To program the garage door opener on a Jeep Compass using the HomeLink system, follow these steps:

1. Preparation
- Park outside the garage.
- Ensure the handheld transmitter has fresh batteries.
- Reset HomeLink memory by holding the two outside buttons until the indicator light flashes (about 20 seconds). This erases all previous programming.

2. Programming a Rolling Code Opener
- Turn the vehicle ignition to the "On/Run" position without starting the engine.
- Hold the handheld transmitter 1 to 3 inches (3 to 8 cm) from the HomeLink button you want to program.
- Press and hold both the HomeLink button and the handheld transmitter button simultaneously.
- The HomeLink indicator light will flash slowly, then rapidly. Once it changes to rapid blinking, release both buttons.

3. Syncing with the Garage Door Opener
- Locate the "Learn" or "Training" button on the garage door opener motor (usually near the hanging antenna).
- Press and release the "Learn" button. You have 30 seconds to complete the next step.
- Return to the vehicle and press the programmed HomeLink button twice, holding it for 2 seconds each time.
- If the garage door does not activate, press the button a third time for 2 seconds.

4. For Non-Rolling Code Openers (Pre-1995 Models)
- Follow the same initial steps as for rolling code openers.
- No additional syncing with a "Learn" button is needed.

Once completed, the HomeLink system should operate the garage door opener.

