U S ER GUIDE
2015
Compass

Advertisement

Table of Contents
loading

Related Manuals for Jeep Compass

Summary of Contents for Jeep Compass

  • Page 1 U S ER GUIDE 2015 Compass...
  • Page 2 If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/ Uconnect® Manuals or Warranty Booklet by calling 1-877-426-5337 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer. The driver’s primary responsibility is the safe operation of the vehicle.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION/WELCOME OFF-ROAD CAPABILITIES WELCOME FROM FCA US LLC ..2 FOUR-WHEEL DRIVE OPERATION . . . 78 CONTROLS AT A GLANCE UTILITY DRIVER COCKPIT ....6 TRAILER TOWING WEIGHTS (MAXIMUM INSTRUMENT CLUSTER .

  • Page 4: Introduction/Welcome

    INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles. Your new FCA US LLC vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 5 INTRODUCTION/WELCOME VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.
  • Page 6 INTRODUCTION/WELCOME Rollover Warning WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury. • Always make sure that objects cannot fall into the driver foot well while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control.
  • Page 7 If your symptoms persist, please see an authorized dealer. CHRYSLER, DODGE, JEEP, RAM, MOPAR and Uconnect are registered trademarks of FCA US LLC. COPYRIGHT ©2016 FCA US LLC...

  • Page 8: Controls At A Glance

    CONTROLS AT A GLANCE DRIVER COCKPIT 1. Electronic Vehicle Information Center (EVIC) Controls pg. 70 2. Turn Signal/Lights Lever (behind steering wheel) pg. 28 3. Electronic Vehicle Information Center (EVIC) Display 4. Instrument Cluster pg. 8 5. Speed Control pg. 31 6.
  • Page 9 CONTROLS AT A GLANCE 11. Glove Compartment 12. Power Outlet pg. 77 13. Shift Lever pg. 33 14. Switch Panel • Heated Seat Switches pg. 26 • Electronic Stability Control (ESC) OFF pg. 87 • Hazard Switch 15. Tilt Steering Column pg. 27 16.

  • Page 10: Instrument Cluster

    CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Fuel Filler Door Location 2. Fuel Gauge 3. Speedometer (See page 82 for Instrument Cluster Warning Light information.)
  • Page 11 CONTROLS AT A GLANCE 4. Tachometer 5. Engine Temperature Gauge 6. Gear Selection Display (See page 87 for Instrument Cluster Indicator Light information.)

  • Page 12: Getting Started

    GETTING STARTED KEY FOB Locking And Unlocking The Doors And Liftgate Lock The Doors And Liftgate Push and release the LOCK button on the RKE transmitter to lock all doors and liftgate. The turn signal lights will flash, and the horn will chirp to acknowledge the signal.
  • Page 13 GETTING STARTED Panic Alarm To turn the Panic Alarm feature ON or OFF, push and hold the PANIC button on the RKE transmitter for at least one second and release. When the Panic Alarm is on, the headlights and park lights will flash, the horn will pulse on and off and the interior lights will turn on.

  • Page 14: Remote Start

    GETTING STARTED REMOTE START NOTE: The vehicle must be equipped with an automatic transmission to be equipped with Remote Start. • Push the REMOTE START button on the Key Fob twice within five seconds. Pushing the REMOTE START button a third time shuts the engine off. •...

  • Page 15: Vehicle Security Alarm

    GETTING STARTED VEHICLE SECURITY ALARM The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the Keyless Enter-N-Go™ START/STOP button for unauthorized operation. While the Vehicle Security Alarm is armed, interior switches for door locks and decklid release are disabled.

  • Page 16: Seat Belt Systems

    GETTING STARTED SEAT BELT SYSTEMS Lap/Shoulder Belts • All seating positions in your vehicle are equipped with lap/shoulder belts. • Be sure everyone in your vehicle is in a seat and using a seat belt properly. • Position the lap belt so that it is snug and lies low across your hips, below your abdomen.

