- Page 1 Installation Manual Model 600A1 Moisture Sensor Kit for Large Square Balers Forage Harvester 600A1-15-INST 2/15...
- Page 2 DECLARATION OF APPLICATION OF ESSENTIAL REQUIREMENTS OF THE DIRECTIVE 2006/42/ EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 17, MAY, 2006 AND OTHER RELEVANT EU DIRECTIVES: The Harvest Tec Hay Moisture Sensor Kit conforms with the Directive and other relevant EU directives.
-
Page 3: Table Of Contents
600A1 Installation Manual Table of Contents PAGE Introduction System Requirements Tools Needed Safety Safety Signs Installing the 600A1 Moisture Sensor Kit Mount the Dual Channel Processor (DCP) Installing Star Wheels Wiring Installation Connecting the Star Wheels to DCP Connecting the Harnesses to the DCP Parts Breakdown 9-10 Controls and Harnesses... -
Page 4: System Requirements
System Requirements The Baler Processor must have Version 3.3 or higher. Tools Needed: - Standard wrench set - Side cutter - Standard socket set - Electric drill and bits - Standard nut driver set - Hammer & Center Punch Safety Carefully read all safety signs in this manual and on the moisture sensor kit before use. -
Page 5: Installing The 600A1 Moisture Sensor Kit
Installing the 600A1 Moisture Sensor Kit Mounting the Dual Channel Processor (DCP) Locate the Dual Channel Processor (006-6671LS), four 5/16” x 1” hex bolts, flats, locks and nuts. Mark, and drill four 3/8” (9.525 mm) holes following the template shown below. The whip wire extension on the DCP should be facing down when attached to the baler. -
Page 6: Installing Star Wheels
Installing Star Wheels The star wheel block has a plug on one side and a wire grommet on the other side. If there is interference or problems with the star wheel wires on one side of the block, exchange the wire grommet with the plug so the wire can exit the block on the opposite side. -
Page 7: Wiring Installation
If your baler has the White Terminating Resistor you will need to attach the Pre 2012 AGCO Integration Harness (006-6650VAX) to the end of the Baler Interface harness (006-6650VC). Please contact Harvest Tec for this harness. This style terminator may be next to the Baler’s Main Processor. -
Page 8: Connecting The Star Wheels To Dcp
Connecting the Star Wheels to the DCP Locate the moisture harness (006-4640E2). Remove the four pan head screws on each star wheel and loosen the grommet. Insert the eye loop of the wire into the star wheel block and install on the end of the swivel. Leave a loop in the wire to allow the star wheel cover space to be reinstalled. -
Page 9: Parts Breakdown
Controls and Harnesses Ref # Description Part # Ref # Description 5/16” nuts Star wheel spacer 001-6707E 5/16” lock washers Star wheels 030-4641 5/16” flat washer Moisture harness 006-4640E2 10/24 x 5/8” PHS DCP cover 001-5650X Dual Channel Processor 006-6671LS 10/24 lock washers 5/16”... -
Page 10: Star Wheel Sensors
Star Wheel Sensors Ref # Description Part# Ref # Description Part# Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left for Agco 001-4645H Snap ring (per side) 006-4641K Twine guard-Right for Agco 001-4644H... -
Page 11: Warranty Statement
WARRANTY AND LIABILITY AGREEMENT Harvest Tec, Inc. will repair or replace components that are found to be defective within 12 months from the date of manufacture. Under no circumstances does this warranty cover any components which in the opinion of Harvest Tec, Inc. have been subjected to negligent use, misuse, alteration, accident, or if repairs have been made with parts other than those manufactured and obtainable from Harvest Tec, Inc. - Page 12 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