This answer is automatically generated

Summary of Contents for Jeep COMPASS

Page 1 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your JEEP dealer.
Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Jeep gives the opportunity to consult a dedicated section which is available in electronic format. Jeep workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
Page 3 In the enclosed Warranty Booklet you will also find a description of the Dealer Services that Jeep offers to its customers, the Warranty Certificate and details of the terms and conditions for the maintenance of the vehicle.
Page 4 ELECTRICAL ACCESSORIES If, after buying the car, you decide to add electrical accessories (with the risk of gradually draining the battery), contact a Jeep Dealership. They can calculate the overall electrical requirement and check that the car's electric system can support the required load.
Page 5 SCHEDULED SERVICING Correct maintenance helps to preserve the vehicle's performance and safety features, respect for the environment and low operating costs over time. ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and has a higher center of gravity compared to many other vehicles for transporting passengers, so that it allows a better performance to be reached in a wide range of off-road applications.
Page 6 HOW TO USE THIS MANUAL OPERATING INSTRUCTIONS Each time that instructions relating to the vehicle are provided (left/right or forward/rearward), these should be understood as referring to an occupant in the driver seat. If a direction is written from a different perspective, it will be specified as such in the text as appropriate. The figures that appear in the manual are used as a guide: this may mean that some of the details shown in the picture do not match those on your vehicle.
Page 7 SYMBOLS USED Some of the vehicle's components bear colored placards, the symbols on which indicate important cautions to be observed relating to the component itself. It is important to follow all warnings when operating your vehicle. See below for a brief description of each symbol. Always take great care to all warnings herein.
Page 8 VEHICLE MODIFICATIONS/ALTERATIONS WARNING Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death of the occupants.
Page 9 GRAPHICAL TABLE OF CONTENTS KNOWLEDGE OF THE VEHICLE KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN CASE OF EMERGENCY MAINTENANCE AND CARE TECHNICAL DATA MULTIMEDIA CONTENTS...
Page 11 GRAPHICAL TABLE OF CONTENTS FRONT VIEW ..... 10 REAR VIEW ..... . 11 INSTRUMENT PANEL .
Page 12: Front View
FRONT VIEW 5520471D Hood/engine compartment Outside Rearview Mirrors Doors Headlamps Windshield Wheels/tires...
Page 13: Rear View
REAR VIEW 5520472D Rear lights Rear windshield wiper Liftgate...
Page 14: Instrument Panel
INSTRUMENT PANEL 5520469D Headlight Switch Windshield wiper lever Multifunction Lever Switch panel EVIC Controls Uconnect System Instrument panel Climate Controls Cruise Controls Glovebox Storage Compartment...
Page 15: Vehicle Interior
VEHICLE INTERIOR 5520470D Locking Doors Transmission Shift Lever USB, AUX port and front power socket Door handles Power Window Switches Glovebox Storage Compartment Seats SPORT Button...
Page 17: Table Of Contents
KNOWLEDGE OF THE VEHICLE In-depth knowledge of your new vehicle KEYS ......16 starts here.
Page 18: Keys
KEYS Emergency key removal KEY FOB The metal insert of the key fob operates: The ignition device; the door lock. Press button (1) fig. 6 to open/close the 5520294D metal insert. All doors can be programmed to unlock 5520295D The emergency key (fig. 8) can be used on the first press of the button.
Page 19 Immobilizer system serviced, bring all Release button on the first push of the key special containers or taken to a Jeep car keys with you to the Jeep Dealership. This feature lets you program the system Dealership, which will take care of their to unlock either the driver's door or disposal.
Page 20: Ignition Device
IGNITION DEVICE the clutch pedal (versions with manual gearbox); START: engine starting. 4) 5) 6) 7) 8) 9) 10) 11) VERSIONS WITH ELECTRONIC KEY ("Keyless Enter-N-Go" Starting the engine (with electronic key system) battery flat): in this case, rest the rounded edge of the electronic key (the This feature allows the driver to operate the ignition device with the push of a...
Page 21: Sentry Key
4) If the starter switch has been tampered indicates that there is a fault in the with (e.g. an attempted theft), have it electronics. Should this occur, have the checked over by a Jeep Dealership before IMPORTANT car serviced as soon as possible by the driving again.
Page 22: Alarm
If the displaying is still on, driver and/or passenger side door open. you lock the doors using the manual door contact a Jeep Dealership. Push the lock button on the exterior lock plunger. Passive Entry Door Handle with a valid key fob available in the same exterior zone (refer to the "Doors”...
Page 23: Premium Vehicle Security
PREMIUM VEHICLE NOTES: refer to "Doors" in this section for further information. The driver's door key cylinder and the SECURITY ALARM Press the button on the key. button on the key fob cannot arm or (where provided) disarm the car’s security alarm. 3.
Page 24: Doors
DOORS Central locking / unlocking The system lets you lock/unlock the doors (and the liftgate) without having to Press the button on the driver fig. 13 press any button on the electronic key. or passenger door trim panel to lock the doors.
Page 25 within 1.5 m of the liftgate, push the passenger side front door handle, press electronic liftgate release to open with the 'Door Lock' button fig. 16 on the one fluid motion. handle to lock all doors and the liftgate. Locking liftgate NOTE DO NOT grab the door handle, when pushing the door handle lock With a valid Passive Entry key fob within...
Page 26 NOTES: The device fig. 18 can only be activated window, and open the door with the when the doors are open: outside door handle. After pushing the door handle button, position: system activated (door you must wait two seconds before you can lock or unlock the doors, using locked) NOTE Always use this system when...
Page 27: Seats
Reclining bucket seats parking brake, the brake pedal or the transmission lever. Use lever (3) fig. 19 to adjust the 15) Do not leave the Key Fob in or near backrest angle, accompanying it with the the car or in a location accessible to movement of the torso (operate the lever children, and do not leave the ignition until the desired position is reached,...
Page 28 Lift the seatbacks by pushing them Therefore, when the passenger side front Folding the rear seat rearward, until you hear both coupling seat is folded down, the presence of 1. Make sure that the seat belt is mechanisms lock into place, visually rear occupants is not permitted while positioned on the panel (1) fig.
Page 29 Forward/rearward adjustment function and buttons (1) and (2) related 2. Adjust all memory profile settings to to the memory profiles. The memory Push switch (1) fig. 22 forwards or desired preferences (i.e., seat and radio buttons allow the driver to recall either of station presets).
Page 30 2. Select the desired memory profile (1) A recall can be canceled by pushing Press the button a third time to o (2). any of the memory buttons (S, 1, or turn the ventilated seat function OFF. 2) during a recall. When a recall is NOTE If a memory profile has not NOTE The engine must be running for canceled, the driver seat will stop...
Page 31: Head Restraints
If either of the 5) Do not arrange objects beneath the head restraints require removal, see a electrically adjustable seat and do not Jeep Dealership. 5520438D impede its movement, since the controls NOTE The head restraints should only may be damaged.
Page 32: Steering Wheel
If either of the NOTE The engine must be running for head restraints require removal, see a the heated steering wheel to operate. Jeep Dealership. ADJUSTMENTS IMPORTANT If the rear seats are used, WARNING The steering wheel can be adjusted both always set the head restraint of the in height and depth.
Page 33: Mirrors
MIRRORS IMPORTANT Once adjustment is complete, rotate the device (2) to the central position to prevent accidental movements. Inside rearview mirror Use the lever fig. 28 to adjust the mirror between two different positions: normal or dimming. It is equipped with a safety device which releases it in the event of forceful contact with the passenger.
Page 34: Exterior Lights
EXTERIOR LIGHTS Power folding mirrors WARNING (where provided) To fold the mirrors, press button (1) 36) Vehicles and other objects seen in the fig. 30. Press the button again to restore MULTIFUNCTION LEVER passenger side convex mirror will look the mirrors to the driving position. The multifunction lever (1) is located smaller and farther away than they really on the left side of the steering column...
Page 35 LOW BEAM HEADLIGHTS NOTES: With the ignition device on RUN, turn The Automatic dim high beams control can be turned on or off the switch (1) fig. 33 to position using the Uconnect™ System. Refer The low beam and license plate lights to the “Settings”...
Page 36 Headlight Time Delay. To have this checked and any necessary REAR FOG LIGHTS The Headlight Time Delay can be adjustments made, contact a Jeep The rear fog light switch is integrated programmed using the Uconnect™ Dealership. with the light switch.
Page 37: Interior Lights
INTERIOR LIGHTS WINDSHIELD WIPER / chart, aligns with the indicator line on the switch. REAR WIPER FRONT DOME LAMP Driver only, or driver and front The right lever controls the operation of The interior lights come on when a door passenger.
Page 38 function: operation is limited to the WARNING If the stalk is activated for amount or measured rain. time for which the stalk is held in this less than half a second, only the screen The same stroke will be visible every position.
Page 39 If operation is engaged. not subsequently restored, even after NOTE If automatic wiping mode is active restarting the engine, contact a Jeep Dealership. and the sensor does not detect water, by 8) Do not operate the screen wiper with...
Page 40: Climate Controls
CLIMATE CONTROLS The Climate Control System allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the touchscreen (if equipped) and on the instrument panel below the Uconnect™ system. Manual Climate Controls 5520467D Manual climate control system controls description...
Page 41 Icon Description Recirculation button Press and release this button to change the system between “Recirculation” mode and “Outside air” mode. The “Recirculation” mode can be used when outside conditions, such as smoke, odours, dust or high humidity are present. The “Recirculation” mode can be used in all modes except defrosting. The “Recirculation” function may be unavailable if there are conditions that could create fogging on the inside of the windscreen.
Page 42 Icon Description “Dashboard” Mode Airflow at central and side dashboard vents to ventilate the chest and the face during the hot season. Each vent can be individually adjusted to direct the airflow as preferred. The air vanes of the central and outer vents can be moved up and down or side-to-side to adjust airflow direction.
Page 43 Uconnect™ 7" automatic dual-zone climate control system controls 5520442D...
Page 44 Uconnect™ 8.4" automatic dual-zone climate control system controls 5520443D...
Page 45 Automatic dual-zone climate control system control panel controls 5520322D...
Page 46 Automatic dual-zone climate control system controls description Automatic dual-zone climate control system controls description Icon Description Max A/C button Press and release the Max A/C button on the touchscreen to activate the maximum cooling function (Max A/C). Max A/C The Max A/C button lights up. Press the button again to deactivate the function. NOTE The A/C Max button is only available on the touchscreen.
Page 47 Icon Description Rear defrost button Push and release this button to turn on the heated rear window and the heated outside mirrors (where provided). When the heated rear window is activated the corresponding LED lights up. The heated rear window deactivates REAR automatically after ten minutes.
Page 48 Icon Description “Dashboard” Mode Airflow at central and side dashboard vents to ventilate the chest and the face during the hot season. Each vent can be individually adjusted to direct the airflow as preferred. The air vanes of the central and outer vents can be moved up and down or side-to-side to adjust airflow direction.
Page 49: Windows
WINDOWS To stop the window from going all the way down during the AUTO-Down operation, pull up on the switch briefly. POWER WINDOWS Anti-pinch safety device This safety system can recognize the presence of any obstacle during the The electric window controls on the window closing movement.