  • Page 17: Supplemental Restraint System (Srs) - Air Bags

    GETTING STARTED SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS Air Bag System Components Your vehicle may be equipped with the following air bag system components: • Occupant Restraint Controller (ORC) • Air Bag Warning Light • Steering Wheel and Column •...
  • Page 18 GETTING STARTED • The ORC turns on the Air Bag Warning Light in the instrument panel for approximately four to eight seconds for a self-check when the ignition switch is first turned to the ON/RUN position. After the self-check, the Air Bag Warning Light will turn off.
  • Page 19 GETTING STARTED Supplemental Side Air Bags • This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags (SABs) located in the outboard side of the front seats. The SABs are marked with a SRS AIRBAG or AIRBAG label sewn into the outboard side of the seats. •...

  • Page 20: Child Restraints

    GETTING STARTED CHILD RESTRAINTS Children 12 years or younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
  • Page 21 GETTING STARTED Locating LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seatback and seat cushion.
  • Page 22 GETTING STARTED Installing The Child Restraint Using The LATCH Lower Anchors NOTE: Never “share” a LATCH anchorage with two or more child restraints. 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
  • Page 23 GETTING STARTED 7. If the child restraint has a top tether strap and the seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether strap. See below for directions to attach a tether anchor. 8.

  • Page 24: Head Restraints

    GETTING STARTED WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are. The child and others could be severely injured or killed.

  • Page 25: Front Seats

    GETTING STARTED To remove the head restraint, raise it as far as it can go then push the adjustment button and the release button at the base of each post while pulling the head restraint up. To reinstall the head restraint, put the head restraint posts into the holes and push downward.
  • Page 26 GETTING STARTED Manual Seat Adjustment Forward/Rearward • Lift up on the adjusting bar located at the front of the seat near the floor and release it when the seat is at the desired position. Then, using body pressure, move forward and backward on the seat to be sure that the seat adjusters have latched.

  • Page 27: Rear Seats

    GETTING STARTED Lumbar Support • The lumbar lever is on the inboard side of the seatback. Rotate the lumbar lever downward to increase the lumbar support or upward to decrease the lumbar support as desired. Lumbar Support Lever REAR SEATS Folding Rear Seatback •...

  • Page 28: Heated Seats

    GETTING STARTED WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury. HEATED SEATS Front Heated Seats The controls for the front heated seats are located on the center instrument panel...

  • Page 29: Tilt Steering Column

    GETTING STARTED TILT STEERING COLUMN The tilt lever is located on the steering column, below the turn signal lever. • Push down on the lever to unlock the steering column. • With one hand firmly on the steering wheel, move the steering column up or down as desired.

  • Page 30: Operating Your Vehicle

    OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in.
  • Page 31 OPERATING YOUR VEHICLE Instrument Panel Dimmer • Rotate the center portion of the lever to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened. • Rotate the center portion of the lever up to increase the brightness of the instrument panel lights when the parking lights or headlights are on.

  • Page 32: Wiper/Washer Lever

    OPERATING YOUR VEHICLE WIPER/WASHER LEVER Wiper/Washer Lever Front Wipers Intermittent, Low And High Operation • Rotate the end of the lever to the first detent position for one of five intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

  • Page 33: Electronic Speed Control

    OPERATING YOUR VEHICLE ELECTRONIC SPEED CONTROL The Electronic Speed Control switches are located on the steering wheel. Cruise ON/OFF • Push the ON/OFF button to activate the Speed Control. NOTE: CRUISE will appear on the instru- ment cluster to indicate the Speed Con- trol is on.
  • Page 34 OPERATING YOUR VEHICLE To Decrease Speed • When the Electronic Speed Control is set, you can decrease speed by pushing the SET - button. The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Understanding Your Instrument Panel” in the Owner’s Manual DVD for more information.

  • Page 35: Parkview® Rear Back-Up Camera

    OPERATING YOUR VEHICLE PARKVIEW® REAR BACK-UP CAMERA You can see an on-screen image of the rear of your vehicle whenever the shift lever is put into REVERSE. The ParkView Rear Back-Up Camera image will be displayed on ® the radio display screen, located on the center stack of the instrument panel. If the radio display screen appears foggy, clean the camera lens located on the liftgate.

