal Toll Free Number  G.Astras street 5, Jeep® Customer Service* Tel: 00 800 36343 000  LV-1084 Riga Local Toll Free Number Universal Toll Free Number   Tel.: +371 67812312...

  • Page 399: Netherlands

    CUSTOMER ASSISTANCE NETHERLANDS NEW ZEALAND PANAMA Jeep® Customer Service* Chrysler New Zealand Automotora Autostar S. A.  Private Bag 14907 Avenida Domingo Diaz, Via Tocumen, Frente a Universal Toll Free Number  la Urbanizacion El Crisol Tel: 00 800 0 426 5337 Panmure New Zealand Panamá, Panamá...

  • Page 400: Peru

    Tel: 00 800 3 634 3000 FCA Caribbean LLC Tel: +48 (033) 813-21-00, 813-51-00 International Toll Number P.O. Box 191857  Jeep® Customer Service*  Not Available San Juan 00919-1857 Universal Toll Free Number  Tel: 00 800 0 426 5337...

  • Page 401: Reunion

    CUSTOMER ASSISTANCE REUNION RUSSIA SERBIA COTRANS AUTOMOBILES Jeep® Customer Service* Jeep® Customer Service*   17 Bd du Chaudron, 97490 Sainte Clotilde Universal Toll Free Number Universal Toll Free Number   Tel: 88 001 00 8182 Tel: 0800 120120...

  • Page 402: Slovakia

    CUSTOMER ASSISTANCE SLOVAKIA SLOVENIA Chrysler Customer Service*  Universal Toll Free Number Jeep® Customer Service* Avto Triglav d.o.o.   Tel: 8066727869 Dunajska 122 Universal Toll Free Number  International Toll Number Tel: 800 900 001  1000 Ljubljana Tel: +27102525000...

  • Page 403: Spain

    CUSTOMER ASSISTANCE SPAIN Dodge Customer Service* Chrysler Customer Service*   Universal Toll Free Number Universal Toll Free Number Jeep® Customer Service*    Tel: 00 800 36343 000 Tel: 00 800 1692 1692 Universal Toll Free Number ...

  • Page 404: Switzerland

    CUSTOMER ASSISTANCE SWITZERLAND TURKEY Dodge Customer Service*  Universal Toll Free Number Jeep® Customer Service* Tofaş Türk Otomobil Fabrikasi A.S.   Tel: 00 800 36343 000 Büyükdere Cad, No:145 Tofaş Han Zincirlikuyu Universal Toll Free Number  Local Toll Free Number Tel: 00 800 0 426 5337 ...

  • Page 405: United Kingdom

    CUSTOMER ASSISTANCE UNITED KINGDOM Local Toll Free Number Fax: +(58) 241-613 2538  Tel: 0800 1692956 Fax: (58) 241-6132602 Jeep® Customer Service*  International Toll Number  (58) 241-6132438 Universal Toll Free Number  Tel: Not Available Tel: 00 800 0 426 5337...

  • Page 406: Index

    INDEX ......... 330 ........148 Air Conditioner System Automatic Transaxle ........170 ......66 ........ 150 Active Speed Limiter Air Conditioning Filter Automatic Transmission ....337 .......65 ........341 Adding Engine Coolant (Antifreeze) Air Conditioning, Operating Tips Adding Fluid ............187 ............329 ......341 Adding Fuel Air Filter Fluid And Filter Change...
  • Page 407 ....225 ..........222 ......336 Brake Control System, Electronic Cellular Phone Drain, Flush, And Refill ............386 ......... 192 ..........338 Brake Fluid Certification Label Inspection ........339 ........101 ........ 338 Brake System Change Oil Indicator Points To Remember ........339 ........
  • Page 408 ..........319 ........283 Dipsticks Tow Hooks Exhaust System ..........326 ............317 ..........49 Oil (Engine) Towing Exterior Lighting ........317 ............324 ........49 Disabled Vehicle Towing Engine Exterior Lights ..........329 Disposal Air Cleaner .......338 ..... 139 Antifreeze (Engine Coolant) Break-In Recommendations ..........
  • Page 409 ..........37 Fold-Flat Seats .......... 39 ......285 .............25 Folding Rear Seats Hazard Warning Flashers Ignition .........315 ..........43 ............25 Freeing A Stuck Vehicle Head Restraints Switch ............. 379 ............43 ......46 Fuel Head Rests Inside Rearview Mirror ...........381 ............49 .....87 Additives Headlights Instrument Cluster...
  • Page 410 ..........283 Leaks, Fluid Diesel Particulate Filter (DPF) Cleaning ..........294 ........... 365 ........... 126 Jack Location Life Of Tires In Progress ........293 ............. 78 ....49 Jack Operation Liftgate Dimmer Switch, Headlight ........295 .......56 ..........119 Jacking Instructions Liftgate Window Wiper/Washer Door Open ..........309 ............
  • Page 411 ........53 ..124 Intensity Control Tire Pressure Monitoring (TPMS) ............53 ......126 ............77 Interior Towing Hook Breakdown Maintenance ..........128 ........230 ......326 LaneSense Traction Control Maintenance Free Battery ..........120 ........121 .. 123 Liftgate Open Transmission Fault Malfunction Indicator Light (Check Engine) ......
  • Page 412 ........131 Operating Precautions ......139 ..........364 New Vehicle Break-In Period Outlet Radial Ply Tires ............69 .... 337 Power Radiator Cap (Coolant Pressure Cap) ......46 ..........222 Outside Rearview Mirrors Radio Operation ........238 ........313 ......... 222 Occupant Restraints Overheating, Engine Radio Remote Controls ....
  • Page 413 ......246 ........... 368 Seat Belt Pretensioner Spare Tires ......281 ....... 244 Safety Checks Inside Vehicle Untwisting Procedure Specifications ......283 ....... 374 .......... 384 Safety Checks Outside Vehicle Seat Belts Maintenance Fuel (Gasoline) .........360 ...............37 ............ 329 Safety Information, Tire Seats .............281 ..........37...
  • Page 414 ........... 74 ............. 293 Sun Roof Jacking Transaxle ............47 ..........365 ..........148 Sun Visor Life Of Tires Automatic ..248 ........360 ..........148 Supplemental Restraint System – Air Bag Load Capacity Operation ........328 ..........150 Synthetic Engine Oil Pressure Monitoring System Transmission ........
  • Page 415 ........329 ..........74 ......54 Viscosity, Engine Oil Wind Buffeting Windshield Washers ..........44 ..........66 ............326 Voice Command Window Fogging Fluid ......44 ............72 ......331 Voice Recognition System (VR) Windows Windshield Wiper Blades ............72 ...........54 Close Windshield Wipers ............72 ......

Table of Contents

Save PDF