Page 50: Power Sunroof
“Multimedia” section for further Where this function is available, this 42) The anti-pinch system is not active information. type of opening can be activated when the window is almost closed. To irrespective of the position of the avoid personal injury be sure to clear your OPENING arms, hands, fingers and all objects from sunroof.
Page 51 SUN BLIND MOVEMENT Express system is deactivated and the sunroof must be closed in Manual mode. The sunshade has two programmed Push the switch (1) and release it within open positions: half open and full open one-half second. If the sunroof is in The power sunroof switch will remain positions.
Page 52: Engine Hood
ENGINE HOOD sunroof switch. Such entrapment may result in serious injury or death. 45) In a collision, there is greater risk of being thrown from a vehicle with an open OPENING sunroof. You could also be seriously injured or killed. Always fasten your 47) 48) seat belt properly and make sure all Proceed as follows:...
Page 53: Trunk
CLOSING TRUNK 49) For safety reasons, the bonnet must always be properly closed while driving. 49) 50) 51) Therefore, make sure that the bonnet is properly closed and that the lock is OPENING FROM THE OUTSIDE Proceed as follows: engaged. If you discover that the bonnet is not perfectly closed while driving, stop 1.
Page 54 TRUNK INITIALIZATION If the battery has been disconnected or if the fuse protection has intervened, you will need to "initialize" the opening/closing mechanism of the trunk, as follows: Close all the doors and the trunk Press the button on the key fob Press the button on the key fob POWER LIFTGATE...
Page 55 Lock the vehicle Reconfigurable load platform be necessary to assist the props when opening the liftgate in cold weather. The cargo load floor can be adjusted Before driving off, check the to three different levels to create more NOTES: instrument panel for a liftgate or door space in the cargo area.
Page 56 Cargo anchorage injured. Use only the anchors provided for The tie-downs located on the cargo area child seat tethers. 58) To help protect against personal floor should be used to secure loads injury, passengers should not be seated in safely when the vehicle is moving. the rear cargo area.
Page 57 KNOWING THE INSTRUMENT PANEL This section of the handbook provides EOBD SYSTEM (European On all information that is useful for getting Board Diagnosis) ....56 to know, interpreting, and using the INSTRUMENT PANEL .
Page 58: Eobd System (European On Board Diagnosis)
This check can also be carried out by traffic control officers. WARNING Once the fault has been corrected, to fully check the system, a Jeep Dealership must run bench tests and, if necessary, road tests, which may also call for long journeys.
Page 59: Instrument Panel
INSTRUMENT PANEL Standard instrument panel 5520342D 1. Tachometer 2. Multifunctional display 3. Speedometer (speed indicator) 4. Digital fuel level gage with reserve indicator light (the triangle on the right side of the symbol indicates the side of the vehicle where the fuel filler neck is located) 5. Digital engine coolant temperature gage...
Page 60 Premium instrument panel 5520343D 1. Tachometer 2. Multifunctional display 3. Speedometer (speed indicator) 4. Digital fuel level gage with reserve symbol (the triangle on the right side of the symbol indicates the side of the vehicle where the fuel filler neck is located) 5. Digital engine coolant temperature gage...
Page 61: Display
Standard display The display fig. 54 shows the following 5520347D information: Top left/center/right area (1): Compass, Outside Temperature, Date, Time, Trip A, Trip B, Speedometer (depending on the display customization). Central area of the display (2): car speed, vehicle status information, fuel...
Page 62 Indicator (GSI) system advises the None VEHICLE INFO (Vehicle information) driver to shift gears through a specific Compass indication on the display . Through the Press and release the button Outside Temperature GSI the driver is notified that shifting until the "VEHICLE INFO"...
Page 63: Trip Computer
OK button to display the Trip various values. Possible options are: "US information. Compass (imperial)", "Metric", "Customized". Select “Compass” to change the Trip A Date and Time following settings: "Calibration", Shows the total distance traveled for Select “Date and Time” to set the time "Variance".
Page 64: Indicator Lights And Messages
ON/RUN position. The light should illuminate for approximately four seconds. The light should then turn off unless the parking brake is applied or a brake fault is detected. If it does not switch on, contact a Jeep Dealership. Parking brake on The warning light switches on when the electric parking brake is engaged.
Page 65 In this case, the airbags or pretensioners may not be activated in the event of an accident or, in a more limited number of cases, may be activated when not necessary. Before continuing, contact your Jeep Dealership immediately to have this system checked.
Page 66 ESC system. If this warning light remains on after several ignition cycles and the car has been driven several kilometres at speeds greater than 48 km/h, see your Jeep Dealership as soon as possible to have the problem diagnosed and corrected.
Page 67 The warning light will turn on when the ignition device is in the RUN position before the engine is started. If the warning light does not turn off, contact a Jeep Dealership immediately.
Page 68 Warning light What it means Low tyre pressure The warning light switches on and a message is displayed to indicate that the tyre pressure is lower than the recommended value and/or that slow pressure loss is occurring. In these cases, optimal tyre duration and fuel consumption may not be guaranteed.
Page 69 14) Do not continue driving with one or more flat tires as handling may be compromised. Stop the vehicle, avoiding sharp braking and steering. If a tire puncture occurs, repair immediately using the dedicated tire repair kit and contact a Jeep Dealership as soon as possible.
Page 70 Symbol What it means ALTERNATOR MALFUNCTION If the symbol lights up with the engine running it indicates an alternator malfunction. Please contact your Jeep Dealership as soon as possible. DOOR OPEN The symbol switches on when one or more doors are not completely closed. An acoustic warning sounds when the doors are open and the vehicle is moving.
Page 71 This symbol will illuminate to indicate low engine oil pressure. If the symbol switches on while driving, stop the car immediately, shut off the engine as soon as possible, and contact a Jeep Dealership. The symbol will appear together with an acoustic signal.
Page 72 MIN and MAX marks on the reservoir itself. Also check visually for any fluid leaks. Contact a Jeep Dealership if the symbol comes on when the engine is started again.
Page 73 TOW HITCH MALFUNCTION (where provided) The symbol lights up to indicate a fault to the tow hitch. Please contact your Jeep Dealership as soon as possible. ACTIVE SPEED LIMITER FAILURE (where provided) The symbol switches on in the case of failure of the Active Speed Limiter device. Please contact a Jeep Dealership as...
Page 74 The symbol lights up fixed, together with the symbol and dedicated messages appears on the display in case of failure to the GPF (Gasoline Particulate Filter). In this case please contact a Jeep Dealership as soon as possible. FORWARD COLLISION WARNING SYSTEM (where provided) This symbol lights up, on some versions together with a dedicated message, to indicate a possible accident with the car in front.
Page 75 The water in fuel symbol indicates that water was detected in the fuel filter. If this symbol remains on, DO NOT start the vehicle before you drain the water from the fuel filter to prevent engine damage, and please see a Jeep Dealership.
Page 76 FUEL CUT-OFF SYSTEM FAILURE The symbol lights up, together with a message on the display, when a fuel cut-off system malfunction is detected. Please contact your Jeep Dealership as soon as possible. DEGRADED ENGINE OIL (where provided) Diesel versions: the symbol is displayed on some versions, along with a dedicated message. The symbol is displayed for 3 minute cycles and intervals of 5 seconds until oil is changed.
Page 77 20) The presence of water in the fuel system circuit may cause severe damage to the injection system and irregular engine operation. If symbol comes on contact a Jeep Dealership as soon as possible to bleed the system. If this problem is indicated immediately after refueling, water may have entered the fuel tank.
Page 78 Symbols What it means ADAPTIVE CRUISE CONTROL (ACC) ACTIVE WITHOUT REFERENCE CAR (where provided) This symbol appears when the Adaptive Cruise Control is on and no reference car is detected. Refer to the “Adaptive Cruise Control (ACC)” chapter in the “Starting and driving” section for further information. ADAPTIVE CRUISE CONTROL (ACC) ACTIVE WITH REFERENCE CAR (where provided) This symbol appears when the Adaptive Cruise Control is on and a reference car is detected.
Page 79 Symbol What it means CRUISE CONTROL READY (where present) This symbol will turn on when the Cruise Control has been turned on, but not set. Refer to the “Electronic Cruise Control” chapter in the “Starting and driving” section for further information. SPEED LIMIT EXCEEDED (where present) When the “Speed limiter”...
Page 81 SAFETY The following section is very important: ACTIVE SAFETY SYSTEMS ..80 it describes the safety systems fitted DRIVING ASSISTANCE on the car and provides the necessary SYSTEMS ......86 information on how to use them OCCUPANT PROTECTION correctly.
Page 82: Active Safety Systems
Jeep Dealership to restore driven axle. If one wheel on a driven typically in an emergency braking the brakes anti-lock function.
Page 83 Contact power may also be reduced to help the rear axles by limiting braking pressure a Jeep Dealership as soon as possible to vehicle maintain the desired path. to the rear axle. This is done to prevent have it repaired.
Page 84 Be sure to adapt 48 km/h, see your Jeep Dealership as your speed and driving to the prevailing soon as possible to have the problem road conditions.
Page 85 Park brake must be off. Be sure to adapt your speed and driving a small amount of brake pressure to Driver door must be closed. to the prevailing road conditions. remove any water buildup on the front The vehicle must be on a sufficient brake rotors.
Page 86 wheels in an attempt to stop the trailer 70) The ABS cannot overrule the natural and dangerous way that could jeopardize from swaying. TSC is disabled when the laws of physics, and cannot increase the your own safety and the safety of others. ESC system is in the “Partial Off”...
Page 87 control, vehicle rollover, personal injury and slight rolling may occur, such as on brake pressure prior to releasing the brake and death. minor hills or with a loaded vehicle, pedal. 82) The ESC system cannot overrule or while pulling a trailer. HSA is not a 93) HSA is not a parking brake.
Page 88: Driving Assistance
DRIVING ASSISTANCE know that the system is operational. The the “Multimedia” section for further BSM system sensors operate when the information. SYSTEMS car is in any forward gear or reverse and The Blind Spot Monitoring (BSM) The car can feature the following driving enters stand-by mode when the car is in system may experience drop outs assistance systems:...
Page 89 to the “Operating mode” paragraph for rear detection area with a difference in further information. speed of less than approx. 48 km/h with respect to your car. 0304052893 The BSM system is designed not to issue an alert on stationary objects such as safety barriers, posts, walls, 0304052890 5520447D...
Page 90 "Blind Spot Alert", "Light/acoustic warning" mode When the system is enabled and presence of a vehicle in the blind spot is detected, a visual warning is sent to the door rear-mirror on the side of the detected object. The acoustic warning will sound if the driver switches on the direction 0304052894 030405522...
Page 91 shut off. Each time the car is started the In situations with the risk of collision, previously stored mode will be recalled if the system detects no intervention by and used. the driver, it provides automatic braking to help slow the car and mitigate the Sensors potential frontal accident (automatic If the system detects degraded...
Page 92 This setting provides less reaction deactivates the system, so no warning or but it is recommended that you contact a time than the “Far” and “Medium” autonomous braking will be available in Jeep Dealership as soon as possible. case of a possible collision.