  • Page 36: Manual Climate Controls

    OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS Manual Climate Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 — Rotate Mode Control 3 — Rotate Temperature Control 6 — Push Rear Window Defroster Air Recirculation •...

  • Page 37: Automatic Temperature Controls (Atc)

    OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Automatic Temperature Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 — Rotate Mode Control 3 — Rotate Temperature Control 6 — Push Rear Window Defroster Automatic Operation •...

  • Page 38: Power Sunroof

    OPERATING YOUR VEHICLE POWER SUNROOF The power sunroof switch is located on the overhead console. Opening Sunroof Express Open Push the switch rearward and release it within one-half second. The sunroof will fully open and stop automatically. Manual Open Push and hold the switch rearward to open the sunroof. Any release of the switch will stop the movement, and the sunroof will remain in a partially open position until the switch is pushed again.

  • Page 39: Wind Buffeting

    OPERATING YOUR VEHICLE WARNING! • Never leave children alone in a vehicle, or with access to an unlocked vehicle. Never leave the Key Fob in or near the vehicle, or in a location accessible to children. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch.

  • Page 40: Electronics

    ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect ® Voice Command Button pg. 67 2. Uconnect ® Phone Button pg. 64 3. Steering Wheel Audio Controls (Right) pg. 63 4. Steering Wheel Audio Controls (Left) pg. 63...
  • Page 41 ELECTRONICS 5. USB Port on Radio pg. 53 6. Audio Jack pg. 48 7. Front Power Outlet pg. 77 8. USB Port (inside glove box) pg. 63...

  • Page 42: Uconnect ® 130

    ELECTRONICS Uconnect® 130 Uconnect® 130 1 — CD Eject Button 9 — Set Clock Button 2 — Seek Down Button 10 — Audio Settings/Rotate To Tune 3 — Seek Up Button 11 — Radio Sales Code 4 — AM/FM Button 12 —...
  • Page 43 ELECTRONICS Equalizer, Balance And Fade 1. Push the TUNE/SCROLL control knob and “BASS” will display. 2. Rotate the TUNE/SCROLL control knob to select the desired setting. 3. Continue pushing the TUNE/SCROLL control knob to display and set “MID RANGE,” “TREBLE,” “BALANCE” and “FADE.” Radio Operation Seek Up/Down Buttons •...

  • Page 44: Satellite Radio

    ELECTRONICS Uconnect® 130 WITH SiriusXM SATELLITE RADIO Uconnect® 130 With SiriusXM Satellite Radio 1 — CD Eject Button 12 — Audio Jack 2 — Seek Down Button 13 — Set Preset/CD Random Play 3 — Seek Up Button 14 — Station Preset Buttons 4 —...
  • Page 45 ELECTRONICS Clock Setting 1. Push and hold the TIME button until the hours blink. 2. Turn the TUNE/SCROLL control knob to set the hours. 3. Push the TUNE/SCROLL control knob until the minutes begin to blink. 4. Turn the TUNE/SCROLL control knob to set the minutes. 5.
  • Page 46 ELECTRONICS SiriusXM Satellite Radio SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to cancel.

  • Page 47: Uconnect ® 230

    ELECTRONICS Uconnect® 230 Uconnect® 230 1 — CD Eject Button 13 — Audio Jack 2 — Seek Down Button 14 — Radio Sales Code 3 — Seek Up Button 15 — AUX Mode Button 4 — Scan Radio Stations Button 16 —...
  • Page 48 ELECTRONICS Clock Setting 1. Push and hold the TIME button until the hours blink. 2. Turn the TUNE/SCROLL control knob to set the hours. 3. Push the TUNE/SCROLL control knob until the minutes begin to blink. 4. Turn the TUNE/SCROLL control knob to set the minutes. 5.
  • Page 49 ELECTRONICS SiriusXM Satellite Radio SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to cancel.

