- Page 1 Operation Manual Model 600A & 600UHD Moisture Sensor Kit for Large Square Balers Forage Harvester 600A & 600UHD-16-OPR-Imp&Metric 11/19...
- Page 2 European Parliment and the Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.
-
Page 3: Table Of Contents
Operations Manual Table of Contents PAGE Introduction System Requirements Safety Safety Decals Operation of the 600A Moisture Sensor Kit 5-11 Operations of the ISOBUS Monitor Baler Monitor Setup System Setup Adjust the Moisture Alarm Option To Turn OFF/ON All Alarms or Beeps Baler Monitor Setup / View –... -
Page 4: Introduction
Introduction Thank you for purchasing a Harvest Tec moisture monitor system. This moisture monitoring system has been designed to be operated through the baler’s ISOBUS system and/or an Apple iPad (not included) using the Hay App. The unit offers these advantages: 1. -
Page 5: Operation Of The 600A Moisture Sensor Kit
Operation of 600A Moisture Sensor Kit Operation of the ISOBUS Monitor The ISOBUS Monitor utilizes a combination of soft keys, number menus, and the scroll wheel on the upper right side of the actual monitor to make selections. Selections are made by scrolling the Thumb Wheel and pressing in once the selection is highlighted. -
Page 6: System Setup
System Setup 1. To view moisture from the 600A Moisture Sensor begin setup at the main baler screen. Select the WRENCH icon (arrow A) which is the fourth icon down on the right side of the screen-the right menu. 2. The service screen displayed below should appear. Select the Next Screen icon (arrow B) located at the bottom of the right selection menu. - Page 7 5. The A B 2 screen will appear. The Harvest Tec On/Off selection icon can now be selected. To turn the Harvest Tec Moisture Sensor On (signified by a green check mark) or Off (signified by a red X) navigate to the box and select (arrow E) by pressing the Scroll Wheel.
- Page 8 7. Once the user has selected the container they would like to change, a drop down list (arrow H) will appear. The Moisture option (arrow I) should be at the bottom of the drop down selection list. 8. The Moisture container will have a red background until HayBoss G2 system is put in Manual Mode or Auto Mode.
-
Page 9: Adjust The Moisture Alarm
Adjust the Moisture Alarm 1. From the main baler screen, select the third icon down the right selection menu that shows a diamond beside a baler (arrow K). 2. To adjust the moisture alarm set point select the box option to the right of the moisture droplets (arrow L) and adjust to the desired moisture limit. -
Page 10: Option To Turn Off/On All Alarms Or Beeps
Option to turn Off/On all Alarms or Beeps 1. From the main baler work screen select the third icon down the right selection menu that shows a diamond beside a baler (arrow N). 2. Select the fourth icon on the right selection menu showing a bugle beside an alarm icon (arrow O). 3. -
Page 11: Baler Monitor Setup / View - Uhd Baler Only
Baler Monitor Setup / View – UHD Baler Only These four containers can be configured by the This container is reserved for the operator. In the selectable list are the items for moistures system. It shows the tagger your system. They are Current moisture, status and applicator status. -
Page 12: Wiring Diagram
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. IF MODIFICATIONS ARE REQUIRED CONTACT HARVEST TEC FIRST! b. This unit will not function on positive ground tractors. - Page 13 Pin Outs Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black...
- Page 14 Pin Outs (continued) 006-6650VA to 006-6650LS2(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield 3 4 5 Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A 006-6650VA &...
-
Page 15: Common Questions
Common Questions 1. How do I turn the system on/off? To turn the system ON open the Hay App, then select the active system for the baler you are using. Press the Wake Up tab if the system was put into Standby mode when last used. If not in Standby mode, select Automatic or Manual mode to begin. -
Page 16: Troubleshooting
5. Short in wire between star 5. Replace wire. wheels and DCP. 6. Check hay with hand tester 6. Contact Harvest Tec if conditions to verify. persist. Moisture readings erratic. 1. Test bales with hand tester to verify that DCP has more variation than hand tester. -
Page 17: Parts Breakdown
Parts Breakdown Star Wheels and Bale Rate Sensors Ref Description Part# Description Part# Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left for AGCO 001-4645H Snap ring (per side) 006-4641K 001-4644H AGCO Twine guard-right for... -
Page 18: Controls And Harnesses
Parts Breakdown for 600A & 600UHD Series Control and Harnesses Ref Description Part Number End Of Bale Sensor 006-7400 Terminating Connector w green cap 006-5650Z End of Bale Sensor Bracket 001-4648 DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO 006-6671LS DCP Baler Harness 30 FT 006-6650LS2(E) -
Page 19: Warranty
Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 20 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