Page 93 TPMS (Tyre Pressure Monitoring The TPMS will warn the driver of a low to approximately 1.9 bars, but the System) tyre pressure if the tyre pressure falls warning light will still be on. In this below the low-pressure warning limit for situation, the warning light will turn OFF 107) 108) 109) 110) 111) any reason, including low temperature...
Page 94 Seasonal temperature changes will The low tyre pressure values appear in a The car may need to be driven for up to affect tyre pressure and the TPMS will different colour. 10 minutes above 24 km/h in order for monitor the actual tyre pressure in the the TPMS to receive this information.
Page 95 Using snow chains. assemblies (road tyres) with wheel and WARNING Using wheels/tyres not equipped with tyre assemblies that do not have TPMS TPMS sensors. sensors, such as when installing winter Space-saver spare wheel (where provided): wheel and tyre assemblies on your car. 98) The BSM system is intended as a driving aid, it does NOT warn the driver of the space-saver spare wheel is not...
Page 96 People, animals and things camera on the windscreen glass. In the (e.g. pushchairs) are not taken into 110) The TPMS cannot indicate sudden event of a sensor failure, contact a Jeep consideration. tyre pressure drops (e.g. if a tyre bursts). Dealership.
Page 97: Occupant Protection
OCCUPANT PROTECTION belt-positioning booster seat in a rear cases, go to a Jeep Dealership to have the seating position. radar sensor realigned or replaced. SYSTEMS 30) The TireKit, which comes with 2. Never allow children to slide the belt Some of the most important safety the vehicle, is compatible with the strap behind them or under their arm.
Page 98 (5 mph) and the driver or front seat The SBR system can be activated or passenger is unbuckled (if the SBR deactivated by your Jeep Dealership. SBR (Seat Belt Reminder) system on driver system for the passenger side front seat...
Page 99 tongue run along the belt to wrap around housing. Accompany the belt movement, your abdomen. if needed, to allow the belt to retract completely. 3. Now, insert the fastening tongue (2) into the buckle (1) (fig. 71) until Three-point seat belt untwisting procedure you hear it click indicating that it is Use the following procedure to untwist a fastened.
Page 100 mini-fastening tongue and buckle, if equipped, should remain connected at all times. If the mini-fastening tongue and buckle become disconnected, they must be properly reconnected prior to the rear centre seat belt being used by an occupant. 1. Grasp the mini-fastening tongue and pull the seat belt over the seat.
Page 101 Its activation is signalled by the optional equipment on others. If you are shortening of the metal cable. not sure, ask a Jeep Dealership. A slight discharge of smoke may be The airbag system must be ready to produced during the activation of the protect you in a collision.
Page 102 If the icon on the display The occupant restraint control unit possible failure of the airbag system. In stays on while driving, go to a Jeep turns on the warning light on the this condition, the airbags may not be...
Page 103 Front airbag and front knee bag positions sensor that detects whether the driver When the occupant restraint control unit or front passenger seat belt is fastened. detects a collision requiring the front This sensor allows you to adjust the airbags, it sends a signal to the inflation inflation level of the front airbags.
Page 104 If any of the With the ignition device set to ON or following occurs, have a Jeep Dealership 153) 154) 155) 119) RUN, a LED with the amber symbol service the airbag system immediately:...
Page 105 Press the “OK” button on the steering Press the “OK” button on the car central dashboard will illuminate wheel to select “Passenger airbag OFF“ steering wheel to enter the “Vehicle indicate that the passenger front airbag Settings” will deploy during a collision. DO NOT Scroll up or down using the assume that the passenger front airbag is Scroll up or down to select “YES”...
Page 106 Side bag label location Following the actions in the table above bags, please refer to the information will enable (ON) the passenger front below. airbag. The LED above the climate The window bags are located above the control system panel on the central side windows.
Page 107 Airbag system components at an even greater risk of injury from a angled or offset frontal collisions where deploying airbag. the front airbags deploy. NOTE The occupant restraint control The window bags (where provided) Side airbags are a supplement to the unit monitors the internal circuits and may help reduce the risk of partial or seat belt restraint system.
Page 108 Turn on the interior lights, which are a normal by-product of the process If you have any doubt, contact a Jeep remain on as long as the battery has that generates the non-toxic gas used for Dealership.
Page 109 Customer action Effect of the action Customer action Effect of the action Customer action Effect of the action 1. Turn the ignition Right direction Turn hazard flashers device to the OFF indicator light is OFF (Manually). 7. Activate the right position.
Page 110 How fast the car was travelling. be protected with suitable restraining a rear-facing child seat. Always comply devices. Statistics on accidents indicate This information can help provide with the instructions on the passenger that the rear seats offer greater safety for a better understanding of the side sun visor (see "Front passenger airbag and child seat”...
Page 111 Jeep Dealership with seats and seat belts. slack so that it is comfortable and not immediately and have it fixed.
Page 112 139) The pretensioner may be used only objects could cause harm if the vehicle is the airbags or pretensioners may not be once. Contact a Jeep Dealership to have it in a collision severe enough to cause the activated in the event of an accident or, replaced after it has been deployed.
Page 113 Take knee impact bolsters such as alarm lights, appropriate for the size of the child. your vehicle to a Jeep Dealership for stereos, citizen band radios, etc. 165) Side Air Bags need room to inflate.
Page 114 Any child riding in your vehicle should be in a proper child restraint system for the child’s size.
Page 115 In Europe the characteristics of child restraint systems are ruled by the regulation ECE-R44, dividing them into five weight groups: Group Weight ranges Size class / Fixing ISO/L1 Group 0 Indicatively up to 9 months up to 10 kg in weight ISO/L2 ISO/R1 ISO/R1...
Page 116 WARNING 173) Extreme Hazard! Never place a rearward facing child restraint in front of an active air bag. Refer to the warnings on the sun visor labels. Deployment of the air bag in an accident could cause fatal injuries to the baby regardless of the severity of the collision. It is advisable to always carry children in a child restraint system on the rear seat, which is the most protected position in the event of a collision.
Page 117 Child restraint system Group 2 induce stress on the neck in the event of installation with universal seat sudden decelerations or a collision. belts The rearward-facing child restraint is restrained by the vehicle’s seat belts, as The figures in the following sections shown in fig.
Page 118 Children who weigh between 22 kg and 179) When your child restraint system is 36 kg and who are tall enough to use not in use, secure it in the vehicle with the adult belt strap may use a Group 3 the seat belt or ISOFIX anchorages, or remove it from the vehicle.
Page 119 FRONT PASSENGER AIRBAG AND CHILD RESTRAINT SYSTEMS: ATTENTION F1B0129C...
Page 120 Seat belts for children over 12 ISOFIX Restraint System run your finger along the gap between years of age the seatback and seat cushion. Children over 1.50 m in height can wear seat belts instead of using child restraints. Use this simple 5-step test to decide whether the seat belt properly fits the child or if they should still use a Group 2 or Group 3 child restraint to improve the...
Page 121 5520382D Center Seat ISOFIX 185) 186) 187) WARNING 184) Never allow a child to put the belt strap under an arm or behind their back. In a crash, the belt strap will not protect a child properly, which may result in serious injury or death.
Page 122 Child restraint system installation The table below shows the various installation possibilities for ISOFIX child restraint systems on seats fitted with ISOFIX anchorages in accordance with European standard ECE 16. The following table provides guidelines on positioning child restraint systems on the vehicle seats.
Page 123 Number of seats Seat number Airbag Airbag ENABLED DISABLED Sear suitable for ISOFIX forward facing fixtures (F2/ F2X / F3) (IUF) Seat suitable for forward facing child restraint YES (only B2) YES (only B2) systems fixtures (B2/B3) (IUF) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal"...
Page 124 Installing an ISOFIX child should not move more than 25 mm in restraint system any direction. 1. Loosen the adjusters on the lower 188) 189) 190) connectors and on the tether strap of the Installing child restraints using child seat so that you can more easily the top tether anchorage attach the connectors to the vehicle 1.
Page 125 Compatibility between the vehicle harnesses or for attaching other items or seats and the child restraint systems is equipment to the vehicle. better: the i-Size child restraint systems 190) Install the child restraint system can be considered as "Super ISOFIX"; when the car is stationary.
Page 126 ® using the seat belt with three anchor points or the ISOFIX anchorages. IMPORTANT Jeep recommends fitting the child restraint system according to the instructions, which must be included. Weight group...
Page 127 Group 2: from 15 to 25 kg from 95 approval number: E1 04301304, present. Jeep recommends cm to 135 cm Jeep order code: 71807984 installing the child restraint system using the vehicle’s ISOFIX anchor points. The child restraint system must be fitted on the rear seats.
Page 128: Safety Tips
Do not disassemble or secured by seat belts. See a Jeep Dealership for service if your modify the system. defroster is inoperable. Front seat belt assemblies must be...
Page 129 Lights which is colorless and odorless. Breathing approved floor mat for the specific make, Have someone observe the operation it can make you unconscious and can model, and year of your vehicle. eventually poison you. To avoid breathing 203) ONLY use the driver’s side floor of brake lights and exterior lights while (CO), follow these safety tips: Do not mat on the driver’s side floor area.
Page 130 Blank page...
Page 131 STARTING AND DRIVING We have now reached the "heart" of the STARTING THE ENGINE ..130 DRIVING TIPS ....174 vehicle: let's see how to use the vehicle ENGINE BREAK-IN .
Page 132: Starting The Engine
STARTING THE ENGINE Dual clutch automatic transmission If the problem persists, contact a Jeep versions Dealership. NOTE Engine start up in very low Before you start the vehicle, adjust the Proceed as follows: ambient temperature could result in seat, the inside and outside mirrors and engage the electric parking brake evident white smoke.
Page 133 STARTING AFTER EXTENDED Cars equipped with electronic key (Keyless WARNING PARKING Enter-N-Go): To switch off the engine hold down the NOTE Extended Park condition occurs 209) It is dangerous to run the engine in ignition device button for a while or when the vehicle has not been started or enclosed areas.
Page 134: Engine Break-In
ENGINE BREAK-IN 217) Make sure that the ignition device is IMPORTANT in the OFF position, remove the key fob RECOMMENDATIONS FOR from the vehicle and lock the vehicle. BREAKING IN THE ENGINE 34) A quick burst on the accelerator 218) Never leave children alone in a before turning off the engine serves A long break-in period is not required for vehicle, or with access to an unlocked...
Page 135: Parking
WARNING Should the vehicle battery IMPORTANT WARNING be faulty, to unlock the electric parking brake the battery must be replaced. 37) Never use non-detergent oil or 223) Never leave children unattended in If You Wish To Manually Lock The Steering straight mineral oil in the engine or the car.
Page 136 The parking brake should always be The parking brake can be applied even brake pedal movement while the park applied whenever the driver is not in the when the ignition device is the OFF brake is engaging. vehicle. position (in this case the warning Automatic deactivation of the electric light will not turn on, however, it can...
Page 137 Vehicle speed is below 3 km/h. lock your vehicle. Have the brake system serviced by a Jeep There is no attempt to depress the 228) Never leave children alone in a Dealership immediately.
Page 138: Manual Transmission
MANUAL TRANSMISSION IMPORTANT (where provided) 39) Never drive with your foot resting on the clutch pedal, or try to hold the vehicle 233) 234) on a hill with the clutch pedal partially engaged, as this will cause abnormal wear 39) 40) on the clutch.