  • Page 50: Uconnect® 430/430N

    ELECTRONICS • Pushing the AUX button will change the mode to auxiliary device if the Audio Jack is connected, allowing the music from your portable device to play through the vehicle's speakers. The functions of the portable device are controlled using the device buttons, not the buttons on the radio.
  • Page 51 ELECTRONICS Clock Setting 1. Turn the radio on, then press the screen where the time is displayed. 2. Press the “User Clock” button on the touchscreen or the time display (Navigation radio only). 3. To adjust the hours, press either the “Hour Forward” or “Hour Backward” button on the touchscreen.
  • Page 52 ELECTRONICS Equalizer, Balance And Fade Audio Control Menu • Push the AUDIO button on the face- plate on the right side of the radio. • Use either the “arrow” buttons on the touchscreen or the cross-hair on the screen to change Balance and Fade. The “CENTER”...
  • Page 53 ELECTRONICS Radio Operation Radio Operation 1 — Radio Tuner Tabs 6 — Station Scan 2 — Individual Presets 7 — Seek Down 3 — Search/Browse 8 — Direct Tune 4 — Radio Station/Track Info 9 — Seek Up 5 — Sort Presets •...
  • Page 54 ELECTRONICS • Once the station is found, press and hold one of the “PRESET” buttons on the touchscreen in the list to the right, until you hear a confirmation beep. NOTE: If the Presets are not visible on the right side of the screen, press the “PRESETS” button on the touchscreen.
  • Page 55 ELECTRONICS Insert a CD/DVD Disc • To insert a disc, push the LOAD button on the faceplate. • With the printed side upwards, insert the disc into the disc slot of the radio. The radio pulls the disc in automatically and closes the flip screen. The radio selects the appropriate mode after the disc is recognized, and starts playing the first track.
  • Page 56 ELECTRONICS Copying Music From CD • Push the LOAD button on the faceplate. • Insert a disc, then push the MY FILES button on the faceplate and then select “MY MUSIC” button on the touchscreen. • Press the “Add Music Files to HDD” button on the touchscreen, then press the “Disc”...
  • Page 57 ELECTRONICS Copying Pictures To The HDD • Insert either a CD or a USB device containing your pictures in JPEG format. • Push the MY FILES button on the faceplate. • Press the “My Pictures” button on the touchscreen to get an overview of the currently stored images, then press the “Add”...
  • Page 58 ELECTRONICS Playing Music From The HDD • Push the MEDIA button on the faceplate to display the media source tabs at the top of the screen. Press the “HDD” button on the touchscreen. Press the desired track button on the touchscreen to play or press the “SEARCH/BROWSE” button on the touchscreen to search by artist, by album, by song, by genre, from a folder, or from Favorites.
  • Page 59 ELECTRONICS Changing the Navigation Voice Prompt Volume 1. Program a destination. 2. While traveling on your route, press the upper left area of the map screen where your next turn is displayed. 3. The Navigation system will then repeat the distance to your next turn. 4.
  • Page 60 ELECTRONICS Edit Home Location • From the main Navigation menu press the “Where To?” button on the touch- screen, then press the "Tools" icon. Next, press the "My Data" folder. • You may enter a new address directly, use your current location or choose from recently found locations.

  • Page 61: Siriusxm Satellite Radio/Travel Link

    ELECTRONICS Adding A Via Point To add a stop between the current location and the end destination (Via Point) you must be navigating a route. • Press the “back arrow” icon multiple times to return to the Main Navigation menu. •...
  • Page 62 ELECTRONICS SiriusXM Parental Controls • SiriusXM offers the option to permanently block selected channels. Call 1-888-539-7474 and request the Family Package. • Uconnect® 430/430N and 730N: Push the MENU button on the faceplate while in SiriusXM Satellite Radio Mode, then press the “Channel Lock” to enable and/or disable desired channels.
  • Page 63 ELECTRONICS Display SAT Favorites List • Press the “Search/Browse” button on the touchscreen and select “Favorites” from the SAT Browse screen. • Press the desired favorites button on the touchscreen to switch the SAT tuner to the corresponding channel. You may use the “LIST” button on the touchscreen to toggle between: •...
  • Page 64 ELECTRONICS SiriusXM Travel Link (Uconnect® 730N & Uconnect® 430N Only) NOTE: SiriusXM Travel Link requires a subscription, sold separately after the five year trial subscription included with your vehicle purchase and is ONLY available in the United States. SiriusXM Travel Link SiriusXM Travel Link brings a wealth of useful information into your vehicle, right to your fingertips.

  • Page 65: Steering Wheel Audio Controls

    ELECTRONICS STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to in- crease or decrease the volume. • Push the button in the center to change modes AM/FM/CD/SAT.

  • Page 66: Uconnect® Phone

    ELECTRONICS When connected to this feature: • The iPod ® can be controlled using the radio buttons to Play, Browse, and List the iPod ® or external devices contents. • The iPod ® battery charges when plugged into the USB port (if supported by the specific audio device).
  • Page 67 ELECTRONICS Phone Pairing NOTE: Pairing is a one-time initial setup before using the phone. Prior to starting the pairing procedure ensure all additional phones within the vehicle have their Bluetooth ® disabled. • Activate Bluetooth ® on the mobile phone you are pairing. •...
  • Page 68 ELECTRONICS NOTE: The mobile phone may require authorization prior to download. • A maximum of 1,000 entries per phone will be downloaded and updated every time a phone is connected to the Uconnect ® Phone. • Depending on the maximum number of entries downloaded, there may be a short delay before the latest downloaded names can be used.

  • Page 69: Uconnect® Voice Command

    ELECTRONICS WARNING! • Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.
  • Page 70 ELECTRONICS Common Voice Commands (Examples) While In: Voice Command Example: “Radio AM” (to switch to the AM radio mode) “Radio FM” (to switch to the FM radio mode) “Satellite Radio” (to switch to the Satellite radio mode) “Disc” (to switch to the disc mode) Main Menu “USB”...
  • Page 71 ELECTRONICS While In: Voice Command Example: To switch to the voice recorder mode, say “Memo.” The fol- lowing are common voice commands for this mode: “New Memo” (to record a new memo) — During the recording, you may push the Voice Command button to stop re- cording.

  • Page 72: Bluetooth® Streaming Audio

    • Push the DOWN Arrow button to scroll downward through the sub-menus. • Push the COMPASS button to display one of eight compass readings and the outside temperature or to exit sub-menus. • Push the RIGHT Arrow button for access to main menus, sub-menus or to select a personal setting in the setup menu.

  • Page 73: Programmable Features

    When the vehicle is new, the compass may appear erratic, and the EVIC will display “CAL” until the compass is calibrated. You may also calibrate the compass by completing one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in the EVIC turns off.
  • Page 74 ELECTRONICS Auto Unlock Doors On Exit To have all of the vehicle doors unlock when any door is opened: • Enter your vehicle and close all the doors, and fasten your seat belt. • Cycle the ignition switch between the LOCK and ON position four times, ending in the LOCK position (do not start the engine).

  • Page 75: Universal Garage Door Opener (Homelink )

    ELECTRONICS UNIVERSAL GARAGE DOOR OPENER (HomeLink®) • HomeLink replaces up to three hand-held transmitters that operate devices such ® as garage door openers, motorized gates, lighting or home security systems. The HomeLink ® unit is powered by your vehicles 12 Volt battery. •...
  • Page 76 ELECTRONICS Programming A Rolling Code NOTE: For programming Garage Door Openers that were manufactured after 1995. These Garage Door Openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the Garage Door Opener. It is NOT the button that is normally used to open and close the door.
  • Page 77 ELECTRONICS Programming A Non-Rolling Code NOTE: For programming Garage Door Openers manufactured before 1995. 1. Turn the ignition switch to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink ®...

  • Page 78: Power Inverter

    ELECTRONICS POWER INVERTER A 115 Volt, 150 Watt AC power inverter is located on the front of the center console. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts. NOTE: The power inverter is designed with built-in overload protection.

  • Page 79: Power Outlet

    ELECTRONICS POWER OUTLET The power outlet is located on the instrument panel below the climate control and is powered when the ignition switch is in the ON/RUN position. The outlet can operate a conventional cigar lighter unit or power accessories designed for use with a standard power outlet adapter.