Page 139: Twin Clutch Automatic Transmission
Shifting from D to N is free, while engine to overspeed if too low of a gear shifting from D to R or P can only be is selected and the clutch pedal is made by the button on the gear lever. released.
Page 140 STARTING THE ENGINE VEHICLE SHUTDOWN WARNING The inconsistency between the speed actually engaged and the Starting the engine is allowed only when Versions with Keyless Enter-N-Go system: position of the gear lever is indicated by the gear lever is in position P or N. When shift the gear lever to P (Park) before the letter corresponding to the position the engine is started, the system is...
Page 141: Stop&Start System
If even positioning the gear lever to R or N. pollution. the problem persists, contact a Jeep Once you have put the gear lever in the P Dealership. WARNING The system is activated...
Page 142: Speed Limiter
ACTIVATING THE SYSTEM 49) When replacing the battery, always To activate the system, press the contact a Jeep Dealership. Replace the battery with the same type (EFB - button on the steering wheel fig. 98. Enhanced Flooded Battery) and with the same specifications.
Page 143: Electronic Cruise
SET –: quick speed limit programming Traveling downhill, the system could There is a risk of inadvertently activating (saves a lower value); brake the car to keep the set speed it and losing control of the car due to RES: device activation (the device unvaried.
Page 144: Adaptive Cruise Control (Acc)
240) In case of a malfunction or failure of 242) the device, contact a Jeep Dealership. RESUMING THE SET SPEED 241) The electronic Cruise Control can To resume a previously set speed, push be dangerous if the system cannot keep the RES button and release.
Page 145 6. RES (Resume) When the dual clutch automatic transmission is in the P (Park), R 7. SET (-) (Deceleration) (Reverse) or N (Neutral) position. 8. Speed Limiter When the Vehicle speed is outside of NOTE Any chassis/suspension or tire size the speed parameters.
Page 146 DEACTIVATION The system will not be controlling the display. For more information, refer to distance between your vehicle and the the “Display” chapter in the “Knowing The device is deactivated and the set vehicle ahead. The vehicle speed will the instrument panel” section. speed is canceled if: only be determined by the position of the Press the SET +/- button once: the...
Page 147 If an ACC host vehicle follows a target the vehicle ahead leaves the lane or NOTE The device detects the direction vehicle to a standstill, after two seconds the detection field of the Adaptive Cruise of traffic automatically when the car the driver will either have to push the Control device sensor;...
Page 148 PRECAUTIONS WHILE DRIVING changing lanes and it may not detect the vehicle until it's too late for the ACC The device may not work correctly in system to take action. some driving conditions (see below): the driver must control the car at all times. In this case, sufficient distance from the vehicle which is changing lane may Towing a trailer...
Page 149 ELECTRONIC CRUISE CONTROL or moving in the crosswise direction and MODE stationary objects (e.g. a vehicle standing in a queue or a broken down vehicle). Electronic Cruise Control mode is 246) The device cannot take account of available for traveling at constant speed road, traffic and weather conditions and in addition to the Adaptive Cruise Control conditions of poor visibility (e.g.
Page 150: Sport Mode
If the target during parking manoeuvres). In these vehicle does not start moving within cases, go to a Jeep Dealership to have the 51) The system may have limited three minutes, the parking brake will be radar sensor realigned or replaced.
Page 151: Idle Coasting
Battery disconnection. In this case the until the vehicle speed is increased is shown on the display as long as following procedure must be carried out: to approximately 11 km/h or above. SPORT mode is active. When in reverse and above the system's start the engine;...
Page 152 arc moving closer to the vehicle and by the driver, faulty or temporarily required” message to be displayed in the the audible chime will increase as the deactivated. instrument panel display. objects gets close to the vehicle. ParkSense System Usage NOTE If any objects are attached to the NOTE When the system acoustic Precautions...
Page 153: Parksense System - Versions With 12 Sensors
Jeep The system will become active again if and shape, giving a false indication that Dealership.
Page 154 increase as the objects gets close to the the vehicle and the audible chime will ParkSense will retain its last known vehicle. increase as the objects gets close to the configuration state through ignition vehicle. cycles. NOTE When the system acoustic Enabling And Disabling warning is heard, the volume of the NOTE When the system acoustic...
Page 155 Activation - Deactivation presence on the surface of the sensor of: There may be a delay in the object ice, snow, mud, thick paint. detection rate if the object is moving. The system can operate only after driving Jackhammers, large trucks, and other The operation of the rear sensors is a short distance and if the vehicle vibrations could affect the performance...
Page 156 The presence of a tow hook without sensors could detect the ball mount and area of the sensors carried out by a Jeep a trailer may interfere with the correct hitch ball assembly, depending on its size Dealership.
Page 157: System
ACTIVE PARKSENSE hands from the steering wheel, the The parking maneuver is completed. system will cancel, and the driver will Vehicle speed greater than 30 km/h (AUTOMATIC PARK be required to manually complete the when searching for a parking space. ASSIST) SYSTEM parking maneuver.
Page 158: Active Parksense (Automatic Park Assist)
Rear liftgate is closed. Active ParkSense (Automatic Park Assist) forward to position the vehicle for a Vehicle speed is less than 25 km/h. system will automatically search for a parallel parking sequence. parking space on the passenger's side of NOTE If the vehicle is driven above Area detected - Continue moving forward the vehicle if the direction indicator is approximately 25 km/h, the instrument...
Page 159 The Active ParkSense (Automatic Park to position D (for versions with dual When the car is stationary, you will be Assist) system allows a maximum of automatic transmission) or to first gear prompted to shift the gear lever to the six shifts between the D (Drive) and (for versions with manual transmission).
Page 160 Check the surroundings - Wait for appears on the instrument panel display. The feature will only indicate the The arrow buttons on the left side of the last detected parking space (example: completion of the maneuver steering wheel can be used to switch if passing multiple available parking The system will then instruct the driver parking maneuvers.
Page 161 When the vehicle has reached the end will instruct the driver to check their (Park) or the manual transmission gear of its backward movement, the system surroundings and stop the vehicle’s lever in first gear. The notification will instruct the driver to check their movement.
Page 162 automatically for exiting the parking a completed maneuver. At the end of anti-parking posts, pavements, rubbish space. If the driver continues to carry out the maneuver, the system gives back the bins, motor vehicles, etc.). Always take a voluntary or involuntary action on the vehicle control to the driver.
Page 163: Lanesense System
(no direction area of the sensors carried out by a Jeep to lapse during potentially dangerous indicator applied), the LaneSense system Dealership. Incorrect paint application...
Page 164 ENABLING / DISABLING THE With standard display: when the Lanes Sensed (white lines/green symbol SYSTEM LaneSense system senses the lane has been approached and is in a lane When the engine is started, the system With standard display: when the departure situation, the left thick lane is disabled (LED on the button in the LaneSense system senses a lane drift...
Page 165 Changing the system settings rear view mirror. In the event of a failure The LaneSense system has settings of the camera, contact a Jeep Dealership. to adjust the intensity of the steering 75) Do not cover the operating range of wheel torque (Low / Medium / High) and the camera with stickers or other objects.
Page 166: Rear Camera (Parkview Rear Backup Camera)
REAR CAMERA REFUELING THE VEHICLE 264) (PARKVIEW REAR Before refueling, check you are using the BACKUP CAMERA) correct type of fuel. Furthermore, turn off the engine before WARNING refueling. (where provided) Gasoline Engine 264) The driver is always responsible Every time reverse is engaged, the for parking and other potentially Only use unleaded petrol with an octane display shows the area around the car, as...
Page 167 REFUELING PROCEDURE Then remove the nozzle from the filler and close the flap. Opening the flap To refuel proceed as follows: Open the flap fig. 110, from the point shown by the arrow 5520335D 3. Ensure funnel is inserted fully to hold flapper door open.
Page 168 TOPPING UP AdBlue ® DIESEL 3. Remove the access flap (1) fig. 114 Refilling with containers located on right interior trim panel to EMISSIONS ADDITIVE Proceed as follows: release the cable with the tip of your key. (where provided) (Diesel versions only) check the expiration date;...
Page 169 ® the container. Diesel fuel tank, this can result in serious engine damage, contact a Jeep Dealership. B7: Diesel containing up to 7% (V/V) Do not add additives or other fluids 271) of FAME (Fatty Acid Methyl Esters)
Page 170: Additive For Diesel Emissions Adblue
B10: Diesel containing up to 10% (V/V) vapours are not harmful or dangerous to If you notice a pungent burning odor or of FAME (Fatty Acid Methyl Esters) health. some light smoke, your engine may be compliant with EN16734. 271) Carbon monoxide (CO) in exhaust out of tune or malfunctioning and may require immediate service.
Page 171: Trailer Towing
For more information on the AdBlue The weight that the trailer exerts on the ® liquid type, see the “Fluids and tow hitch of the vehicle reduces the lubricants” chapter in the “Technical load capacity of the vehicle itself by the Data”...
Page 172 If even only one of the requirements is system. not met the tow hook must not be used, since there is risk of causing accidents. Contact a Jeep Dealership for any such 5520350D operations. The ball head tow bar can be fitted/removed manually, without requiring specific equipment.
Page 173 REMOVABLE BALL HEAD TOW BAR J0A0423...
Page 174 Should the removable ball head bar loading position even when the knob is Installing the ball head tow bar require repair, only consult with a Jeep released. Remove the cap from the mounting pipe. Dealership.
Page 175 towing a trailer, never exceed the GAWR An electronically actuated trailer brake Be sure to reconnect once clear from or GCWR ratings. controller is required when towing a water area. trailer with electronically actuated Towing tips 274) 275) brakes. When towing a trailer equipped Before setting out on a trip, practice Towing requirements - tires with a hydraulic surge actuated brake...
Page 176: Driving Tips
Highway driving DRIVING TIPS GAWR, 4. Tongue weight rating for the Reduce speed. trailer hitch utilized. Temporarily turn off air conditioning. 276) Do not connect the trailer brakes to the hydraulic lines of the car braking ON-ROAD DRIVING TIPS system, overloading on the trailer may As with other vehicles of this type, WARNING cause failure.
Page 177 Unnecessary Procedures When transporting particularly large fuel consumption (from +15 to +30% in objects, preferably use a trailer. the urban cycle) and emissions. Avoid punching the accelerator when the vehicle is stationary at traffic lights or Electrically-powered Accessories Traffic and road conditions before turning off the engine.
Page 178 - drive straight up drivetrain components, steering, and In heavy snow, when pulling a load, or or down. suspension. If yes, contact a Jeep for additional control at slower speeds, If the wheels start to slip as you Dealership.
Page 179 After prolonged use on terrain which water may cause damage that may not is muddy or sandy or characterized by be covered by the New Vehicle Limited water courses or similar, check the Warranty. radiator, fan, brake pads and discs and tire conditions and clean them as soon as possible;...
Page 180 Blank page...
Page 181 IN CASE OF EMERGENCY Have a flat tire or a burnt-out bulb? HAZARD WARNING LIGHTS ..180 At times, a problem such as these may SOS CALL AND ASSIST interfere with your driving experience. CALL ......180 The pages on emergencies can help BULB REPLACEMENT .
Page 182: Hazard Warning Lights