  • Page 80: Off-Road Capabilities

    OFF-ROAD CAPABILITIES FOUR-WHEEL DRIVE OPERATION This vehicle has two full time, on-demand, four-wheel-drive (4WD) systems avail- able, Freedom Drive I™ and Freedom-Drive II™. They provide for all-weather, all-terrain capability for added driving security in less-than-ideal road conditions. Freedom-Drive I™ Four Wheel Drive System Freedom-Drive I™...
  • Page 81 OFF-ROAD CAPABILITIES • This can be done on the fly, at any vehicle speed. To deactivate, simply pull on the T-handle one more time. The “4WD Indicator Light” will then turn off. 4WD T-Handle Trail Rated® Freedom-Drive II™ Four Wheel Drive System (IF EQUIPPED) This system offers all the benefits of Freedom Drive I™...

  • Page 82: Utility

    UTILITY TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) Engine/ Max. GTW Max. Tongue Wt. Frontal Area Transmission (Gross Trailer Wt.) (See Note) 22 sq ft 2.0L Auto/Man 1,000 lbs (450 kg) 150 lbs (68 kg) (2.04 sq m) 22 sq ft 2.4L Auto/Man 1,000 lbs (450 kg) 150 lbs (68 kg)

  • Page 83: Recreational Towing (Behind Motorhome, Etc.)

    UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Wheels OFF the Automatic Transmis- Towing Condition Manual Transmission Ground sion • Transmission in NEUTRAL Flat Tow None NOT ALLOWED • Key in ACC Posi- tion Front OK (FWD Only) OK (FWD Only) Dolly Tow Rear NOT ALLOWED NOT ALLOWED...

  • Page 84: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
  • Page 85 WHAT TO DO IN EMERGENCIES – Electronic Throttle Control (ETC) Indicator Light This light informs you of a problem with the system. If a problem is detected, the light will come on while the engine is running. Cycle the ignition when the vehicle has completely stopped and the shift lever is placed in the PARK position;...
  • Page 86 WHAT TO DO IN EMERGENCIES When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. When the malfunc- tion indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended.
  • Page 87 WHAT TO DO IN EMERGENCIES The dual brake system provides a reserve braking capacity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.
  • Page 88 WHAT TO DO IN EMERGENCIES – Transmission Temperature Warning Light This light indicates that there is excessive transmission fluid temperature that might occur with severe usage such as trailer towing. If this light turns on, you will experience reduced vehicle performance until the automatic transmission cools down.

  • Page 89: Instrument Cluster Indicator Lights

    WHAT TO DO IN EMERGENCIES The “ESC Activation/Malfunction Indicator Light” starts to flash as soon as the tires lose traction and the ESC system becomes active. If the light begins to flash during acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions.

  • Page 90: If Your Engine Overheats

    WHAT TO DO IN EMERGENCIES Oil Change Indicator Message If an “oil change” message (shown as CHANgE OIL) appears and a single chime sounds, it is time for your next required oil change. Resetting The Light After Servicing 1. Turn the ignition switch to the ON/RUN position (do not start engine). 2.

  • Page 91: Automatic Transmission Overheating

    WHAT TO DO IN EMERGENCIES AUTOMATIC TRANSMISSION OVERHEATING During sustained high speed driving or trailer towing up long grades on hot days, the automatic transmission oil may become too hot. When the transmission overheat warning light turns on, you will experience reduced performance until the automatic transmission cools down.
  • Page 92 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm level surface, avoiding ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3. Set the parking brake. 4. Place the shift lever in PARK (automatic transmission) or REVERSE (manual transmission).
  • Page 93 WHAT TO DO IN EMERGENCIES 2. Loosen, but do not remove, the wheel nuts by turning them to the left one turn while the wheel is still on the ground. NOTE: • There are front and rear jacking locations on each side of the body. The front locations are outlined by two triangular cutouts, the rear locations by two rectangular cutouts.
  • Page 94 WHAT TO DO IN EMERGENCIES 3. Turn the jack screw to the left until the jack can be placed under the jacking location. Once the jack is positioned, turn the jack screw to the right until the jack head is properly engaged with the lift area closest to the wheel to be changed. 4.
  • Page 95 WHAT TO DO IN EMERGENCIES Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle. 2. To ease the installation process for steel wheels with wheel covers, install two lug nuts on the mounting studs which are on each side of the valve stem. Install the lug nuts with the cone shaped end of the nut toward the wheel.
  • Page 96 WHAT TO DO IN EMERGENCIES CAUTION! • Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. • Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the spare tire is mounted incorrectly.

  • Page 97: Jump-Starting Procedures

    WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
  • Page 98 WHAT TO DO IN EMERGENCIES • To access the battery remove the air intake duct by turning the two finger screws, located on the radiator support. 1. Set the parking brake, shift the auto- matic transmission into PARK and turn the ignition to LOCK. 2.
  • Page 99 WHAT TO DO IN EMERGENCIES 3. Disconnect the opposite end of the positive (+) jumper cable from the positive (+) post of the booster battery. 4. Disconnect the positive (+) end of the jumper cable from the positive (+) post of the vehicle with discharged battery.

  • Page 100: Shift Lever Override

    WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1. To access the shift lever override, locate and remove the removable plug in the right side of the shift lever housing.

  • Page 101: Towing A Disabled Vehicle

    WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE Wheels 6-Speed Towing Manual 6-Speed Automatic OFF the Automatic Condition Transmission Automatic 4WD Transmis- Ground (FWD Only) sion If transmission is operable: If transmission • Transmis- is operable: • Transmis- sion in •...

  • Page 102: Event Data Recorder (Edr)

    WHAT TO DO IN EMERGENCIES CAUTION! • When “rocking” a stuck vehicle by shifting between REVERSE and DRIVE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Revving the engine or spinning the wheels too fast may lead to transmission overheating and failure.

  • Page 103: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE OPENING THE HOOD 1. Pull the release lever located below the instrument panel and in front of the driver’s door. 2. Raise the hood and locate the safety latch, in the middle of the hood open- ing. 3.

  • Page 104: Engine Compartment

    MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 2.0L Engine 1. Washer Fluid Reservoir 2. Brake Fluid Reservoir 3. Integrated Power Module (Fuses) 4. Air Cleaner Filter 5. Battery...
  • Page 105 MAINTAINING YOUR VEHICLE 6. Engine Oil Fill 7. Engine Coolant Pressure Cap 8. Engine Oil Dipstick 9. Engine Coolant Reservoir 10. Power Steering Fluid Reservoir...
  • Page 106 MAINTAINING YOUR VEHICLE 2.4L Engine 1. Washer Fluid Reservoir 2. Brake Fluid Reservoir 3. Integrated Power Module (Fuses) 4. Air Cleaner Filter 5. Battery...
  • Page 107 MAINTAINING YOUR VEHICLE 6. Engine Oil Fill 7. Engine Coolant Pressure Cap 8. Engine Oil Dipstick 9. Engine Coolant Reservoir 10. Power Steering Fluid Reservoir...

  • Page 108: Fluid Capacities

    MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 13.6 Gallons 51 Liters Engine Oil with Filter 2.0L and 2.4L Engine 4.5 Quarts 4.26 Liters (SAE 5W-20, API Certified) Cooling System * 2.0L and 2.4L Engine (MOPAR ® Antifreeze/ Engine Coolant 10 Year/ 7.2 Quarts 6.8 Liters 150,000 Mile Formula or...
  • Page 109 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...

  • Page 110: Maintenance Procedures

    MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Maintenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or applicable supplement on the DVD for further details. MAINTENANCE SCHEDULE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 111 MAINTAINING YOUR VEHICLE Severe Duty All Models Change Engine Oil at 4,000 miles (6,500 km) if the vehicle is operated in a dusty and off road environment. This type of vehicle use is considered Severe Duty. Once A Month Or Before A Long Trip: •...
  • Page 112 MAINTAINING YOUR VEHICLE...
  • Page 113 MAINTAINING YOUR VEHICLE...
  • Page 114 MAINTAINING YOUR VEHICLE...