HAZARD WARNING The lights will turn off automatically are advised to consult the Connectivity when the braking is no longer deemed to section of the Jeep website for updates LIGHTS be emergency braking. on the terms of service. Press the button fig. 121 to turn the SOS CALL AND ASSIST lights on/off.
Page 183 Privacy: GPS location is always Once the connection has been active, for both SOS and Assist calls. established, the following data will Press and hold icons to drag to menu bar below. Deactivating it via the "Settings" menu of be automatically transmitted to the Radio ASSIST WiFi...
Page 184 Contact a Jeep Dealership as soon as The call will be made through the car and/or on the display fig. 124 of the possible. sound system to provide any additional Uconnect™ system will call one or more information about the assistance...
Page 185: Bulb Replacement
It will disappear during could affect or entirely prevent service normal use. operation. NOTE Regardless of charge, the battery must be replaced every 5 years by a Jeep dealership. BULB REPLACEMENT 281) 282) 283) 284) 285) 286) 287) GENERAL GUIDELINES...
Page 186 Low beam / high beam headlights (halogen) Front side lights/Daytime Running Lights (DRL) PSX24W Front direction indicator lights 7444NA LED (Contact a Jeep Dealership for Front side lights – Premium LED – replacement) Front fog lamps D3S (HID) (Contact a Jeep –...
Page 187 Lamps type power LED (Contact a Jeep Dealership for – Liftgate lamp tail replacement)
Page 188 8. Reinstall the wheel liner. clockwise. NOTE The procedure is described by 8. Reinstall the wheel liner. way of example only. Contact a Jeep WARNING The procedure is described Dealership for replacement. by way of example only. Contact a Jeep Dealership for replacement. 289)
Page 189 Contain the following: 4. Replace bulb and twist the socket Side lights NOTE It is advisable to contact a Jeep clockwise to reinstall. Stop lights Dealership. Direction indicator 5. Reinstall the lamp by snapping in the...
Page 190: Fuse Replacement
7. Finally close the liftgate. transparent light bulb is in contact with ENGINE COMPARTMENT FUSE NOTE It is advisable to contact a Jeep the fingers, reduces the intensity of the emitted light and you can also affect the Dealership.
Page 191 Removing the mounting screw and removing the fuse box cover Proceed as follows: 1. Slowly turn the screw (1) fig. 134 counterclockwise. 2. Slowly release the screw. 3. Remove the fuse cover (2) by sliding it upward. Fuse puller To replace a fuse, use the puller attached to the cover of the engine compartment fuse box (see fig.
Page 192 INSTRUMENT PANEL FUSE BOX The fuse box fig. 139 is located near the left side of the steering column and the fuses can be accessed easily from the lower part of the dashboard. To replace the fuses, contact a Jeep Dealership. J0A0114C...
Page 193 ENGINE COMPARTMENT FUSE BOX Position Maxi fuse Cartridge fuse Mini fuse Description – – 40 Amp orange TTM supply – – 20 Amp yellow Horn – – 20 Amp yellow 12V rear cargo outlet ignition powered – – 7.5 Amp brown Air conditioner compressor –...
Page 194 WARNING 290) When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. Never replace a blown fuse with metal wires or any other material.
Page 195 INSTRUMENT PANEL FUSE BOX Position Foil fuse Description 20 A yellow Passenger side electric window motor 20 A yellow Driver side electric window motor Uconnect box, UCI/USB door, climate control system and radio controls, sunroof controls, electronic steering lock, safety gateway, EOBD 20 A yellow socket, air conditioning system power, radio power, window/rear-view mirror controls on...
Page 196 Rear Cargo Fuse/Relay Distribution Unit To access the fuses, remove the access door from the left rear panel of the rear cargo area. The fuses may be contained in two units. Fuse holder No. 1 fig. 140 is located closest to the rear of the vehicle and fuse holder No. 2 (if equipped with trailer towing) is located closest to the front of the vehicle.
Page 197 Fuse holder no. 1 Position Mini fuse Description 30 Amp green Socket for 230V power supply 30 Amp green Memory seat Sunroof – if equipped 20 Amp yellow 30 Amp green Power seat (pass) 30 Amp green Power seat (driver) 7.5 Amp brown Power lumbar (power seats) 15 Amp blue...
Page 198 Position ATO / Uni-Val Fuse Description 25 Amp clear HIFI sound system...
Page 199: Changing A Wheel
CHANGING A WHEEL Jack and tools The jack is located in the tool container under the spare wheel. 294) 295) JACK EXTRACTION JACK 1. Open the liftgate. Please note that: 2. Lift the access cover using the load the jack requires no adjustment; floor handle.
Page 200 CHANGING PROCEDURE Jacking instructions 296) 297) 298) 299) 300) 301) 302) stop the car in a position that is not Jack warning label dangerous for oncoming traffic where you can change the wheel safely, as far as possible from the side of the road. The ground must be as flat and solid as possible engage the hazard warning lights and...
Page 201 (see fig. 150). In the case of any doubts regarding the bolts tightening torque, contact a Jeep Dealership; 5520395D Front jacking location 5520393D Jacking locations...
Page 202 Jeep Dealership where it can be is limited in these conditions. This come loose; raised on a lift.
Page 203 Do not get under a raised vehicle, take it to a with the space-saver wheel fitted. Avoid Jeep Dealership where it can be raised on use the jack to lift loads heavier than that violent acceleration and braking, abrupt a lift.
Page 204: Tirekit
TIREKIT puncture, change the tire respecting the laws of the country you are traveling in; (where provided) insert the sealant cartridge (A) into the corresponding compressor compartment DESCRIPTION (B) and press it down hard. Remove the 306) 307) 308) 309) 310) 311) 312) 313) 314) 315) speed limit sticker (C) and apply it in a clearly visible position;...
Page 205 If, however, the engage the electric handbrake. Take the pressure is lower than 1.8 bar / 26 psi, compressor and restore pressure using do not resume driving but contact a Jeep the black inflation tube (L). Dealership. J0A0957...
Page 206 - overheating hazard. regulations. the tire is too damaged. Contact a Jeep 307) Damage to the sides of the tire Dealership for any such operations. cannot be repaired. Do not attempt to use...
Page 207: Jump-Starting
(+) to the positive terminal system of the car could be damaged. the vehicle battery and charging system (+) of the vehicle with the discharged checked by a Jeep Dealership. Do not attempt jump-starting if the battery battery is frozen. The battery could...
Page 208: Dual Clutch Automatic Transmission Lever
lever assembly (fig. 158) and press down 318) The batteries contain acid that can devices, if left connected too much time on the release lever; burn skin or eyes. Batteries produce with engine off, may cause the battery to hydrogen, which is easily flammable and drain with following reduction of its life explosive.
Page 209: Freeing A Stuck Vehicle
(3) releasing it from its housing; 90) It is advisable to contact a Jeep rocking motion, without spinning the pull tab (4) fig. 161 downwards using Dealership to have the refitting procedure wheels, or racing the engine.
Page 210: Towing A Disabled
to “Electronic Brake Control” in “Safety” can also damage the tires. Do not spin the for further information. Once the car has wheels above 48 km/h while in gear (no been freed, press the button again to transmission shifting occurring). restore the ESC engagement mode.
Page 211 Towing condition Wheels off the ground Towability Flat tow NONE NOT ALLOWED Rear NOT ALLOWED Wheel lift or dolly tow Front Flatbed BEST METHOD...
Page 212 NOTES: automatic transmission so as to able to You must ensure that the Auto Park move the car. Brake feature is disabled before towing 92) 93) 94) 95) this vehicle to avoid inadvertent Electric Keyless models Park Brake engagement. The automatic Particular attention must be dedicated parking brake function is enabled or when towing the car with the ignition...
Page 213 Insert the flat end of the jack handle 325) Do not use a chain with a tow eye. through the tow eye and tighten, refer Chains may break, causing serious injury to “Replacing a wheel” in this section or death. for further information.
Page 214 94) Ensure that the Electric Park Brake is released, and remains released, while being towed. 95) Do not use a bumper mounted clamp- on tow bar on your vehicle. The bumper face bar will be damaged. 96) Towing this vehicle in violation of the above requirements can cause severe engine and/or transmission damage.
Page 215 MAINTENANCE AND CARE Proper maintenance allows vehicle SCHEDULED SERVICING ..214 performance to be maintained over ENGINE COMPARTMENT ..221 time, operating costs to be contained, CHARGING THE BATTERY ..225 and safety system performance to be MAINTENANCE safeguarded.
Page 216: Scheduled Servicing
Failure to have them carried out may following conditions: invalidate the warranty. It is advisable Law enforcement (or security service), to inform a Jeep Dealership of any small taxi service operating irregularities without waiting towing a trailer or caravan; for the next service.
Page 217 SCHEDULED SERVICING PLAN (gasoline versions) WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations! ...
Page 218 Thousands of miles Thousands of kilometers Years Replace passenger compartment filter Spark plug replacement(2) Visually inspect the condition of the accessory drive belt(s) Check tension of accessory drive belt (versions without automatic tensioner) Replace accessory drive belt(s) (3) Check oil level of electro- hydraulic actuator and top up, if necessary (versions with dual-clutch automatic...
Page 219 Scheduled Servicing Plan. To change the spark plugs you are advised to contact a Jeep Dealership. (3) The maximum mileage is 120,000 km/72,000 miles. The belt must be replaced every 6 years, regardless of distance travelled. If the car is used in heavy conditions (dusty areas, especially severe weather conditions, very low or very high temperatures for extended periods, urban driving, long periods of idling), the maximum mileage is 60,000 km/36,000 miles.
Page 220 SCHEDULED SERVICING PLAN (Diesel versions) WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations! ...
Page 221 Thousands of miles Thousands of kilometers Years Replace passenger compartment filter Change the brake fluid every 24 months if using DOT 4 brake fluid (3) Replace fuel filter cartridge Visually inspect the condition of the accessory drive belt(s) (2) Replace accessory drive belt(s) Change the manual transmission fluid if the car is used in the following ways:...
Page 222 Thousands of miles Thousands of kilometers Years Uconnect Box system battery replacement (where provided) (1) The actual oil and engine oil filter replacement interval depends on car usage conditions and is indicated by means of a warning light/symbol or message on the instrument panel. It should not exceed 20.000 km/12.500 miles or 1 year. (2) Areas that are not dusty: recommended maximum distance 120,000 km/75,000 miles.
Page 223: Engine Compartment
ENGINE COMPARTMENT 1.3 version 5520384D 1. Engine oil dipstick 2. Cap/engine oil filler 3. Engine coolant 4. Windshield/rear window washer fluid 5. Brake fluid 6. Battery...
Page 224 1.6L Diesel engine 5520385D 1. Engine oil dipstick 2. Cap/engine oil filler 3. Engine coolant 4. Windshield/rear window washer fluid 5. Brake fluid 6. Battery...
Page 225 5,000 - The transmission control oil level should The engine oil level dipstick (1) is 6,000 km. only be checked at a Jeep Dealership. integral with the cap (2). Unscrew the cap, clean the dipstick with a lint-free ENGINE COOLANT...
Page 226 It is advisable to contact loosening the filler cap, particularly for For battery replacement, contact an a Jeep Dealership to have the fluid vehicles with aluminium cap (where authorized dealership. changed. provided). WARNING: risk of burns!
Page 227: Charging The Battery
If a "fast charger" is used while the environment. To change the oil and battery is in the vehicle, disconnect both filters, it is advisable to contact a Jeep vehicle battery cables before connecting Dealership. the battery charger. Do not use a "fast charger"...
Page 228: Maintenance
MAINTENANCE WARNING Do not operate the windshield wiper with the wiper blades raised from PROCEDURES the windshield. Installing the front wipers Lift the wiper arm off of the glass, 110) 111) 112) until the wiper arm is in the full up WINDSHIELD WIPER/REAR position.
Page 229: Raising The Vehicle
RAISING THE VEHICLE IMPORTANT If the vehicle needs to be raised, go to a Jeep Dealership, which is equipped with 110) Incorrect servicing of the car or ground lifts or workshop lifts. failure to carry out operations or repairs (when necessary) may lead to more...
Page 230: Wheels And Tires
WHEELS AND TIRES Tire rotation recommendations IMPORTANT 347) The tires on the front and rear of your 114) To avoid damage to your vehicle or SAFETY INFORMATION vehicle operate at different loads and tires, observe the following precautions: Before embarking on a long trip, and perform different steering, handling, and Because of limited chain clearance approximately every two weeks, check...
Page 231: Storing The Vehicle
STORING THE VEHICLE do not drain the engine cooling IMPORTANT system; If the car is left inactive for longer than a any time the car is left inactive for month, the following precautions should 115) Before removal of the positive and two weeks or more, operate the air be observed: negative terminals to the battery, wait...
Page 232 WARNINGS the car by hand only, using pH-neutral IMPORTANT detergents Avoid parking the vehicle under trees Dry it with a damp chamois leather. as much as possible; resins dull the 116) In order to preserve the appearance Abrasive products and/or polishes should paintwork and increase the possibility of of the paint abrasive products and/or not be used for cleaning the car.
Page 233 IMPORTANT 4) Detergents pollute the water. The vehicle should be washed in areas equipped for collecting and purifying the liquid used in the washing process.
Page 234 Blank page...
Page 235 TECHNICAL DATA Everything you may find useful for IDENTIFICATION DATA ..234 understanding how your vehicle is made ENGINE ......236 and works is contained in this section RIMS AND TIRES .
Page 236: Identification Data
IDENTIFICATION DATA Vehicle Identification Number The chassis number (VIN) is indicated in the front left corner of the windscreen and can be seen from outside the car (fig. 175). The VIN is also printed on the front right part of the body, on the front floor (fig.
Page 237 5520401D...
Page 238: Engine
ENGINE Versions 1.3 130HP 1.3 150HP 1.6 Multijet 120HP Typical code 55282328 55282328 55280444 Cycle Otto Otto Diesel Number and position of cylinders 4 in line 4 in line 4 in line Piston bore and stroke (mm) 70 x 86.5 70 x 86.5 79.5 x 80.5 Total displacement (cm³)
Page 239: Rims And Tires
RIMS AND TIRES Load index (capacity) 348) 60 = 250 kg 80 = 450 kg Alloy rims, tubeless radial tires. 61 = 257 kg 81 = 462 kg All approved tires can also be found in the Vehicle Registration. 62 = 265 kg 82 = 475 kg WARNING In the event of any...
Page 240 CORRECT READING OF THE RIM Example fig. 181: 7J x 17 H2 ET 37.5 7 width of the rim in inches (1). J rim drop center outline (side projection where the tire bead rests) (2). 17 fitting diameter in inches (corresponds to the diameter of the tire to be fitted) ((3) = Ø).
Page 241 STANDARD RIMS AND TIRES 349) 350) Versions Rims Tyres Snow tyres 6.5J x 19 ET40 (*) 205/55 R19 97H (*) 205/55 R19 97Q (M+S) 6.5J x 16 ET40 (*) 215/65 R16 98H (*) 215/65 R16 98Q (M+S) 215/60 R17 96H 7J x 17 ET37.5 215/60 R17 96Q (M+S) 1.3-litre 130 HP...
Page 242 WARNING 349) DO NOT fit wheel hub caps when using integral hub caps fixed (with springs) to the steel rim and tires provided with Rim Protector. The use of unsuitable tires and hub caps could cause a sudden pressure loss of the tire. 350) If winter tyres with a lower speed rating than that indicated in the Registration Document are used, do not exceed the maximum speed corresponding to the speed rating of the tyres used.
Page 243 COLD TIRE INFLATION PRESSURE When the tires are warm, the inflation pressure should be +0.3 bar in relation to the prescribed value. However, recheck that the value is correct with the tire cold. For snow tires, the inflation pressure should be +0.2 bar in relation to the specified value for the standard tires. If it is necessary to jack the vehicle, refer to the "Jacking the Vehicle"...
Page 244: Dimensions
DIMENSIONS Dimensions are expressed in mm and refer to the car equipped with its original tires. Height refers to the vehicle when unladen. 5520426D 1624 (*) / 4394 2636 1547 1819 1542 1819 1629 (**) (*) Without roof rack bars (**) With roof rack bars...
Page 245 5520462D Minimum ground clearance / typical angles Minimum ground clearance Approach angle (B) Departure angle (C) Breakover angle (D) – mm (A) 1.3 130HP(*) 15.8° 30.8° 21.8° 1.3 150HP(**) 15.8° 30.8° 21.8° 1.6 Multijet 120HP 15.8° 30.8° 21.8° (*) Versions with manual transmission (**) Version with dual-clutch automatic transmission Minimum ground clearance (Reference A)
Page 246 Departure angle (Reference C) The departure angle is determined by the same lines of the “Approach angle”, and refers to the rear part of the vehicle. Breakover angle (Reference D) The value of the “Breakover angle” is linked to the ground clearance of the vehicle and indicates the attitude of the vehicle to overcome a wedge, more or less steep, preventing the vehicle from resting on the ground with the body or chassis after touching the wedge with its lowest and most projecting parts (usually the underbody), because this would highly reduce wheel grip.
Page 247: Weights
WEIGHTS Weights (kg) 1.3-litre 130 HP 1.3-litre 150 HP 1.6-litre Multijet 120 HP Unladen weight (with all liquids, fuel tank filled to 90% and without optional 1430 1430 1540 equipment) Payload including the driver (*) Maximum permitted loads (**) –...
Page 248 119) IMPORTANT 119) Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles. This could cause you to lose control.
Page 249: Refuelling
REFUELLING Prescribed fuels and original 1.3-litre 130 HP 1.3-litre 150 HP lubricants Fuel tank (litres): Unleaded petrol with at least 95 R.O.N. (EN228 specifications) Including a reserve of (litres): Mixture of demineralised water and Engine cooling system (litres): 50% PARAFLU UP (*) Engine sump (litres): SELENIA DIGITEK P.E.
Page 250 Prescribed fuels and original 1.6-litre 16V Multijet lubricants Fuel tank (litres): Diesel for motor vehicles (EN590 Specification) Including a reserve of (litres): AdBlue ® (DIN 70 070 and ISO AdBlue® tank (where provided) capacity approximately (litres): 22241-1 specifications) Mixture of demineralised water and Engine cooling system (litres): 50% PARAFLU UP (*) Engine sump and filter (litres):...
Page 251: Fluids And Lubricants
FLUIDS AND LUBRICANTS The engine oil used in your vehicle has been carefully developed and tested to meet the requirements of the Scheduled Servicing Plan. Always using the lubricants specified will ensure that the vehicle meets the stated consumption and emissions performances. The quality of the lubricant is a key factor in the operation and life of the engine.
Page 252 Original fluids and Features Specifications Applications lubricants Low friction coefficient TUTELA STAR 700 Lubricants and greases for grease for constant velocity Differential-side constant 9.55580-GRAS II Contractual Technical drive transmission system joints. NLGI consistency 0- velocity joints Reference No. F701.C07 Synthetic fluid for brake and clutch systems.
Page 253 IMPORTANT 120) The use of products with specifications other than those indicated above could cause damage to the engine not covered by the warranty.
Page 254: Performance
PERFORMANCE Top speed achievable after the car break-in period. Versions km/h 1.3 130HP 1.3 150HP 1.6 16V Multijet 120 HP...
Page 255: Fuel Consumption And Co 2 Emissions
FUEL CONSUMPTION AND CO 2 EMISSIONS The fuel consumption and CO emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the vehicle is registered. Type of route, traffic, weather conditions, driving style, general condition of the vehicle, level of equipment/accessories, use of the climate control system, vehicle load, presence of roof rack, and other situations that negatively affect the aerodynamics or resistance will lead to different consumption values.
Page 256: Provisions For The Treatment Of End-Of-Life
PROVISIONS FOR THE TREATMENT OF END-OF-LIFE VEHICLES (where present) For years, Fiat has been committed to protecting the environment through the continuous improvement of production processes and the manufacture of products that are ever more environmentally friendly. To grant customers the best possible service in terms of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life, FCA is offering its customers the chance to hand over their vehicle at the end of its life without incurring any additional costs.
Page 257 Uconnect™ 8.4" NAV DAB Radio (only Compass 4xe versions) ..... . . 292 CONNECTED SERVICES - UCONNECT SERVICES .
Page 258: Tips, Controls And General Information
In case you lose the car radio passport, products to clean the display lens and the paragraph below. please go to Jeep Dealership with an ID make sure that the Uconnect™ system is and the car papers. switched off during cleaning;...
Page 259 Immediately stop using the system in the event of a fault. Otherwise the system might be damaged. Contact a Jeep Dealership as soon as possible to have the system repaired. WARNING 351) Follow the safety rules here below:...
Page 260: Uconnect™ 5" Live
Uconnect™ 5” LIVE CONTROLS ON FRONT PANEL 5520404D...
Page 261 Short button press SETTINGS Access the settings menu Short button press Access to the additional functions: (e.g. Time display, Compass, Outside temperature, Media APPS Short button press Radio and Uconnect™LIVE services where provided) Scrolling the list or tuning to a radio station or...
Page 262 CONTROLS ON THE STEERING WHEEL (where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below. 5520407D Controls on steering wheel summary table Hard-key...
Page 263 Controls behind the steering wheel Buttons Interaction Button A (steering wheel left side) Brief button press: search for next radio station or selection of USB next track. Upper button Long button press: scan of higher frequencies until released/fast forward of USB track.
Page 264 "TOUCH SCREEN" FUNCTION Bluetooth SOURCE “Info”: additional information on the source being listened to; The system uses the "touch screen” Pairing a Bluetooth®audio device “Audio”: access to the “Audio setting” function; to interact with the different Proceed as follows: screen. functions, press the "graphic buttons"...
Page 265 WARNING If the connection is lost press the PHONE button on the the list of devices paired to the radio, between Bluetooth® and the mobile deleting the previous system pairing from front panel; phone and system, consult the mobile the available Bluetooth device list on the if no phone is paired with the system phone's instruction handbook.
Page 266 (grayed out). functions are, such as: Settings, When a text message is received, the Compass (if available in the navigation display will show a screen where the Okay system), Uconnect™LIVE applications. options "Listen", "Call" or "Ignore" can be I can't talk right now If the Uconnect™...
Page 267 Through the Radio menu dedicated (email and password), so the contents of available on www.jeep-official.it or for the Uconnect™LIVE services you your own personal account are protected www.driveuconnect.eu. can access the "Settings" paragraph by and accessible only by the real user.
Page 268 Trip data storage and transfer the internal memory of the Uconnect™ monitor the following parameters: acceleration/deceleration/gear LIVE system could fill up: in this case, The trip data can be stored in the system shift/speed. follow the recommendations provided by memory and transferred using a suitably the messages on the Uconnect™...
Page 269 SETTINGS that indicate the route of the car on the driver that there is an obstacle via display. acoustic signal only, using the car Press the SETTINGS button on the “ParkView Camera Delay” (where speakers. front panel to display the “Settings” "Sound &...
Page 270 VOICE COMMANDS The options available are: Show SMS Send SMS to <0127457322> "Off": the system is deactivated; NOTE For languages not supported Show messages "Sound Only": the system warns the by the system, voice controls are not driver that there is an obstacle via Radio voice controls available.
Page 271 Show current trip Show previous trip...
Page 272: Uconnect™ 7" Hd Live
Uconnect™ 7” HD LIVE COMMANDS 5520405D...
Page 273: Radio
Bluetooth® Telephone Access to the Phone mode Press graphic button Access to additional functions (display of Apps Time, Compass, Outside temperature, Media Press graphic button Player and App/Services in the car) Compass (where provided) Viewing compass information Press graphic button...
Page 274 CONTROLS ON DASHBOARD Hard-key Functions Modes On/off Short button press / VOLUME Volume Control Left/right rotation of knob SCREEN OFF Display on/off Short button press MUTE Volume activation/deactivation (Mute/Pause) Short button press Confirmation of the option displayed Browsing Short button press lists opening (Radio mode and Media mode) Scrolling the list or tuning to a radio station TUNE SCROLL / BROWSE ENTER...