  • Page 115: Fuses

    MAINTAINING YOUR VEHICLE FUSES Integrated Power Module The Integrated Power Module is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini-fuses. A label that identifies each component may be printed on the inside of the cover. Refer to “Engine Compartment”...
  • Page 116 Radio Amplifiers 15 Amp Lt Blue Radio 10 Amp Red Intrusion Module/Siren – If Equipped 10 Amp Red Heating, AC/Compass 15 Amp Lt Blue Auto Shutdown Relay 15 Amp Lt Blue Power Sunroof – If Equipped 10 Amp Red Heated Mirror –...

  • Page 117: Tire Pressures

    MAINTAINING YOUR VEHICLE CAUTION! • When installing the IPM cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the IPM, and possibly result in an electrical system failure. •...

  • Page 118: Spare Tires - If Equipped

    MAINTAINING YOUR VEHICLE SPARE TIRES — IF EQUIPPED NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit” in “What To Do In Emergencies” on your DVD for further information. CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with a compact or limited-use temporary spare installed.

  • Page 119: Wheel And Wheel Trim Care

    MAINTAINING YOUR VEHICLE Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not. This spare tire may have limited tread life.
  • Page 120 MAINTAINING YOUR VEHICLE CAUTION! Avoid products or automatic car washes that use acidic solutions or strong alkaline additives or harsh brushes. These products and automatic car washes may damage the wheel's protective finish. Such damage is not covered by the New Vehicle Limited Warranty.

  • Page 121: Replacement Bulbs

    MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Bulbs Bulb Number Front Header Lamp T578 Center Dome Lamp T578 Rear Cargo Lamp/Flashlight 8–A35LFAA Exterior Bulbs Bulb Number Low Beam Headlamp Premium Low Beam Headlamp HIR2 High Beam Headlamp 9005 Premium High Beam Headlamp HIR2 Premium Front Park Lamp 3157K...

  • Page 122: Customer Assistance

    CUSTOMER ASSISTANCE FCA US LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1-877-426-5337 FCA CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800-465-2001 (English) Phone: 1-800-387-9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.

  • Page 123: Publications Ordering

    Warranty Booklet. United States customers may visit the Jeep Contact Us page at www.jeep.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Box Material” from the left menu.

  • Page 124: Reporting Safety Defects In The United States

    CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS IN THE UNITED STATES If you believe that your vehicle has a defect that could cause a collision or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 125: Mopar® Accessories

    The following highlights just some of the many Authentic Jeep Accessories by MOPAR featuring a fit, finish, and functionality specifically for your Jeep Compass.

  • Page 126: Faq

    Uconnect ® Hands-Free Voice Activation System? pg. 65 • How do I configure my Universal Garage Door Opener (HomeLink )? pg. 73 ® UTILITY • How do I know how much I can tow with my Jeep Compass? pg. 80...
  • Page 127 WHAT TO DO IN EMERGENCIES • What do I do if my TPMS warning light is blinking? pg. 83 • How do I change a flat tire? pg. 89 • How do I Jump-Start my vehicle? pg. 95 MAINTAINING YOUR VEHICLE •...

  • Page 128: Index

    Side Air Bags ... .17 Side Impact Curtains ..17 Calibration, Compass ..71 Side Impacts ... .15 Capacities, Antifreeze Air Bag Light .
  • Page 129 Jacking ....89 Compact Spare Tire..116 Compass Calibration ..71 Jump Starting .
  • Page 130 INDEX Tank Capacity ..106 Remote Start ... .12 Unlock The Doors ..10 Garage Door Opener (HomeLink ®...
  • Page 131 INDEX New Vehicle Break-In Period ..28 Panic Alarm ... .11 Remote Keyless Entry (RKE) . . .10 Occupant Restraints ..16 Unlock The Doors .
  • Page 132 INDEX Steering Wheel Audio Controls ..63 Turn Signals ... .29, 87 Supplemental Restraint System - Air Bag ....15 Uconnect ®...
  • Page 133 This guide has been prepared to help you get quickly acquainted with your new Jeep and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect®...
  • Page 134 Download a FREE electronic copy of the Owner’s Manual and Warranty Booklet by visiting: www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). Jeep and Compass are registered Trademarks of FCA US LLC. © 2016 FCA US LLC. All Rights Reserved. 15MK49-926-AA Compass Fifth Edition...

This manual is also suitable for:

Patriot 2015

Table of Contents