Page 275 CONTROLS ON THE STEERING WHEEL (where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below. 5520407D Controls on steering wheel summary table Hard-key...
Page 276 CONTROLS BEHIND THE STEERING WHEEL Buttons Interaction Button A (steering wheel left side) Brief button press: search for next radio station or selection of USB next track. Upper button Long button press: scan of higher frequencies until released/fast forward of USB track.
Page 277 "TOUCH SCREEN" FUNCTION "Audio": access to the "Audio Settings" “Shuffle": to play the tracks in random screen. order; The system uses the "touch screen” Track progress and duration. function; to interact with the different Audio menu functions, press the "graphic buttons" In the middle: information on the track To access the "Audio"...
Page 278 USB / AUX SOURCE USB device you can also use the TUNE when requested by the audio device, SCROLL / BROWSE ENTER button/knob enter the PIN code shown on the system USB source or buttons to scroll through display or confirm on the device the PIN The car has a USB/AUX port located on the list of artists, genres and albums displayed on the device...
Page 279 connected to the AUX socket after conditions; this function is deactivated NOTE After updating the phone software, disconnection. when the car is moving. for proper operation, it is recommended to remove the phone from the list of PHONE MODE The pairing procedure for a mobile phone devices linked to the radio, delete the is described below: always consult the Phone mode activation...
Page 280 graphic button is deactivated (grayed graphic button the user will not receive NOTE For details on how to send an SMS out). notifications of incoming calls or text using the voice commands, refer to the messages. The user can reply with a dedicated paragraph.
Page 281 If the "Phone" option is selected with the Android Auto APP Setup and confirm or hold the "Microphone" Before use, download the Android Auto graphic button pressed (long press on phone not connected, the list of favorite application to your smartphone from the graphic button) on the display in numbers cannot be viewed.
Page 282 Safety/Driving Assistance Brakes Lights Doors & Locks Engine Off Options Audio Phone/Bluetooth® Radio Setup Restore Default Settings Clear Personal Data Restore Apps VOICE COMMANDS For the functions controlled with voice commands, see the description of the Uconnect™ 5” LIVE system.
Page 283: Engine)
Uconnect™ 8.4” HD Nav LIVE (only versions with thermal engine) COMMANDS 5520406D...
Page 284 Interaction with climate control system Climate Press graphic button controls Access to additional functions (display of Time, Compass, Outside temperature, Media Press graphic button Player and App/Services in the car) Activation of front heated seats (where fitted), Checks heated wing mirrors (where fitted),...
Page 285 CONTROLS ON DASHBOARD Button Functions Modes On/off Short button press / VOLUME Volume Control Left/right rotation of knob SCREEN OFF Display on/off Short button press MUTE Volume activation/deactivation (Mute/Pause) Short button press Confirmation of the option displayed Browsing Short button press lists opening (Radio mode and Media mode) Scrolling the list or tuning to a radio station TUNE SCROLL / BROWSE ENTER...
Page 286 CONTROLS ON THE STEERING WHEEL (where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below. 5520407D Controls on steering wheel summary table Button...
Page 287 CONTROLS BEHIND THE STEERING WHEEL Buttons Interaction Button A (steering wheel left side) Brief button press: search for next radio station or selection of USB next track. Upper button Long button press: scan of higher frequencies until released/fast forward of USB track.
Page 288 "TOUCH SCREEN" FUNCTION "Select Source": select the required Track selection The system uses the "touch screen” audio source. The “Tracks” function allows you to open function; to interact with the different On the right: display of the following a window with the list of tracks being functions, press the "graphic buttons"...
Page 289 the AUX output socket the system starts PHONE MODE the system yet, the display shows a reproducing the AUX source connected, dedicated screen; Phone mode activation if it is already playing. select “Yes" to start the pairing To activate the phone mode and procedure, then search for the Adjust the volume using the VOLUME record/pair the phone to be used (if it...
Page 290 Making a phone call the mobile phone (the list displays a Call me maximum of 60 messages received). I'll call you later A call can be made by: I’m on my way redialing a phone number that was NOTE On some mobile phones, to Thanks previously dialed;...
Page 291 reader" to display and read the last 10 “Climate” To use Apple CarPlay, the smartphone SMS text messages received. “Controls” must be connected to the car by means "Nav" of a USB cable. Browsing favorites "Phone" Android Auto APP Setup (where provided) "Settings"...
Page 292 USB port. possible to zoom in on minor roads); NOTE To update the navigation maps, “Time of Arrival/Estimated Time to SETTINGS contact a Jeep Dealership. Destination/Distance" (only during Press the button to access the navigation): press this button at the top To activate the main navigation menu, "Settings"...
Page 293 "Turn List" (only during navigation): press the list of turns along the route at the middle of the top of the display. Select a turn through the following options: “Show on Map” or “Avoid Street”. "Options": press this button to display the map display options.
Page 294: Versions)
Uconnect™ 8.4" NAV DAB Radio (only Compass 4xe versions) COMMANDS 5520406D...
Page 295 Interaction with climate control system Climate Press graphic button controls Access to additional functions (display of Time, Compass, Outside temperature, Media Press graphic button Player and App/Services in the car) Activation of front heated seats (where fitted), Checks heated wing mirrors (where fitted),...
Page 296 CONTROLS ON DASHBOARD Button Functions Modes On/off Short button press / VOLUME Volume Control Left/right rotation of knob SCREEN OFF Display on/off Short button press MUTE Volume activation/deactivation (Mute/Pause) Short button press Confirmation of the option displayed Browsing Short button press lists opening (Radio mode and Media mode) Scrolling the list or tuning to a radio station TUNE SCROLL / BROWSE ENTER...
Page 297 CONTROLS ON THE STEERING WHEEL (where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below. 5520407D Controls on steering wheel summary table Button...
Page 298 CONTROLS BEHIND THE STEERING WHEEL Buttons Interaction Button A (steering wheel left side) Brief button press: search for next radio station or selection of USB next track. Upper button Long button press: scan of higher frequencies until released/fast forward of USB track.
Page 299 "TOUCH SCREEN" FUNCTION "Tune” : manual radio station tuning; “Shuffle": to play the tracks in random “Audio”: access to the “Audio setting” order; The system uses the "touch screen” screen. Track progress and duration. function; to interact with the different functions, press the "graphic buttons"...
Page 300 USB / AUX SOURCE USB device you can also use the TUNE when requested by the audio device, SCROLL / BROWSE ENTER button/knob enter the PIN code shown on the system USB source or buttons to scroll through display or confirm on the device the PIN The car has a USB/AUX port located on the list of artists, genres and albums displayed on the device...
Page 301 PHONE MODE of Bluetooth® devices on the phone and handbook for the mobile phone in any case. make a new pairing. Phone mode activation To pair the mobile phone, proceed as Making a phone call Press the “Phone” button on the display follows: to activate the Phone mode.
Page 302 SMS message reader Press the "SMS" graphic button to access Browsing text messages the list of text messages received by Default SMS messages are stored in (where provided) the mobile phone (the list displays a the system memory and can be sent to Using the steering wheel commands, you maximum of 60 messages received).
Page 303 Apple CarPlay and Android Auto The application is compatible with Navigation Android 5.0 (Lollipop) and later versions. (where provided) If the system's “Nav” mode is already To use Android Auto, the smartphone active, or when a device is connected The Apple CarPlay and Android Auto must be connected to the car by means to the car with a navigation session applications allow you to use your...
Page 304 Phone/Bluetooth® Radio Setup “Parking”: select this button to Press this button to open the search for car parks. "Settings" menu; Restore Default Settings Clear Personal Data Restore Apps Select this button to open “Charging station”: select this the "Help" menu. The "Help" button to search for charging VOICE COMMANDS menu contains information on...
Page 305: Connected Services - Uconnect Services
The navigation system can also be with legal requirements. Read more updated at the Jeep Dealership. about the general conditions of service NOTE The dealer may charge for and data protection policies on the Jeep updating the navigation system. official website.
Page 306 For "Compass 4xe" versions may be available for different durations. routed to a private FCA Call Centre. We only it is also possible to use the...
Page 307 "Settings" paragraph to deactivate the official Jeep website, by contacting NOTE The hotspot name and password the function. the Customer Care or by going to a Jeep can only be changed with the ignition Dealership. device in RUN position and engine...
Page 308: Mopar® Connect
FAQ on the tracing remains active for the assistance www.driveuconnect.eu portal, contact services, where provided, in the event the Jeep Dealership or contact Customer of accident or vehicle theft, but is not Care. visible to the customer.
Page 309 WARNINGS AND RECOMMENDATIONS IMPORTANT GLOVE BOX Do not operate this vehicle with a glove box in the open position. Driving with the glove box open may result in injury in a collision. TUNNEL GLOVE BOX COMPARTMENT Do not operate this vehicle with a tunnel compartment lid in the open position. Driving with the tunnel compartment lid open may result in personal injury in case of an accident.
Page 310 An improperly adjusted weight distributing hitch system may reduce handling, stability, and braking performance and could result in a collision. Weight Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or Jeep authorized dealer.
Page 311 EXHAUST SYSTEM Exhaust gases can injure or kill. They contain carbon monoxide, a colorless, odorless gas which can cause fainting and poisoning if inhaled. The exhaust system can reach high temperatures and can start a fire if you park over materials that can burn. Also grass or dry leaves can catch fire if they come into contact with the exhaust system.
Page 312 GENERAL INFORMATION Improperly inflated tires are dangerous and can cause accidents. Underinflation increases tire flexing and can result in tire overheating and failure. Overinflation reduces a tire’s ability to cushion shock. Objects on the road and chuck holes can cause damage that results in tire failure. Overinflated or underinflated tires can affect vehicle handling and can fail suddenly, resulting in loss of vehicle control.
Page 313 Tires and the spare tire should be replaced after six years, regardless of the remaining thread. Failure to follow this warning can result in sudden tire failure. You could lose control and have a collision resulting in serious injury or death. Do not use a tire, wheel size, load rating, or speed rating other than that specified for your vehicle.
Page 314 If the pointer remains on the “H,” and you hear continuous chimes, turn the engine OFF immediately, and call a Jeep authorized dealer for service.
Page 315 Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involving engine misfire or other apparent loss of performance, contact a Jeep authorized dealer immediately. Continued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and vehicle.
Page 317 Fully synthetic lubricant developed for American design petrol engines Fully synthetic Low SAPS lubricant for Euro 6 diesel engines. High fuel economy.
Page 319 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
Page 320 NOTES...
Page 321 CONTENTS EOBD System ....56 Performance (top speed) ..252 Exterior Lights ....32 Periodic checks .
Page 322 Towing a disabled vehicle ..208 Trailer Towing Requirements ..169 Trip computer ....61 Trunk ..... 51 Twin clutch automatic transmission .

Jeep COMPASS Owner's Handbook Manual

Graphical

Knowledge of the Vehicle

Knowing the Instrument Panel

Safety

Starting and Driving

In Case of Emergency

Maintenance and Care

Technical Data

Multimedia

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Jeep COMPASS

Summary of Contents for Jeep COMPASS

Table of Contents
